IEI Technology WAFER-PV-D5253 User Manual

3.5" sbc with intel atom processor up to 2.0 gb ddr3, vga, 18-bit+48-bit lvds, pcie mini sata 3gb/s, rs-232/422/485, compactflash eight usb 2.0, rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WAFER-PV-D5253/D4253/N4553 SBC
IEI Technology Corp.
MODEL:
WAFER-PV-D5253/D4253/N4553
3.5" SBC with Intel® Atom™ Processor
Up to 2.0 GB DDR3, VGA, 18-bit+48-bit LVDS, PCIe Mini
SATA 3Gb/s, RS-232/422/485, CompactFlash®
Rev. 1.00 – 27 June, 2011
Eight USB 2.0, RoHS

User Manual

Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAFER-PV-D5253 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology WAFER-PV-D5253

Summary of Contents for IEI Technology WAFER-PV-D5253

  • Page 1: User Manual

    WAFER-PV-D5253/D4253/N4553 SBC IEI Technology Corp. MODEL: WAFER-PV-D5253/D4253/N4553 3.5" SBC with Intel® Atom™ Processor Up to 2.0 GB DDR3, VGA, 18-bit+48-bit LVDS, PCIe Mini SATA 3Gb/s, RS-232/422/485, CompactFlash® Eight USB 2.0, RoHS User Manual Page i Rev. 1.00 – 27 June, 2011...
  • Page 2 WAFER-PV-D5253/D4253/N4553 SBC Revision Date Version Changes 27 June, 2011 1.00 Initial release Page ii...
  • Page 3 WAFER-PV-D5253/D4253/N4553 SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    WAFER-PV-D5253/D4253/N4553 SBC Table of Contents 1 INTRODUCTION......................1 1.1 I ......................2 NTRODUCTION 1.2 B ........................3 ENEFITS 1.3 F ........................3 EATURES 1.4 C ......................4 ONNECTORS 1.5 D ....................... 5 IMENSIONS 1.6 D ........................ 6 1.7 T ..................7...
  • Page 5 WAFER-PV-D5253/D4253/N4553 SBC 3.2.11 LVDS2 Connector................... 24 3.2.12 LVDS Backlight Connector ................25 3.2.13 LVDS2 Backlight Connector ................26 3.2.14 PCIe Mini Card Slot ..................27 3.2.15 Power Button Connector................28 3.2.16 Reset Button Connector ................. 29 3.2.17 RS-232/422/485 Serial Port Connector (COM2) .......... 30 3.2.18 RS-232 Serial Port Connector (COM1, COM3)..........
  • Page 6 WAFER-PV-D5253/D4253/N4553 SBC 4.6.1 Airflow......................53 4.6.2 Motherboard Installation................. 53 4.7 I ............53 NTERNAL ERIPHERAL EVICE ONNECTIONS 4.7.1 AT Power Connection ..................53 4.7.2 Audio Kit Installation..................54 4.7.3 Keyboard/Mouse Connector ................56 4.8 E ........... 58 XTERNAL ERIPHERAL NTERFACE ONNECTION 4.8.1 LAN Connection (Single Connector) ...............
  • Page 7 WAFER-PV-D5253/D4253/N4553 SBC 5.6 S ......................... 86 ECURITY 5.7 E ......................... 86 A BIOS OPTIONS ......................88 B ONE KEY RECOVERY ..................... 91 B.1 O ..............92 ECOVERY NTRODUCTION B.1.1 System Requirement..................93 B.1.2 Supported Operating System ................94 B.2 S ................
  • Page 8 WAFER-PV-D5253/D4253/N4553 SBC List of Figures Figure 1-1: WAFER-PV-D5253/D4253/N4553 Front View............2 Figure 1-2: WAFER-PV-D5253/D4253/N4553 Solder View............2 Figure 1-3: Connectors Front View...................4 Figure 1-4: Connectors Solder View..................4 Figure 1-5: Dimensions (mm) ....................5 Figure 1-6: Data Flow Diagram ....................6 Figure 3-1: Connector and Jumper Locations ............... 14 Figure 3-2: ATX Power Connector Location................
  • Page 9 WAFER-PV-D5253/D4253/N4553 SBC Figure 3-25: USB Connector Location..................35 Figure 3-26: External Interface Connectors ................36 Figure 3-27: Ethernet Connector .................... 37 Figure 3-28: Serial Port Pinout Locations ................38 Figure 3-29: VGA Connector....................39 Figure 4-1: SO-DIMM Installation .................... 43 Figure4-2: SO-DIMM Location....................
  • Page 10 WAFER-PV-D5253/D4253/N4553 SBC Figure B-9: Press any key to continue ................. 101 Figure B-10: Press F3 to Boot into Recovery Mode............. 102 Figure B-11: Recovery Tool Menu ..................102 Figure B-12: About Symantec Ghost Window ..............103 Figure B-13: Symantec Ghost Path ..................103 Figure B-14: Select a Local Source Drive................
  • Page 11 WAFER-PV-D5253/D4253/N4553 SBC List of Tables Table 1-1: Technical Specifications..................8 Table 2-1: Packing List......................12 Table 2-2: Optional Items ......................12 Table 3-1: Peripheral Interface Connectors ................15 Table 3-2: Rear Panel Connectors ..................16 Table 3-3: ATX Power Connector Pinouts................17 Table 3-4: Audio Connector Pinouts ..................
  • Page 12 WAFER-PV-D5253/D4253/N4553 SBC Table 3-28: Serial Port Pinouts ....................38 Table 3-29: USB Connector Pinouts..................38 Table 3-30: VGA Connector Pinouts..................39 Table 4-1: Jumpers........................46 Table 4-2: AT/ATX Mode Selection ..................47 Table 4-3: Clear CMOS Jumper Settings ................48 Table 4-4: LVDS Voltage Selection ..................
  • Page 13 WAFER-PV-D5253/D4253/N4553 SBC BIOS Menus BIOS Menu 1: Main ........................67 BIOS Menu 2: Advanced ......................68 BIOS Menu 3: ACPI Configuration..................69 BIOS Menu 4: CPU Configuration................... 70 BIOS Menu 5: IDE Configuration .................... 71 BIOS Menu 6: USB Configuration................... 72 BIOS Menu 7: Super IO Configuration..................

