3.1.2 Drum brake wheels

(1) The drum brake wheels can also be removed with
a quick-release axle. To apply or remove, proceed as
described with the rear wheels.
ATTENTION
(2) The drum brake wheels' brake pads are
extremely sensitive and can lose their functionality
from dirt or scratches on the brake pads.
Remove lint and dirt from the brake pads regularly
with a soft brush.
(3) The drum brake wheels are operated by the carer
over the two levers on the push handles. To slow the
ride down squeeze both levers simultaneously (A).
(4) To secure the wheelchair, pull both levers (A) up
and latch the small lock levers (B) in the grooves (C).
The drum brakes are now blocked.
To unlock the blockage pull both brake levers (A) a
little bit higher to unlock the small lock levers (B).
(1)
(2)

3.2 casters

14
(3)
(4)
(C)
(A)
(A)
(B)
