PCI-DAS4020/12 User's Guide
Functional Details
An example of each input impedance configuration option is shown in Figure 12.
Solder gap SG3
is open (1.5 Mohms)
Solder gap SG4
is closed (50 ohms)
Figure 12. Open and closed solder gaps
20
