3.7 Seat shell

3.7.1 Putting on/securing

(1) In order to put on the seat shell
• Loop needs to be secured from rolling away,
• place the seat shell with the wedge on the
bottom onto the wedge holder (A),
• push it back until the locking pin (B) snaps
into place.
ATTENTION
The Loop is ready to use when the seat shell is
securely attached to the seat plate.
Check before each use: The seat shell should not
be able to be pushed out of it wedge holder.

3.7.2 Removing/unlocking

(1) In order to remove the seat shell
• Loop needs to be secured from rolling away,
• push the release lever (C) on the back down
so that the locking pin (B) unlocks,
• push the seat shell forward out of the wedge
holder.

3.7.3 shortening/extending the release lever

(2) In order to change the reachable length of the
release lever (A) loosen
• both screws (B) on the bottom,
• glide the release lever in the position wanted
• and tighten both screws back on.
(1)
(A)
(2)
(B)
User Manual
(B)
(C)
(A)
