1 Seat shell-base-frame overview
1
15
14
13
12
16
17
2019-08-16
2
3
4
5
6
18
26
25
Instructions for use Loop
1 Push bail, height adjustable
2 Eccentric clamp for angle adjustment
of the push bail
3 Gas pressure spring for angle adjustment
of the back
4 Star grip for height adjustment of
the push bail
5 Wheel cover
6 Wedge and intake
7 Brake lever
8 Caster adapter
9 Caster fork
10 Swivel caster
7
11 Footrest
12 Driving wheel
13 Handrim
8
14 Anti-tipper
9
15 Axle plate
10
11
16 Push bail, height adjustable
17 Tripping lever for (seating unit) tilt
mechanism
19
18 Operating lever for drum brake
19 Eccentric clamp for angle adjustment
of the push bail
20
20 Operating lever for angle adjustment
of the back
21 Gas pressure spring for angle adjustment
21
of the back
22
22 Wheel cover
23 Handrim
24 Brake pressing bolt of the wheel lock
23
25 Cross beams for extending the frame
26 Footrest (can be folded backwards)
24
SORG
5 of 44
