Removing and Replacing the SATA Hard Disk

NOTE:
1. Turn off the system power properly through the operating system, then turn off any external
devices.
2. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION:
3. Detach the rear cover.
WARNING!
This system does not support Parallel ATA (PATA) hard drives.
Before removing the original hard drive, be sure to back up its data so that you
can transfer the data to the replacement hard drive. Also, if you are replacing the
primary hard drive, make sure you have a recovery disc set to restore the
operating system, software drivers, and any software applications that were
preinstalled on the system.
Regardless of the power-on state, voltage is always present on the main board as
long as the system is plugged into an active AC outlet. You must disconnect the
power cord to avoid damage to the internal components of the system.
To avoid scratching the panel during the dismantling process, first place a piece
of cloth or cushion underneath.
16
