PICO840/842 Pico-ITX Board
The pin assignments of CN13 are given as follows.
Pin Signal
1 DCD2
3 RXD2
5 TXD2
7 DTR2
9 GND
11 DCD1
13 RXD1
15 TXD1
17 DTR1
19 GND
Note
2.5.12

Ethernet Port (LAN1)

The board has one RJ-45 Ethernet connector. Connection can be established by
plugging one end of the Ethernet cable into this RJ-45 connector and the other end
(phone jack) to a 1000/100/10-Base-T hub.
Pin Signal
L1 MDI0P
L2 MDI0N
L3 MDI1P
L4 MDI1N
A Active LED (Yellow)
100 LAN LED (Green) / 1000 LAN LED
B
(Orange)
2.5.13

SATA Connector (SATA1)

This Serial Advanced Technology Attachment (Serial ATA or SATA) connector is for
high-speed SATA interface port. It is a computer bus interface for connecting to devices
such as hard disk drives.
Pin
1
2
3
4
5
6
7
20
Pin Signal
2 DSR2
4 RTS2
6 CTS2
8 RI2
10 +5V
12 DSR1
14 RTS1
16 CTS1
18 RI1
20 +5V
It is suggested to insert AX93283 I/O board into CN12 and CN13 (see
chapter 3 for details of AX93283).
Pin Signal
L5 MDI2P
L6 MDI2N
L7 MDI3P
L8 MDI3N
Signal
GND
TXP
TXN
GND
RXN
RXP
GND
2
1
1
Board and Pin Assignments
20
19
