PICO840/842 Pico-ITX Board
2.5

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN6
CN7
CN8
CN9
CN10
CN11
CN12
CN13
LAN1
SATA1
BAT1
SCN1
SSODIMM1
14
Description
VGA Connector
HDMI Connector
DC Power Jack w/ Screw
SMBus Connector
LVDS Connector
Power LED Header
SATA Power Connector
External Speaker and Internal Buzzer Header
Inverter Connector
Fan Power Connector
40-pin Board to Board Connector
20-pin Board to Board Connector
Ethernet Port
SATA Connector
CMOS Battery Connector
Full-size PCI-Express Mini Card and mSATA Connector
DDR3L SO-DIMM Connector
Board and Pin Assignments
