If the vehicle under test does not support the mode, an
advisory message will be displayed on the screen. (Figure
5.29)

For CAN-equipped vehicles, test selections can be as below:
6) Use the UP/DOWN scroll button to select the desired monitor
from On-Board Monitor Test menu and press the OK button.
On-Board Monitor Test
1. Test $01 Data
2. Test $03 Data
3. Test $10 Data
4. Test $21 Data
5. Test $22 Data
6. Test $25 Data
Figure 5.28
On-Board Monitor Test
The selected mode is
not supported
Press any key to continue
Figure 5.29
On-Board Monitor Test
1. EGR Monitor
2. Mis-Fire Monitor Data
3. Mis-Fire Cylinder 1 Data
4. Mis-Fire Cylinder 2 Data
5. Mis-Fire Cylinder 3 Data
6. Mis-Fire Cylinder 4 Data
Figure 5.30
41
..
