Web Page Item
Activate Relay While Call Active
Activate Relay on Button Press
Relay on Button Press Duration
Misc Settings
Device Name
Auto-Answer Incoming Calls
Button Lit When Idle
Button Brightness (0-255)
Play Ringback Tone
Enable Push to Talk
Enable DTMF Push to Talk
Prevent Call Termination
Disable HTTPS (NOT recommended)
Operations Guide
Table 2-7. Device Configuration Parameters (Continued)
931293D
Description
When selected, the relay will be activated as long as the
SIP call is active.
When selected, the relay will be activated when the Call
button is pressed.
The length of time (in seconds) during which the relay will
be activated when the Call button is pressed. Enter up to 5
digits. A Relay on Button Press Duration value of 0 will
pulse the relay once when the Call button is pressed.
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer
incoming calls. When Auto-Answer Incoming Calls is
disabled, the device will play a ring tone (corresponds to
Ring Tone on the Audiofiles page) out of the speaker until
someone presses the Call button to answer the call or the
caller disconnects before the call can be answered.
When selected, the Call button LED is illuminated while
the device is idle (a call is not in progress).
The desired Call button LED brightness level. Acceptable
values are 0-255, where 0 is the dimmest and 255 is the
brightest. Enter up to three digits.
When selected, the device will play a ringback tone
(corresponds to Ringback Tone on the Audiofiles page)
out of the speaker while placing an outbound call. The
Ringback Tone will play until the call is answered.
This option is for noisy environments. When enabled, the
microphone will be muted normally. When the Call button
is pressed and held, it will unmute the microphone and
allow the operator to send audio back. Using Push to Talk
prevents the operator from terminating a call by pressing
the Call button. The call must be terminated by the phone
user.
This option is for noisy environments. When enabled, in an
active call, the remote phone can force receive only audio
(setting the mic gain to max and muting the speaker) by
pressing the * key.
Pressing the # key will force send only audio (setting the
max speaker volume and muting the mic). Pressing the 0
key will restore full duplex operation with the normal
microphone and speaker volume.
When this option is enabled, a call cannot be terminated
using the call button.
Disables the encrypted connection to the webpage. We do
not recommend disabling HTTPS for security reasons.
Click on the Test Audio button to do an audio test. When
the Test Audio button is pressed, you will hear a voice
message for testing the device audio quality and volume.
