8.6
Machine safety terminal block circuit board (JANCD-YFC22-
E)
The machine safety terminal block circuit board (JANCD-YFC22-E) is for the system
external signal to connect with the safety I/O signals.
connection diagrams of each item.
Machine safety I/O logic circuit board I/F connector (CN219)
1
26-50
1-25
51-75
Fig. 8-4: Machine safety terminal block (-X18)
Description of Units and Circuit Boards
For connection, refer to the
-AE4
-CN219
(348744-10)
-
8
57
