Loading Sheet Media - GRAPHTEC CE6000 SERIES Setup Manual

7
Release the lock from the media stopper (Pull the sides and slide it forward).
8
When the set lever is up (and the media is held down by the push rollers)
and the media stopper is unlocked, pull out the roll media and give it
slack.
Create the same amount of slack in the media as will be used for the
back of the machine.
Give it slack

Loading Sheet Media

1
Lower the media set lever to raise the push rollers.
Media sensor
Release
the media
stopper
Media stopper
Give it slack
Push roller
Media set lever
7
Supplement
Dirt from the floor may stick to the media when
giving it slack, so please be careful.
When using the roll media tray
Create the same amount of slack in the media
as will be used for the back of the machine.
Step 1: Raise the set lever
Step 2: Create slack.
Supplement
See "Aligning the Push Rollers" about the
position of the push rollers.
and fix the media.
