SBC86620 AMD Geode GX3 Mini ITX Board User's Manual
1.1

Specifications

CPU: AMD LX800(GX3) CPU ;LX700 is optional
System Chipset: CS5536AD
CPU Frequency: 500MHz/433MHZ(LX700)
BIOS:
Phoenix-Award BIOS, Y2K compliant
4Mbit Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display mode
option and application extension features
RPL/PXE Ethernet Boot ROM
"Load Optimized Default" to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
System Memory:
One 1*184-pin DDR DIMM
Maximum DDR of up to 1GB DDR333
Onboard IDE:
1* PATA-100 with 40-pin 2.54 pitch box-header
PATA-100 as PIO Mode 0-4, DMA Mode 0-2 and Ultra
DMA/33/66/100
Compact Flash Socket:
One Compact Flash Type II Socket
Onboard Multi I/O:
3 x RS-232
1 x RS-232/422/485
PCI slot expansion
USB Interface:
Real Time Clock:
Watchdog Timer:
1~255 seconds; up to 255 levels
Graphics/Streaming:
Integrate LX800
2
4 USB ports with fuse protection and
complies with USB Spec. Rev. 2.0
Integrate CS5536AD
Introduction
