2.5.10

Fan Power Connector (CN11)

The CN11 is a 2.5mm pitch wafer connector which is compliant with JST B2B-ZH-K-S for
fan power interface.
Pin
1
2
2.5.11

Board to Board Connectors (CN12 and CN13)

The pin assignments of CN12 are given as follows.
Pin Signal
1 MIC
3 LINE_IN_L
5 LINE_IN_R
7 GND
9 GND
11 USB1_PWR
13 USB0_DATA-
15 USB0_DATA+
17 GND
19 GND
21 USB2_PWR
23 USB2_DATA-
25 USB2_DATA+
27 GND
29 GND
31 +5V
33 RESET
35 +5V
37 HDD_LED
39 GND
Board and Pin Assignments
Signal
+5V
GND
Pin Signal
2 LINE_OUT_L
4 LINE_OUT_R
6 GND
8 GND
10 GND
12 USB1_PWR
14 USB1_DATA-
16 USB1_DATA+
18 GND
20 GND
22 USB2_PWR
24 USB3_DATA-
26 USB3_DATA+
28 GND
30 GND
32 PS_ON
34 GND
36 +12V
38 +12V
40 Ni
PICO840/842 Pico-ITX Board
1 2
2
1
40
39
19