  • Page 15: Introduction

    WAFER-PV-D5253/D4253/N4553 SBC Chapter Introduction Page 1...

  • Page 16: Introduction

    WAFER-PV-D5253/D4253/N4553 SBC 1.1 Introduction Figure 1-1: WAFER-PV-D5253/D4253/N4553 Front View Figure 1-2: WAFER-PV-D5253/D4253/N4553 Solder View The WAFER-PV-D5253/D4253/N4553 is a 3.5" SBC with a Intel® Atom™ D525, D425 or N455 CPU. Page 2...

  • Page 17: Benefits

    WAFER-PV-D5253/D4253/N4553 SBC The WAFER-PV-D5253/D4253/N4553 is designed for fanless operation. The low power CPUs do not require active cooling to stay within the specified heat range using the included heatsink. Storage on the board is handled by a SATA 3Gb/s port for connecting a hard drive, optical drive or SSD.

  • Page 18: Connectors

    WAFER-PV-D5253/D4253/N4553 SBC 1.4 Connectors The connectors on the WAFER-PV-D5253/D4253/N4553 are shown in the figure below. Figure 1-3: Connectors Front View Figure 1-4: Connectors Solder View Page 4...

  • Page 19: Dimensions

    WAFER-PV-D5253/D4253/N4553 SBC 1.5 Dimensions The main dimensions of the WAFER-PV-D5253/D4253/N4553 are shown in the diagram below. Figure 1-5: Dimensions (mm) Page 5...

  • Page 20: Data Flow

    WAFER-PV-D5253/D4253/N4553 SBC 1.6 Data Flow Figure 1-6 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-6: Data Flow Diagram Page 6...

  • Page 21: Technical Specifications

    WAFER-PV-D5253/D4253/N4553 SBC 1.7 Technical Specifications WAFER-PV-D5253/D4253/N4553 technical specifications are listed in Table 1-1. Specification WAFER-PV-D5253/D4253/N4553 Form Factor 3.5" Socket Embedded 1.8 GHz Intel® Atom™ D525 dual-core CPU with 1 MB L2 cache CPU Supported 1.8 GHz Intel® Atom™ D425 single-core CPU with 512 KB L2 cache 1.66 GHz Intel®...

  • Page 22: Table 1-1: Technical Specifications

    WAFER-PV-D5253/D4253/N4553 SBC I/O Interface Connectors Fan connector One 3-pin wafer CPU fan One 3-pin wafer system fan Keyboard/Mouse One internal 6-pin wafer connector Serial Ports Three RS-232 COM connectors One RS-232/422/485 COM connector USB 2.0/1.1 ports Four internal via pin header...

  • Page 23: Packing List

    WAFER-PV-D5253/D4253/N4553 SBC Chapter Packing List Page 9...

  • Page 24: Anti-Static Precautions

    Only handle the edges of the PCB:- Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the WAFER-PV-D5253/D4253/N4553 is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 25: Packing List

    Contact the IEI reseller or vendor the WAFER-PV-D5253/D4253/N4553 was purchased from or contact an sales representative directly sending email sales@iei.com.tw. The WAFER-PV-D5253/D4253/N4553 is shipped with the following components: Quantity Item and Part Number Image WAFER-PV-D5253, WAFER-PV-D4253 or WAFER-PV-N4553 AT 12 V cable...

  • Page 26: Optional Items

    WAFER-PV-D5253/D4253/N4553 SBC Quantity Item and Part Number Image Utility CD Quick installation guide Table 2-1: Packing List 2.4 Optional Items These optional items are available. Item and Part Number Image Dual USB cable (without bracket) (P/N: 32000-070301-RS) SATA cable (P/N: 32000-0628000-RS)

  • Page 27: Connectors

    WAFER-PV-D5253/D4253/N4553 SBC Chapter Connectors Page 13...

  • Page 28: Peripheral Interface Connectors

    Figure 3-1: Connector and Jumper Locations 3.1.2 Peripheral Interface Connectors The table below shows a list of the peripheral interface connectors on the WAFER-PV-D5253/D4253/N4553. Detailed descriptions of these connectors can be found below. Connector Type Label...

  • Page 29: Table 3-1: Peripheral Interface Connectors

    WAFER-PV-D5253/D4253/N4553 SBC Connector Type Label CompactFlash® card slot CF card slot Digital I/O connector 10-pin header DIO1 Fan connectors 3-pin wafer FAN1, FAN2 Keyboard/mouse connector 6-pin wafer KB/MS1 Keypad connector 9-pin header KEY1 LED indicators and 5 V power output...

  • Page 30: External Interface Panel Connectors

    WAFER-PV-D5253/D4253/N4553 SBC 3.1.3 External Interface Panel Connectors The table below lists the rear panel connectors on the WAFER-PV-D5253/D4253/N4553. Detailed descriptions of these connectors can be found in a later section. Connector Type Label USB connectors Dual-USB USB3, USB4 LAN connector...

