PCI-DAS4020/12 User's Guide
2
40
40-pin Female
IDC Connector
If you don't need to connect to the PCI-DAS4020/12 analog outputs (pins 38 to 40), you can connect to a
BP40-37 cable. The BP40-37 cable brings pins 1 through 37 of the 40-pin connector out to 37-pin male "D"
connector mounted on a backplane bracket.
19
1
37-pin Male D Connector
with Backplate Assembly
The red stripe
1
identifies pin # 1
39
Figure 3. C40-37F-x cable
37
20
The red stripe and arrow
identify pin # 1
Figure 4. BP40-37 cable
13
Installing the PCI-DAS4020/12
1
20
37
19
37-pin Female
Dsub Connector
39 40
Key
1 2
40-pin Female
IDC Connector
