Instructions for use Loop
SORG
ENG
Loop
SORG
Instructions for use
2019-08-16
Instructions for use Loop
Unique people, unique solutions.
Unique people, unique solutions.
1 of 44
SORG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LoopSORG 802 and is the answer not in the manual?

Questions and answers

Related Manuals for SORG LoopSORG 802

Summary of Contents for SORG LoopSORG 802

  • Page 1 Instructions for use Loop SORG Loop SORG Instructions for use 2019-08-16 Instructions for use Loop Unique people, unique solutions. Unique people, unique solutions. 1 of 44 SORG...
  • Page 2 Imprint SORG Rollstuhltechnik GmbH + Co. KG Benzstrasse 3-5 68794 Oberhausen-Rheinhausen / Germany Phone +49 7254-9279-0 +49 7254-9279-10 E-Mail info@sorgrollstuhltechnik.de www.sorgrollstuhltechnik.de Revision status 2019-08-15 Technical status Technical changes and misprints reserved. The pictures in this instructions for use can differ from the actual equipment components.

  • Page 3: Table Of Contents

    3.8.1 General information regarding therapy table 3.9 Handling arm pad 3.9.1 General information regarding` arm 3.9.2 Arm pad mounted on the back 3.9.3 Arm pad mounted on the seat shell 35 2019-08-16 Instructions for use Loop 3 of 44 SORG...
  • Page 4 4 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 5: Seat Shell-Underframe Overview

    21 Gas pressure spring for angle adjustment of the back 22 Wheel cover 23 Handrim 24 Brake pressing bolt of the wheel lock 25 Cross beams for extending the frame 26 Footrest (can be folded backwards) 2019-08-16 Instructions for use Loop 5 of 44 SORG...

  • Page 6: General Information

    2 General information 2.1 Preface A warm welcome to the SORG family – many thanks for the trust you have placed in us and for choosing our product. This seat shell­underframe has been individually tailored to meet your specific requirements.

  • Page 7: Signs And Symbols

    Steps to be done on both sides 2019-08-16 Instructions for use Loop 7 of 44 SORG...

  • Page 8: Intended Purpose

    2.2.2 Intended purpose The Loop is a partially growable seat shell-underframe for children, young people and adults SORG intended for indoor and outdoor use. km/h The seat shell-underframe is designed solely for the transport of the person for whom it has been specially adapted by a qualified specialist dealer.

  • Page 9: Contraindication

    Seat shell adapter: loss or no attachment of the seat shell during transport possible • Seat shell back guide: loss or misalignment of the seat shell during transport possible • Push bail: loss or missing pushing option during transport 2019-08-16 Instructions for use Loop 9 of 44 SORG...
  • Page 10 The seat-shell underframe must always be carried by the frame only, never by the seat shell, the extendable push handle(s), push bail, handle bar, leg supports and/or the footrest(s)! 90° max 7° 10 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 11: Loading And Transport Without Occupants

    More information can be found in the crash test brochure at www.sorgrollstuhltechnik.de/ downloadportal. We can recommend the following manufacturers of restraint systems: • SORG restraining eyelets on wheelchairs • AMF-BRUNS GmbH & Co.KG • Q‘Straint Europe...
  • Page 12 ISO 7176-19. No transport with the seat shell-underframe facing sideways! Immediately contact your authorised dealer after a collision to check the carriage, frame and brakes and have any damage repaired by a specialist without delay. 12 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 13: Other Important Information

    > 42°C When configuring the seat shell­underframe, pelvic restraints (lap belts as positioning aids) can be optionally purchased via the SORG order sheets or by ordering from the replacement parts catalogues. Your specialist dealer will carry out the assembly. The product may interact with electromagnetic fields (e.g. shop anti­theft devices) in individual cases.
  • Page 14 Only approach obstacles slowly and overcome them with great care to ensure that little force is applied to the casters, driving wheel and seat shell-underframe as a whole. 14 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 15: Handling

    (2) After insertion, the locking ball (A) must be visibly protruding. Pull at least 1x after each insertion to test whether the quick-release axle is engaged. It should no longer be possi- ble to pull the wheels outwards. 2019-08-16 Instructions for use Loop 15 of 44 SORG...