  • Page 31: Audio Connector

    WAFER-PV-D5253/D4253/N4553 SBC Description Description Table 3-3: ATX Power Connector Pinouts 3.2.2 Audio Connector CN Label: AUDIO1 CN Type: 10-pin header CN Location: See Figure 3-3 CN Pinouts: See Table 3-4 This connector connects to speakers, a microphone and an audio input.

  • Page 32: Compactflash® Slot

    WAFER-PV-D5253/D4253/N4553 SBC CN Type: 2-pin wafer CN Location: See Figure 3-4 CN Pinouts: See Table 3-5 This is connected to the system battery. The battery provides power to the system clock to retain the time when power is turned off.

  • Page 33: Figure 3-5: Compactflash® Slot Location

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-5: CompactFlash® Slot Location Description Description CD1# CE2# VS1# IOR# IOW# CSEL# VS2# RESET# WAIT# INPACK# REG# BVD2 BVD1 IOCS16# CD2# GND2 Table 3-6: CompactFlash® Slot Pinouts Page 19...

  • Page 34: Digital I/O Connector

    WAFER-PV-D5253/D4253/N4553 SBC 3.2.5 Digital I/O Connector CN Label: DIO1 CN Type: 10-pin header CN Location: See Figure 3-6 CN Pinouts: See Table 3-7 The digital I/O connector provides programmable input and output for external devices. The digital I/O provides 4-bit output and 4-bit input.

  • Page 35: Keyboard/Mouse Connector

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-7: Fan Connector Locations Description FANIO1 +12V (PWM) Table 3-8: Fan Connector Pinouts 3.2.7 Keyboard/Mouse Connector CN Label: KB/MS1 CN Type: 6-pin wafer CN Location: See Figure 3-8 CN Pinouts: See Table 3-9 The keyboard/mouse connector connects to a PS/2 Y-cable that can be connected to a PS/2 keyboard and mouse.

  • Page 36: Keypad Connector

    WAFER-PV-D5253/D4253/N4553 SBC Description Mouse Data Mouse Clock Keyboard Data Keyboard Clock Table 3-9: Keyboard/Mouse Connector Pinouts 3.2.8 Keypad Connector CN Label: KEY1 CN Type: 9-pin header CN Location: See Figure 3-8 CN Pinouts: See Table 3-9 The keypad connector connects to a keypad device.

  • Page 37: Led And +5 V Power Output Connector

    WAFER-PV-D5253/D4253/N4553 SBC Description Ground Table 3-10: Keypad Connector Pinouts 3.2.9 LED and +5 V Power Output Connector CN Label: CN Type: 6-pin wafer CN Location: See Figure 3-10 CN Pinouts: See Table 3-11 The connector connects to the hard drive activity LED and power LED on the system front panel.

  • Page 38: Lvds2 Connector

    WAFER-PV-D5253/D4253/N4553 SBC CN Type: 20-pin crimp CN Location: See Figure 3-11 CN Pinouts: See Table 3-12 The LVDS connector is for an LCD panel connected to the board. Figure 3-11: LVDS Connector Location Description Description GND1 GND2 A_Y0 A_Y0# A_Y1...

  • Page 39: Lvds Backlight Connector

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-12: LVDS2 Connector Location Description Description GND1 GND2 A_Y0 A_Y0# A_Y1 A_Y1# A_Y2 A_Y2# A_CK A_CK# A_Y3 A_Y3# GND3 GND4 B_Y0 B_Y0# B_Y1 B_Y1# B_Y2 B_Y2# B_CK B_CK# B_Y3 B_Y3# GND5 GND6 VCC_LCD VCC_LCD VCC_LCD VCC_LCD Table 3-13: LVDS2 Connector Pinouts 3.2.12 LVDS Backlight Connector...

  • Page 40: Lvds2 Backlight Connector

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-13: Backlight Inverter Connector Description LCD_BKLTCTL GROUND +12V GROUND BACKLIGHT ENABLE Table 3-14: Backlight Inverter1 Connector 3.2.13 LVDS2 Backlight Connector CN Label: INVERTER2 CN Type: 5-pin wafer CN Location: See Figure 3-13 CN Pinouts: See Table 3-14 The backlight inverter connector provides power to an LCD panel.

  • Page 41: Pcie Mini Card Slot

    WAFER-PV-D5253/D4253/N4553 SBC Description GROUND BACKLIGHT ENABLE Table 3-15: Backlight Inverter2 Connector 3.2.14 PCIe Mini Card Slot CN Label: CN Type: PCIe Mini card slot CN Location: See Figure 3-15 CN Pinouts: See Table 3-16 The PCIe mini card slot enables a PCIe mini card expansion module to be connected to the board.

  • Page 42: Power Button Connector

    WAFER-PV-D5253/D4253/N4553 SBC Description Description PCIRST# PERN2 3VDual PERP2 1.5V SMBCLK PETN2 SMBDATA PETP2 USBD- USBD+ SATARXP SATARXN RF_LINK# SATATXN BLUELED# SATATXP 1.5V VCC3 Table 3-16: PCIe Mini Card Slot Pinouts 3.2.15 Power Button Connector CN Label: PWR_BTN CN Type: 2-pin wafer...

  • Page 43: Reset Button Connector

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-16: Power Button Connector Location Description PWRBTSW- Table 3-17: Power Button Connector Pinouts 3.2.16 Reset Button Connector CN Label: RST_BTN CN Type: 2-pin wafer CN Location: See Figure 3-17 CN Pinouts: See Table 3-18 The reset button connector is connected to a reset switch on the system chassis.

  • Page 44: Rs-232/422/485 Serial Port Connector (Com2)

    WAFER-PV-D5253/D4253/N4553 SBC Description Table 3-18: Reset Button Connector Pinouts 3.2.17 RS-232/422/485 Serial Port Connector (COM2) CN Label: COM2 CN Type: 14-pin header CN Location: See Figure 3-18 CN Pinouts: See Table 3-19 This connector provides RS-232, RS-422 or RS-485 communications.

