WAFER-BT

Figure 3-3: Audio Connector Location

P IN NO. DES CRIP TION
1 LINE_OUTR
3 Analog_GND
5 LINE_OUTL
7 Analog_GND
9 LMIC1-R

Table 3-4: Audio Connector Pinouts

3.2.3 Ba tte ry Co n n e c to r
CN La b e l:
CN Typ e :
CN Lo c a tio n :
CN P in o u ts :
The battery connector is connected to the system battery. The battery provides power to
the system clock to retain the time when power is turned off.
P IN NO.
2
4
6
8
10
BAT1
2-pin wafer
See Figure 3-4
See Table 3-5
DES CRIP TION
LINEIN_R
Analog_GND
LINEIN_L
Analog_GND
LMIC1-L
P a g e 19
