Feature and option list

It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing
page at www.directechs.com. The web offers more options; however, manual configuration of the features is possible using the
information on this page.
* Default option
Feat. Operation
1 RFTD Output
Type
2 Unlock Driver
Priority
3 Heated Seats
4 Defroster
5 Heated
Seats/Defroster
Temperature
Control
6 Heated Seats
Temperature
Level
7 Smart OEM
Alarm Control
18
Flashes / Option Description
1. No RF Output* Module is connected to a remote starter using a standard installation.
Module is connected to an XL202 using an RSR or RXT installation (when
2. RFTD Output
available).
Module is connected to SmartStart using an RSR or RXT installation (when
3. SmartStart
available).
Unlocks only the driver door when the button is first pressed, and unlocks all
1. Driver priority*
doors when it is pressed a second time within 5 seconds.
2. All Unlocks all doors when the button is first pressed.
1. Disabled* No operation.
When the feature is enabled, it will activate the Heated Seats and heated
2. Enabled
steering wheel.
1. Disabled* No operation.
When the feature is enabled, it will activate the rear defroster and heated
2. Enabled
mirrors.
When Heated Seats or Defroster feature is enabled, it will activate the feature
1. 32 °F (0 °C)*
upon remote start when temperature is below 32 °F (0 °C).
When Heated Seats or Defroster feature is enabled, it will activate the feature
2. 23 °F (-5 °C)
upon remote start when temperature is below 23 °F (-5 °C).
When Heated Seats or Defroster feature is enabled, it will activate the feature
3. 41 °F (5 °C)
upon remote start when temperature is below 41 °F (5 °C).
When Heated Seats or Defroster feature is enabled, it will activate the feature at
4. Always ON
any temperature.
1. High* When Heated Seats are activated, they will be set to HIGH.
2. Low When Heated Seats are activated, they will be set to LOW.
The OEM alarm will not be controlled by the interface upon remote start. No
1. Disabled disarm or arm command will be executed at the beginning or end of the
sequence; it must be controlled by the Remote Starter.
Smart OEM Alarm Control will behave like a standard Safelock feature on a
2. Safelock remote starter. It will unlock at the beginning of the sequence, and relock after
start and shutdown.
Smart OEM Alarm Control will synchronize with the OEM alarm so that it will
disarm and rearm the vehicle in the remote start sequence, only when required.
3. Enabled* Smart OEM Alarm Control will monitor the alarm and door lock status to detect
if the disarm or rearm is required. If the vehicle is unlocked or is not equipped
with factory alarm, the disarm/rearm will not be executed.
403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