  • Page 45: Sata Drive Connectors

    WAFER-PV-D5253/D4253/N4553 SBC CN Location: See Figure 3-19 CN Pinouts: See Table 3-20 This connector provides RS-232 connections for serial ports COM1 and COM3. Figure 3-19: RS-232 Serial Port Connector Location Description Description DATA CARRIER DETECT (DCD) DATA SET READY (DSR)

  • Page 46: Sata Power Connectors

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-20: SATA Drive Connector Location Description Table 3-21: SATA Drive Connector Pinouts 3.2.20 SATA Power Connectors CN Label: SATA_PWR1, SATA_PWR2 CN Type: 2-pin wafer CN Location: See Figure 3-21 CN Pinouts: See Table 3-22 Use the SATA Power Connector to connect to SATA device power connections.

  • Page 47: Smbus Connector

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-21: SATA Power Connector Locations Description Table 3-22: SATA Power Connector Pinouts 3.2.21 SMBus Connector CN Label: CN Type: 4-pin wafer CN Location: See Figure 3-22 CN Pinouts: See Table 3-23 The SMBus (System Management Bus) connector provides low-speed system management communications.

  • Page 48: So-Dimm Connector

    WAFER-PV-D5253/D4253/N4553 SBC Description SMBCLK Table 3-23: SMBus Connector Pinouts 3.2.22 SO-DIMM Connector CN Label: DIMM1 CN Type: 204-pin DDR3 SO-DIMM connector CN Location: See Figure 3-23 The SO-DIMM connector is for installing memory on the system. Figure 3-23: SO-DIMM Connector Location 3.2.23 SPI Flash Connector...

  • Page 49: Usb Connectors

    WAFER-PV-D5253/D4253/N4553 SBC Figure 3-24: SPI Flash Connector Location Description Description Table 3-24: SPI Flash Connector Pinouts 3.2.24 USB Connectors CN Label: USB1, USB2 CN Type: 8-pin header CN Location: See Figure 3-25 CN Pinouts: See Table 3-25 The USB header can connect to two USB devices.

  • Page 50: External Interface Connectors

    WAFER-PV-D5253/D4253/N4553 SBC Description Description DATA+ DATA- Table 3-25: USB Port Connector Pinouts 3.3 External Interface Connectors Figure 3-26 shows the WAFER-PV-D5253/D4253/N4553 motherboard external interface connectors. WAFER-PV-D5253/D4253/N4553 on-board external interface connectors are shown in Figure 3-26. Figure 3-26: External Interface Connectors 3.3.1 Ethernet Connectors...

  • Page 51: Serial Port Connector

    WAFER-PV-D5253/D4253/N4553 SBC Description Description Table 3-26: Ethernet Connector Pinouts Figure 3-27: Ethernet Connector The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked. See Table 3-27.

  • Page 52: Usb Ports

    WAFER-PV-D5253/D4253/N4553 SBC Description Description Table 3-28: Serial Port Pinouts Figure 3-28: Serial Port Pinout Locations 3.3.3 USB Ports CN Label: USB3, USB4 CN Type: USB Combo ports CN Location: See Figure 3-26 CN Pinouts: See Table 3-29 The USB ports attach to standard USB devices.

  • Page 53: Figure 3-29: Vga Connector

    WAFER-PV-D5253/D4253/N4553 SBC CN Type: D-sub 15-pin female connector CN Location: See Figure 3-26 CN Pinouts: See Figure 3-29 an Table 3-30 The standard 15-pin female VGA connector connects to a CRT or LCD monitor. Description Description Description CRT_PLUG# GREEN DDCDAT...

  • Page 54: Installation

    WAFER-PV-D5253/D4253/N4553 SBC Chapter Installation Page 40...

  • Page 55: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the WAFER-PV-D5253/D4253/N4553. Dry climates are especially susceptible to ESD. It is therefore critical to strictly adhere to the following anti-static precautions whenever the WAFER-PV-D5253/D4253/N4553, or any other electrical component, is handled.

  • Page 56: Installation Considerations

    4.2 Installation Considerations NOTE: The following installation notices and installation considerations should be read and understood before the WAFER-PV-D5253/D4253/N4553 is installed. All installation notices pertaining to the installation of WAFER-PV-D5253/D4253/N4553 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the WAFER-PV-D5253/D4253/N4553 and injury to the person installing the motherboard.

  • Page 57: So-Dimm Installation

    WAFER-PV-D5253/D4253/N4553 SBC Before and during the installation of the WAFER-PV-D5253/D4253/N4553 DO NOT:  DO NOT remove any of the stickers on the PCB board. These stickers are required for warranty validation.  DO NOT use the product before verifying all the cables and power connectors are properly connected.

  • Page 58: Compactflash® Installation

    WAFER-PV-D5253/D4253/N4553 SBC Step 3: Insert the SO-DIMM. Push the memory in at a 20º angle. (See Figure 4-1) Step 4: Seat the SO-DIMM. Gently push downwards and the arms clip into place. (See Figure 4-1) 4.4 CompactFlash® Installation NOTE: Both CompactFlash® Type I and Type II cards are supported.

  • Page 59: Jumper Settings

    WAFER-PV-D5253/D4253/N4553 SBC Figure 4-3: CompactFlash® Card Installation 4.5 Jumper Settings NOTE: A jumper is a metal bridge that is used to close an electrical circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 60: At/Atx Mode Selection

    WAFER-PV-D5253/D4253/N4553 SBC Before the WAFER-PV-D5253/D4253/N4553 is installed in the system, the jumpers must be set in accordance with the desired configuration. The jumpers on the WAFER-PV-D5253/D4253/N4553 are listed in Table 4-1. Description Label Type AT/ATX mode selection J_AUTOPWR1 3-pin header...

