3.5" SBC, Socket 479 with Intel® Pentium® M/ Celeron® M
processor with 400MHz FSB CPU, VGA/LVDS, PCIe GbE,
USB2.0, SATA and audio
Quick Installation Guide
Package Contents
WAFER-9102 package includes the following items:
1 x WAFER-9102 Single Board Computer
1 x Mini Jumper Pack
2 x SATA Cable
1 x KB/MS Cable
1 x Audio Cable
1 x Cooler (for WAFER-9102-R10, socket type only)
1 x Utility CD
1 x QIG (Quick Installation Guide)
WAFER-9102
Version 1.0
Oct. 01, 2008
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology WAFER-9102
Summary of Contents for IEI Technology WAFER-9102
-
Page 1: Quick Installation Guide
1 x Mini Jumper Pack 2 x SATA Cable 1 x KB/MS Cable 1 x Audio Cable 1 x Cooler (for WAFER-9102-R10, socket type only) 1 x Utility CD 1 x QIG (Quick Installation Guide) ©2006 Copyright by IEI Technology corp. -
Page 2: Specifications
Specifications CPU: Socket 479 Intel® Pentium® M/ Celeron® M processor with a 400 MHz FSB On board Intel® Celeron® M 1GHz zero cache or 1GHz 512KB cache processor System Chipset: Intel® 910GMLE + ICH-6M BIOS AMI Flash BIOS System Memory One x 200-pin DDRII SDRAM SO-DIMM 400 MHz (system max. -
Page 3: Reset
Humidity: Operating 5% ~ 95% non-condensing Dimension: 146mm x 102mm Weight: GW: 700g; NW: 230g Ordering Information WAFER-9102-R10 3.5” SBC, Socket479 Intel® Pentium® M/ Celeron® M CPU with VGA/LVDS, PCIe GbE, USB2.0, SATA and Audio WAFER-9102-1GZ-R10 3.5” SBC with ULV Intel® Celeron® M 1GHz zero cache CPU with VGA/LVDS, PCIe GbE, USB2.0, SATA and Audio... - Page 4 JP2 : configure COM2 Mode J_CMOS1 : Clear CMOS Setup DESCRIPTION J_CMOS1 DESCRIPTION Short 1-2 Short 1-2 Keep CMOS Setup RS - 232 (default)* (Normal Operation) (default) Short 3-4 RS - 422 Short 2-3 Clear CMOS Setup Short 5-6 RS - 485 J_VLVDS1 : LVDS Voltage Selection JCF1 : configure CF Card type J_VLVDS1...
- Page 5 Connectors LABEL FUNCTION KB_MS1 Keyboard and Mouse Connector CPU_FAN1 CPU Fan Connector LAN1 RJ45 LAN Connector FAN1 System Fan Connector PWRBTN1 Power Button ATXCTL1 ATX Power Control Connector RESET1 Reset Button Infrared Interface Connector ATXPWR1 Power Source Connector SATA1 Serial ATA Connectors SATA2 VGA1 VGA 10-pin Connector...
-
Page 6: Data
KB_MS1: 6-pin Mini-DIN CPU_FAN1 : CPU Fan Connector Keyboard/Mouse Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) +12V Mouse Data CPUFANIN Mouse Clock CPUFANOUT Keyboard Data Keyboard Clock LAN1 : RJ45 LAN Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDIA3- MDIA1+ MDIA3+... -
Page 7: Data
SATA1、SATA2 : Serial ATA Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VGA1 : 15-pin Female Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION GREEN BLUE CRT_PLUG# DDCDAT HSYNC VSYNC DDCCLK COM1 : Serial Port Connector PIN NO. DESCRIPTION DATA CARRIER DETECT (DCD#) RECEIVE DATA (RXD) - Page 8 IDE1 : IDE Interface Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 IDE DRQ...
- Page 9 COM2 : Internal Serial Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA CARRIER DETECT DATA SET READY (DCD#) (DSR#) RECEIVE DATA (RXD) REQUEST TO SEND (RTS#) TRANSMIT DATA (TXD) CLEAR TO SEND (CTS#) DATA TERMINAL READY RING INDICATOR (DTR#) (RI#) TXD485+ TXD485#...
- Page 10 INVERTER1 : 5-pin Header Inverter Connector PIN NO. DESCRIPTION LCD_BKLTCTL +12V BACKLIGHT ENABLE PC104_PLUS1: PC/104-Plus Connector (120-pin PCI bus) PIN Description PIN Description Description Description B1 RESERVED1 VIO1 CBE0- AD11 VIO2 AD10 M66EN AD14 AD13 AD12 CBE1- AD15 SERR- SBO- PERR- SDONE STOP-...
- Page 11 CF1 : CF Card Interface Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION CD1# CE2# VS1# IOR# IOW# CSEL# VS2# RESET# WAIT# INPACK# REG# BVD2 BVD1 IOCS16# CD2# GND2...
-
Page 12: Data-
USB01 & USB23 : Internal USB Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) DATA- DATA+ DATA+ DATA- VCC (+5V) USB_C45: External USB Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) VCC (+5V) DATA- DATA- DATA+ DATA+ AUDIO1: AC’97 Connector PIN NO. - Page 13 Board Layout: Jumper and Connector Locations LAN1...