  • Page 16: Double Hand Rim-Wheels

    3.1 Handling driving wheel 3.1.4 Double hand rim-wheels Insert: 90° (3a) (3b) Remove: Proceed accordingly in reverse order (2a) (2b) 16 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 17: Handling Swivel Caster

    Incorrectly adjusted swivel casters or excessive speed can cause the casters to flutter. Immediately slow down at the first sign of fluttering and have the swivel casters readjusted by a specialist dealer. 3.2.2 Caster track lock Unlock: 90° Lock: 90° 2019-08-16 Instructions for use Loop 17 of 44 SORG...

  • Page 18: Handling Seat And Back

    Only activate the (seating unit) tilt mechanism or angle adjustment when stationary with the brakes applied. 3.3.2 (Seating unit) tilt mechanism Tilting simple gas pressure spring: Tilting double gas pressure spring: 18 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 19: Back With Gas Pressure Spring

    3.3 Handling seat and back 3.3.3 Back with gas pressure spring Shift: 2019-08-16 Instructions for use Loop 19 of 44 SORG...
  • Page 20 3.3 Handling seat and back Folding down back with gas pressure spring: Folding open back with gas pressure spring: Proceed accordingly in reverse order: (1a) (1b) 20 of 44 Instructions for use Loop 2019-08-16 SORG...
  • Page 21 3.3 Handling seat and back Adjust angle for back with gas pressure spring: 2019-08-16 Instructions for use Loop 21 of 44 SORG...

  • Page 22: Seat Shell

    Ensure that the seat shell is firmly anchored to the seat plate and cannot be pushed forward. Remove: Connect back guide (remove: proceed accordingly in reverse order): Position shell back beforehand 22 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 23: Handling Pushing Aid

    It must not be possible to move the pushing aids in the intake with the eccentric clamp(s) in the closed position. Set the eccentric clamp: (2b) (2a) Increase clamping force Reduce clamping force (4a) (4b) 2019-08-16 Instructions for use Loop 23 of 44 SORG...

  • Page 24: Push Bail

    3.4 Handling pushing aid 3.4.2 Push bail Set height: 24 of 44 Instructions for use Loop 2019-08-16 SORG...
  • Page 25 3.4 Handling pushing aid Adjust angle: 2019-08-16 Instructions for use Loop 25 of 44 SORG...

  • Page 26: Handling Leg Support

    Leg support can be swung outwards and detached: Dynamic leg support: Leg rest can be detached, folded down and adjusted in width with continuous (5a) or di- vided footrest (5b) (5b) (5a) 26 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 27: Foldable Footrest With Locking Mechanism

    3.5.2 Foldable footrest with locking mechanism Lock (unlock: proceed accordingly in reverse order): 90° As the occupant, make sure that you do not lean too far out of the seat shell-underframe when handling the locking mechanism. 2019-08-16 Instructions for use Loop 27 of 44 SORG...

  • Page 28: Detachable And Swivelling Leg Support

    3.5 Handling leg support 3.5.3 Detachable and swivelling leg support Attach (detach: proceed accordingly in reverse order): 28 of 44 Instructions for use Loop 2019-08-16 SORG...
  • Page 29 3.5 Handling leg support Swivel out (swivel back: proceed accordingly in reverse order): Set lower leg length: 2019-08-16 Instructions for use Loop 29 of 44 SORG...
  • Page 30 3.5 Handling leg support Swivel up (swivel out: proceed accordingly in reverse order): 90° (4b) (4a) 90° Swivel out: Proceed accordingly in reverse order: (1a) (1b) 30 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 31: Handling Brake

    3.6.2 Wheel lock The knee lever and cable control brakes are wheel locks and are not suitable for slowing down when moving. Locking the wheel with the knee lever brake: (2a) (2b)) 2019-08-16 Instructions for use Loop 31 of 44 SORG...