  • Page 61: Clear Cmos Jumper

    Jumper Location: See Figure 4-5 If the WAFER-PV-D5253/D4253/N4553 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 62: Lvds Voltage Selection

    WAFER-PV-D5253/D4253/N4553 SBC Description Keep CMOS Setup (Default) Clear CMOS Setup Table 4-3: Clear CMOS Jumper Settings Figure 4-5: Clear CMOS Jumper Location 4.5.3 LVDS Voltage Selection Jumper Label: J_VLVDS1, J_VLVDS2 Jumper Type: 3-pin header Jumper Settings: See Table 4-4 Jumper Location: See Figure 4-6 and Figure 4-7 Selects the voltage of the LVDS connector.

  • Page 63: Lvds1 Resolution Selection

    WAFER-PV-D5253/D4253/N4553 SBC Figure 4-7: LVDS2 Voltage Selection Jumper Location 4.5.4 LVDS1 Resolution Selection Jumper Label: J_LCD_TYPE1 Jumper Type: 8-pin header Jumper Settings: See Table 4-5 Jumper Location: See Figure 4-8 Selects the resolution of the LCD panel connected to the LVDS1 connector.

  • Page 64: Lvds2 Resolution Selection

    WAFER-PV-D5253/D4253/N4553 SBC 4.5.5 LVDS2 Resolution Selection Jumper Label: Jumper Type: 6-pin header Jumper Settings: See Table 4-5 Jumper Location: See Figure 4-8 Selects the resolution of the LCD panel connected to the LVDS2 connector. Description Short 1-2 800 x 600...

  • Page 65: Com2 Rs-232/422/485 Selection

    WAFER-PV-D5253/D4253/N4553 SBC NOTE: To use SATA and CF, CF must be set as slave Sets the CompactFlash® slot as the IDE primary master or primary slave. Description Closed Master Open Slave (Default) Table 4-7: CompactFlash® Master/Slave Selection Figure 4-10: CompactFlash® Master/Slave Selection Jumper Location 4.5.7 COM2 RS-232/422/485 Selection...

  • Page 66: Com4 Pin 9 Setting Jumper

    WAFER-PV-D5253/D4253/N4553 SBC Figure 4-11: COM2 RS-232/422/485 Selection Jumper Location 4.5.8 COM4 Pin 9 Setting Jumper Jumper Label: Jumper Type: 5-pin header Jumper Settings: See Table 4-9 Jumper Location: See Figure 4-12 The COM4 Pin 9 Setting jumper configures pin 9 on COM4 as either a +5 V, +12 V power source or as a ring-in (RI) line.

  • Page 67: Chassis Installation

    The chassis should have fans and vents as necessary to keep things cool. The WAFER-PV-D5253/D4253/N4553 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 68: Audio Kit Installation

    AT power supply. See Figure 4-15. 4.7.2 Audio Kit Installation The Audio Kit that came with the WAFER-PV-D5253/D4253/N4553 connects to the audio connector on the WAFER-PV-D5253/D4253/N4553. The audio kit consists of three audio jacks. Mic-in connects to a microphone. Line-in provides a stereo line-level input to connect to the output of an audio device.

  • Page 69: Figure 4-14: Audio Kit Cable Connection

    WAFER-PV-D5253/D4253/N4553 SBC Step 1: Locate the audio connector. The location of the 10-pin audio connector is shown in Chapter 3. Step 2: Align pin 1. Align pin 1 on the on-board connector with pin 1 on the audio kit connector. Pin 1 on the audio kit connector is indicated with a white dot. See Figure 4-14.

  • Page 70: Keyboard/Mouse Connector

    The WAFER-PV-D5253/D4253/N4553 is shipped with a keyboard/mouse Y-cable connector. The keyboard/mouse Y-cable connector connects to a keyboard/mouse connector on the WAFER-PV-D5253/D4253/N4553 and branches into two cables that are each connected to a PS/2 connector, one for a mouse and one for a keyboard. Please follow the steps below to connect the keyboard/mouse Y-cable connector.

  • Page 71: Figure 4-16: Keyboard/Mouse Y-Cable Connection

    Step 3: Insert the cable connectors. Once the cable connector is properly aligned with the keyboard/mouse connector on the WAFER-PV-D5253/D4253/N4553, connect the cable connector to the on-board connectors. See Figure 4-16. Figure 4-16: Keyboard/mouse Y-cable Connection Step 4: Attach PS/2 connectors to the chassis. The keyboard/mouse Y-cable connector is connected to two PS/2 connectors.

  • Page 72: External Peripheral Interface Connection

    Locate the RJ-45 connectors. The locations of the USB connectors are shown in Chapter 4. Step 7: Align the connectors. Align the RJ-45 connector on the LAN cable with one of the RJ-45 connectors on the WAFER-PV-D5253/D4253/N4553. See Figure 4-17. Figure 4-17: LAN Connection Step 8: Insert the LAN cable RJ-45 connector.

  • Page 73: Serial Device Connection

    WAFER-PV-D5253/D4253/N4553 SBC 4.8.2 Serial Device Connection The WAFER-PV-D5253/D4253/N4553 has a single female DB-9 connector on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the WAFER-PV-D5253/D4253/N4553. Step 1: Locate the DB-9 connector. The location of the DB-9 connector is shown in Chapter 3.

  • Page 74: Vga Monitor Connection

    4.8.4 VGA Monitor Connection The WAFER-PV-D5253/D4253/N4553 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the WAFER-PV-D5253/D4253/N4553, please follow the instructions below. Step 1: Locate the female DB-15 connector.

