Chapter 2
Installing Device
• Section 2.2, "Required Tools and Materials"
• Section 2.3, "Cabling Recommendations"
• Section 2.4, "Installing the Device in Hazardous Locations"
• Section 2.5, "Mounting the Device"
• Section 2.6, "Connecting the Failsafe Alarm Relay"
• Section 2.7, "Connecting Power"
• Section 2.8, "Connecting to the Device"
• Section 2.9, "Configuring the Device"
Section 2.1

General Procedure

The general procedure for installing the device is as follows:
1. Review the relevant certification information for any regulatory requirements. For more information, refer to
Section 6.1, "Approvals".
2. Mount the device.
3. Connect the failsafe alarm relay.
4. Connect power to the device and ground the device to safety Earth.
5. Connect the device to the network.
6. Configure the device.
Section 2.2

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RSG2100:
AC power cord (16 AWG)
CAT-5 Ethernet cables
Flathead screwdriver
Phillips screwdriver
4 x #8-32 screws
6
Tools/Materials
For connecting power to the device.
For connecting the device to the network.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For mounting the device to a panel.
RUGGEDCOM RSG2100
Installation Guide