  • Page 32: Drum Brake

    Lock: (2a) (2b) Release: 3.6.4 Reverse-roll locking Not suitable in combination with auxiliary drives. max 7°/ 12% Activate (deactivate: proceed accordingly in reverse order): 32 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 33: Handling Anti-Tipper

    Only rotate the anti-tipper 180° from deactivated position to active position. Avoid full revo- lutions in one direction, since otherwise the tension spring inside the anti-tipper will be dam- aged, which may result in the anti-tipper losing its functionality. 2019-08-16 Instructions for use Loop 33 of 44 SORG...

  • Page 34: Handling Therapy Table

    3.8 Handling therapy table 3.8.1 General information regarding therapy table Connection to the seat shell via the armrests. Set depth or remove (insert: proceed accordingly in reverse order): 34 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 35: Handling Arm Pad

    Connection directly to the back or over the seat shell. 3.9.2 Arm pad mounted on the back Swivel up (swivel out: proceed accordingly in reverse order): 3.9.3 Arm pad mounted on the seat shell Adjust angle: 2019-08-16 Instructions for use Loop 35 of 44 SORG...
  • Page 36 3.9 Handling arm pad Infinitely variable height adjustment: Set height with raster: 36 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 37: Handling Steering & Pushing Aid

    Pay attention to the max. load of the wheelchair, this also applies to the steering max. and pushing aid. km/h Mount (dismount: proceed in reverse order at Fig. 4): 90° (6a) (6b) 90° 2019-08-16 Instructions for use Loop 37 of 44 SORG...

  • Page 38: Repairs And Maintenance

    Pack detachable textile parts in foil or the like, if necessary • Secure the seat shell-underframe against rolling away and contamination • Storage in a dry place without aggressive environmental influences 38 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 39: Reinstatement

    (if present). Thoroughly clean and oil all moving parts. Please contact your dealer immediately if you notice any defects during maintenance. Stop using the seat shell-underframe. 2019-08-16 Instructions for use Loop 39 of 44 SORG...
  • Page 40 Locking mechanisms (springs of the push handles, quick-release axles, eccentric clamps, etc.) checked for functionality, Anti­tipper checked for secure fit and functionality. Oil: Moving parts and bearings oiled Final check: Functional check of all mechanical adjustment devices carried out 40 of 44 Instructions for use Loop 2019-08-16 SORG...

  • Page 41: Technical Data

    5 Technical data 5.1 Data and measurements Model: Loop SORG Type: 802 Measurements ± 5% Designation Dimensions Remarks Size 1 usable width = WW 300-420 mm suitable from ST 320 mm, per WW + 40 mm frame + 40 mm...

  • Page 42: Meaning Of Labels

    5.2 Meaning of labels The meaning of the individual labels can be directly derived from the text at the corresponding position. A new nameplate can be obtained from SORG Rollstuhltechnik if the original one is lost or damaged. Typeplate: Manufacturer logo...

  • Page 43: Verification Of Yearly Inspection

    Date/ Retailer's signature yearly inspection conducted according to Stamp: check list (year 4) comments: Date/ Retailer's signature yearly inspection conducted according to Stamp: check list (year 5) comments: Date/ Retailer's signature 2019-08-16 Instructions for use Loop 43 of 44 SORG...
  • Page 44 Instructions for use Loop SORG SORG Rollstuhltechnik GmbH + Co. KG Benzstrasse 3-5 68794 Oberhausen-Rheinhausen / Germany Germany Phone +49 7254 9279-0 Fax +49 7254 9279-10 info@sorgrollstuhltechnik.de company stamp www.sorgrollstuhltechnik.de...