  • Page 75: Software Installation

    Step 0: 4.9 Software Installation All the drivers for the WAFER-PV-D5253/D4253/N4553 are on the CD that came with the system. To install the drivers, please follow the steps below. Step 1: Insert the CD into a CD drive connected to the system.

  • Page 76: Figure 4-21: Introduction Screen

    WAFER-PV-D5253/D4253/N4553 SBC NOTE: If the installation program doesn't start automatically: Click "Start->My Computer->CD Drive->autorun.exe" Step 2: The driver main menu appears (Figure 4-21). Figure 4-21: Introduction Screen Step 3: Click WAFER-PV-D5253/D4253/N4553. Step 4: A new screen with a list of available drivers appears (Figure 4-22).

  • Page 77: Figure 4-22: Available Drivers

    WAFER-PV-D5253/D4253/N4553 SBC Figure 4-22: Available Drivers Step 5: Install all of the necessary drivers in this menu. S t e p 0 : Page 63...

  • Page 78: Bios

    WAFER-PV-D5253/D4253/N4553 SBC Chapter BIOS Page 64...

  • Page 79: Introduction

    WAFER-PV-D5253/D4253/N4553 SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The UEFI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 80: Getting Help

    WAFER-PV-D5253/D4253/N4553 SBC Function Main Menu – Quit and do not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu General help, only for Status Page Setup Menu and Option...

  • Page 81: Main

    WAFER-PV-D5253/D4253/N4553 SBC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.

  • Page 82: Advanced

    WAFER-PV-D5253/D4253/N4553 SBC  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus:...

  • Page 83: Bios Menu 3: Acpi Configuration

    WAFER-PV-D5253/D4253/N4553 SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced ACPI Sleep State [S1 (CPU Stop Clock)] Select the highest ACPI sleep state the system will enter, when the SUSPEND button is pressed. ---------------------- : Select Screen ...

  • Page 84: Cpu Configuration

    WAFER-PV-D5253/D4253/N4553 SBC 5.3.2 CPU Configuration Use the CPU Configuration menu (BIOS Menu 4) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced CPU Configuration Processor Type Intel(R) Atom(TM) CPU N475 @1.83GHz...

  • Page 85: Ide Configuration

    WAFER-PV-D5253/D4253/N4553 SBC 5.3.3 IDE Configuration Use the IDE Configuration menu (BIOS Menu 5) to change and/or set the configuration of the IDE devices installed in the system. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced PATA Master...

  • Page 86: Usb Configuration

    WAFER-PV-D5253/D4253/N4553 SBC  Configure SATA as [IDE] Use the Configure SATA as option to configure SATA devices as normal IDE devices.  Configures SATA devices as normal IDE device. EFAULT  AHCI Configures SATA devices as normal AHCI device. 5.3.4 USB Configuration Use the USB Configuration menu (BIOS Menu 6) to read USB configuration information and configure the USB settings.

  • Page 87: Super Io Configuration

    WAFER-PV-D5253/D4253/N4553 SBC does not become available until a USB compatible operating system is fully booted with all USB drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard can control the system even when there is no USB driver loaded onto the system.

  • Page 88: Serial Port N Configuration

    WAFER-PV-D5253/D4253/N4553 SBC 5.3.5.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 8) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Serial Port n Configuration Enable or Disable Serial...
  • Page 89 WAFER-PV-D5253/D4253/N4553 SBC  IO=3F8h; Serial Port I/O port address is 3E8h and the interrupt IRQ=3, 4 address is IRQ3, 4  IO=2F8h; Serial Port I/O port address is 2F8h and the interrupt IRQ=3, 4 address is IRQ3, 4 5.3.5.1.2 Serial Port 2 Configuration ...
  • Page 90 WAFER-PV-D5253/D4253/N4553 SBC  Enabled Enable the serial port EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.  Auto The serial port IO port address and interrupt address EFAULT are automatically detected.

  • Page 91: H/W Monitor

    WAFER-PV-D5253/D4253/N4553 SBC  IO=3E8h; Serial Port I/O port address is 3E8h and the interrupt IRQ=10, 11 address is IRQ10, 11  IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt IRQ=10, 11 address is IRQ10, 11 5.3.6 H/W Monitor The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds and system voltages.
  • Page 92 WAFER-PV-D5253/D4253/N4553 SBC  System Temperatures: CPU Temperature System Temperature  Fan Speeds: CPU Fan Speed System Fan Speed  Voltages: VCC3V V_core V1_05V VCC3V VSB3V VBAT  CPU Smart Fan control [Auto Mode] Use the CPU Smart Fan control option to configure the CPU fan.

  • Page 93: Serial Port Console Redirection

    WAFER-PV-D5253/D4253/N4553 SBC  Auto Mode The fan adjusts its speed using these settings: Temperature Bound 1 Temperature Bound 2 Temperature Bound 3 Temperature Bound 4  Manual Mode The fan spins at the speed set in: Manual Duty Cycle Setting 5.3.7 Serial Port Console Redirection...

  • Page 94: Chipset

    WAFER-PV-D5253/D4253/N4553 SBC  Disabled Disabled the console redirection function EFAULT  Enabled Enabled the console redirection function 5.4 Chipset Use the Chipset menu (BIOS Menu 11) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 95: Host Bridge

    WAFER-PV-D5253/D4253/N4553 SBC 5.4.1 Host Bridge Use the Host Bridge menu (BIOS Menu 12) to configure the host bridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset ******* Memory Information ******** Memory Frequency 667 Mhz --------------------- : Select Screen...

