WAFER-BT
PIN NO. DESCRIPTION
1 Buzzer +

Table 3-6: Buzzer Connector Pinouts

3.2.5 CP U Fa n Co n n e c to r
CN La b e l: CP U_FAN1
CN Typ e : 4-pin wafer
CN Lo c a tio n : See Figure 3-6
See Table 3-7
CN P in o u ts :
The fan connector attaches to a cooling fan.

Figure 3-6: CPU Fan Connector Locations

PIN NO. DESCRIPTION
1 GND
3 FANIO1

Table 3-7: CPU Fan Connector Pinouts

3.2.6 DDR3L S O-DIMM S lo t
CN La b e l: DIMM1
CN Typ e :

DDR3L SO-DIMM slot

See Figure 3-7
CN Lo c a tio n :
The DDR3L SO-DIMM slot is for DDR3L SO-DIMM memory module.
PIN NO. DESCRIPTION
2 Buzzer -
PIN NO. DESCRIPTION
2 +12V
4 FANOUT1
P a g e 21
