Soft reset
A module reset will only erase the steps perfomed in "Module programming". The firmware and settings flashed to the module
will not be affected.
Connect the 10-pin & 12-pin harnesses to the module. Press and hold the
1
programming button, then connect the 14-pin harness to the module.
Wait 3 seconds until the LED turns ON solid orange then release the programming button.
2
The LED turns ON solid red.
15
3
rd
1
st
(Button)
(10-pin)
&
Solid
Release
403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
2
nd
4
th
(12-pin)
(14-pin)
&
Solid