  • Page 96: Intel Igd Swsci Opregion

    WAFER-PV-D5253/D4253/N4553 SBC  HD Audio Controller [Enabled] The HD Audio Controller option enables or disables the HD audio controller.  Enabled onboard HD audio controller automatically EFAULT detected and enabled  Disabled The onboard HD audio controller is disabled ...

  • Page 97: Bios Menu 14: Intel Igd Swsci Opregion

    WAFER-PV-D5253/D4253/N4553 SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Intel IGD SWSCI OpRegion Configuration Select DVMT/FIXED Mode DVMT Mode Select [DVMT Mode] DVMT/Fixed Memory [Maximum] --------------------- : Select Screen IGD - Boot Type [VBIOS Default]  : Select Item...

  • Page 98: Boot

    WAFER-PV-D5253/D4253/N4553 SBC  VBIOS Default EFAULT    CRT + LFP  LCD Panel Type [VBIOS Default] Use the LCD Panel Type option to select the type of flat panel connected to the system. Configuration options are listed below.
  • Page 99 WAFER-PV-D5253/D4253/N4553 SBC  Bootup NumLock State [On] Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.  Allows the Number Lock on the keyboard to be EFAULT enabled automatically when the computer system boots up.

  • Page 100: Security

    WAFER-PV-D5253/D4253/N4553 SBC 5.6 Security Use the Security menu (BIOS Menu 16) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set,...

  • Page 101: Bios Menu 17: Exit

    WAFER-PV-D5253/D4253/N4553 SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Reset Exit system setup after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults...

  • Page 102: Abios Options

    WAFER-PV-D5253/D4253/N4553 SBC Appendix BIOS Options Page 88...
  • Page 103 WAFER-PV-D5253/D4253/N4553 SBC Below is a list of BIOS configuration options in the BIOS chapter. BIOS Information ......................67 System Date [xx/xx/xx] ....................67 System Time [xx:xx:xx] ....................68 ACPI Sleep State [S1 (CPU Stop Clock)]................ 69 ATA/IDE Configurations [Enhanced]................71 Configure SATA as [IDE] ....................
  • Page 104 WAFER-PV-D5253/D4253/N4553 SBC Save Changes and Reset....................87 Discard Changes and Reset ................... 87 Restore Defaults ......................87 Save as User Defaults..................... 87 Restore User Defaults..................... 87 Page 90...

  • Page 105: B One Key Recovery

    WAFER-PV-D5253/D4253/N4553 SBC Appendix One Key Recovery Page 91...

  • Page 106: One Key Recovery Introduction

    WAFER-PV-D5253/D4253/N4553 SBC B.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. The one key recovery provides quick and easy shortcuts for creating a backup and reverting to that backup or for reverting to the factory default settings.

  • Page 107: System Requirement

    WAFER-PV-D5253/D4253/N4553 SBC B.1.1 System Requirement NOTE: The recovery CD can only be used with IEI products. The software will fail to run and a warning message will appear when used on non-IEI hardware. To create the system backup, the main storage device must be split into two partitions (three partitions for Linux).

  • Page 108: Supported Operating System

    WAFER-PV-D5253/D4253/N4553 SBC NOTE: Specialized tools are required to change the partition size if the operating system is already installed. B.1.2 Supported Operating System The recovery CD is compatible with both Microsoft Windows and Linux operating system (OS). The supported OS versions are listed below.

  • Page 109: Setup Procedure For Windows

    WAFER-PV-D5253/D4253/N4553 SBC NOTE: Installing unsupported OS versions may cause the recovery tool to fail. B.2 Setup Procedure for Windows Prior to using the recovery tool to backup or restore Windows system, a few setup procedures are required. Step 1: Hardware and BIOS setup (see Section B.2.1)

  • Page 110: Create Partitions

    WAFER-PV-D5253/D4253/N4553 SBC Step 4: Turn on the system. Step 5: Press the <DELETE> key as soon as the system is turned on to enter the BIOS. boot device. (Boot  Boot Step 6: Select the connected optical disk drive as the 1 Device Priority ...

  • Page 111: Figure B-3: Recovery Tool Setup Menu

    WAFER-PV-D5253/D4253/N4553 SBC Step 3: The recovery tool setup menu is shown as below. Figure B-3: Recovery Tool Setup Menu Step 4: Press <5> then <Enter>. Figure B-4: Command Mode Step 5: The command prompt window appears. Type the following commands (marked in red) to create two partitions.

  • Page 112: Figure B-5: Partition Creation Commands

    WAFER-PV-D5253/D4253/N4553 SBC system32>format F: /fs:ntfs /q /v:Recovery /y system32>exit Figure B-5: Partition Creation Commands Page 98...

  • Page 113: Install Operating System, Drivers And Applications

    WAFER-PV-D5253/D4253/N4553 SBC NOTE: Use the following commands to check if the partitions were created successfully. Step 6: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build-up Recovery Partition.S t e p 0 : B.2.3 Install Operating System, Drivers and Applications...

  • Page 114: Build-Up Recovery Partition

    WAFER-PV-D5253/D4253/N4553 SBC B.2.4 Build-up Recovery Partition Step 1: Put the recover CD in the optical drive. Step 2: Start the system. Step 3: Boot the system from recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be...

  • Page 115: Figure B-8: Build-Up Recovery Partition

    WAFER-PV-D5253/D4253/N4553 SBC recovery files in Section B.2.2 is hidden and the recovery tool is saved in this 775H775H partition. Figure B-8: Build-up Recovery Partition Step 6: After completing the system configuration, press any key in the following window to reboot the system.

  • Page 116: Create Factory Default Image

    WAFER-PV-D5253/D4253/N4553 SBC B.2.5 Create Factory Default Image NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below. Step 1: Turn on the system.

  • Page 117: Figure B-12: About Symantec Ghost Window

    WAFER-PV-D5253/D4253/N4553 SBC Figure B-12: About Symantec Ghost Window Step 4: Use mouse to navigate to the option shown below ( Figure B-13). 778H778H Figure B-13: Symantec Ghost Path Step 5: Select the local source drive (Drive 1) as shown in Figure B-14.

  • Page 118: Figure B-14: Select A Local Source Drive

    WAFER-PV-D5253/D4253/N4553 SBC Figure B-14: Select a Local Source Drive Step 6: Select a source partition (Part 1) from basic drive as shown in Figure B-15. 780H780H Then click OK. Figure B-15: Select a Source Partition from Basic Drive Step 7: Select 1.2: [Recovery] NTFS drive and enter a file name called...

  • Page 119: Figure B-16: File Name To Copy Image To

    WAFER-PV-D5253/D4253/N4553 SBC Figure B-16: File Name to Copy Image to Step 8: When the Compress Image screen in Figure B-17 prompts, click High to make 782H782H the image file smaller. Figure B-17: Compress Image Page 105...

  • Page 120: Figure B-18: Image Creation Confirmation

    WAFER-PV-D5253/D4253/N4553 SBC Step 9: The Proceed with partition image creation window appears, click Yes to continue. Figure B-18: Image Creation Confirmation Step 10: The Symantec Ghost starts to create the factory default image ( Figure B-19). 783H783H Figure B-19: Image Creation Process...

  • Page 121: Setup Procedure For Linux

    WAFER-PV-D5253/D4253/N4553 SBC Step 12: The recovery tool main menu window is shown as below. Press any key to reboot the system. S t e p 0 : Figure B-21: Press Any Key to Continue B.3 Setup Procedure for Linux The initial setup procedures for Linux system are mostly the same with the procedure for Microsoft Windows.

  • Page 122: Figure B-22: Partitions For Linux

    WAFER-PV-D5253/D4253/N4553 SBC NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure B-22: Partitions for Linux Step 3: Create a recovery partition. Insert the recovery CD into the optical disk drive. Follow Step 1 Step 3 described in Section B.2.2.

  • Page 123: Figure B-23: System Configuration For Linux

    WAFER-PV-D5253/D4253/N4553 SBC Figure B-23: System Configuration for Linux Step 5: Access the recovery tool main menu by modifying the “menu.lst”. To first access the recovery tool main menu, the menu.lst must be modified. In Linux system, enter Administrator (root). When prompt appears, type: cd /boot/grub vi menu.lst...

  • Page 124: Recovery Tool Functions

    WAFER-PV-D5253/D4253/N4553 SBC Step 7: The recovery tool menu appears. ( Figure B-25) 788H788H Figure B-25: Recovery Tool Menu Step 8: Create a factory default image. Follow Step 2 Step 12 described in Section B.2.5 to create a factory default image.

  • Page 125: Figure B-26: Recovery Tool Main Menu

    WAFER-PV-D5253/D4253/N4553 SBC Figure B-26: Recovery Tool Main Menu The recovery tool has several functions including: 6. Factory Restore: Restore the factory default image (iei.GHO) created in Section B.2.5. 790H790H 7. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 126: Factory Restore

    WAFER-PV-D5253/D4253/N4553 SBC B.4.1 Factory Restore To restore the factory default image, please follow the steps below. Step 1: Type <1> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the factory default. A factory default image called iei.GHO is created in the hidden Recovery partition.

  • Page 127: Backup System

    WAFER-PV-D5253/D4253/N4553 SBC B.4.2 Backup System To backup the system, please follow the steps below. Step 1: Type <2> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to backup the system. A backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 128: Restore Your Last Backup

    WAFER-PV-D5253/D4253/N4553 SBC B.4.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Step 1: Type <3> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the last backup image (iei_user.GHO).

  • Page 129: Manual

    WAFER-PV-D5253/D4253/N4553 SBC B.4.4 Manual To restore the last system backup, please follow the steps below. Step 1: Type <4> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears. Use the Ghost program to backup or recover the system manually.

  • Page 130: Other Information

    WAFER-PV-D5253/D4253/N4553 SBC B.5 Other Information B.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key recovery.
  • Page 131 WAFER-PV-D5253/D4253/N4553 SBC Step 5: When the following window appears, press <S> to select “Specify Additional Device”. Step 6: In the following window, select a SATA controller mode used in the system. Then press <Enter>. The user can now start using the SATA HDD.

  • Page 132: System Memory Requirement

    WAFER-PV-D5253/D4253/N4553 SBC Step 7: After pressing <Enter>, the system will get into the recovery tool setup menu. Continue to follow the setup procedure from Step 4 in Section B.2.2 Create 794H794H Partitions to finish the whole setup process.S t e p 0 : B.5.2 System Memory Requirement...

  • Page 133: C Terminology

    WAFER-PV-D5253/D4253/N4553 SBC Appendix Terminology Page 119...
  • Page 134 WAFER-PV-D5253/D4253/N4553 SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 135 WAFER-PV-D5253/D4253/N4553 SBC Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module.
  • Page 136 WAFER-PV-D5253/D4253/N4553 SBC Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 137: D Hazardous Materials Disclosure

    WAFER-PV-D5253/D4253/N4553 SBC Appendix Hazardous Materials Disclosure Page 123...

  • Page 138: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    WAFER-PV-D5253/D4253/N4553 SBC D.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 139 WAFER-PV-D5253/D4253/N4553 SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies...
  • Page 140 WAFER-PV-D5253/D4253/N4553 SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

This manual is also suitable for:

Wafer-pv-d4253Wafer-pv-n4553

Table of Contents
