Summary of Contents for Directed Electronics Honda/Acura SIRIUS Interface HON-SC1
- Page 1 HON-SC1 Honda/Acura SIRIUS Interface Installation Guide...
-
Page 2: Fcc Notice
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this device. Directed Electronics is not responsible for any radio or TV interference caused by unauthorized modifica- tions to this equipment. Such modifications could void the User’s authority to operate the equipment. -
Page 3: Table Of Contents
2007 SIRIUS Satellite Radio Inc. All Rights Reserved “SIRIUS”, "SiriusConnect", the SIRIUS dog logo, channel names and logos are trademarks of SIRIUS Satellite Radio Inc. All Rights Reserved © Directed Electronics, all rights reserved. Desktop Docking Station Honda/Acura SIRIUS Interface... -
Page 4: Warning And Safety Information
Hold for 10sec to toggle channel or category tune modes. Channel control Preset 1-6. DISC- DISC+ Hold until beep to save to a preset. SOUND Headunit bus cable SiriusConnect Cable HON-SC1 Honda Bus Compatible Translator © Directed Electronics, all rights reserved. - Page 5 CATEGORY Category Control PLAY/PROG Toggles Scan mode SCAN AUDIO © Directed Electronics, all rights reserved. Bank and Tune mode Sirius-Ready, SAT Radio Ready or select OEM headunits with optional Honda Bus Compatible Translator Channel and text indicator Text selector. Hold for 10sec to toggle channel or category tune modes.
-
Page 6: Congratulations And Package Contents
Headunit bus cable HON-SC1 Honda Bus Compatible Translator Sirius-Ready, SAT Radio Ready or select OEM headunits with optional Honda B © Directed Electronics, all rights reserved. Text selector. Hold for 10sec to toggle channel or category tune modes. SiriusConnect Ca... -
Page 7: Compatibility And Features
HON-SC1 is not compatible with the factory satellite radio antenna that might be installed in the vehicle. For best operation you must install a SIRIUS compatible antenna as © Directed Electronics, all rights reserved. Desktop Docking Station Honda/Acura SIRIUS Interface supplied with the compatible SIRIUS Satellite Radio tuner. - Page 8 “XM2” as the display source. This information is hard coded in the headunit design and can not be changed. Dip Switch Settings Two dip switches located on the side panel are used to con- © Directed Electronics, all rights reserved.
- Page 9 "16 character".In order for text display configuration switch settings to take effect, you must disconnect power to the HON-SC1 module then reconnect and turn ignition on again. © Directed Electronics, all rights reserved. Desktop Docking Station Honda/Acura SIRIUS Interface...
-
Page 10: Installation
Installation Directed Electronics recommends that you have this prod- uct professionally installed. It is recommended that prior to starting the installation, you thoroughly read this manual and follow the guidelines listed below: Some installations may use the factory satellite radio tuner location. -
Page 11: Connections
DISC+ SCAN SOUND AUDIO Connects to rear of factory radio, may connect to bottom of radio in some vehicles Connects to factory XM/Satellite harness if applicable 11:53 © Directed Electronics, all rights reserved. CATEGORY XM1-1 CH-001 PLAY/PROG DISC- DISC+ SCAN... - Page 12 PLAY/PROG DISC- DISC+ SCAN SOUND AUDIO Connects to rear of factory radio, may connect to bottom of radio in some vehicles Connects to factory XM/Satellite harness if applicable SC-VDOC1 (Detail) To HON-SC1 SIRIUS Antenna © Directed Electronics, all rights reserved.
-
Page 13: Mounting Instructions
Desktop Docking Station Honda/Acura SIRIUS Interface Mounting Instructions Mounting HON-SC1 Bracket Assembly Mounting HON-SC1 with SIRIUS SCC1 Bracket Assembly © Directed Electronics, all rights reserved. -
Page 14: Activating Your Installed Sirius Tuner
Radio Service. You can use the directions provided with the radio for activation, or follow the directions above for activation while the radio is docked in the SiriusConnect Vehicle Dock attached to your factory audio system. © Directed Electronics, all rights reserved. -
Page 15: Operating The System
“No tuner” - displayed when connection to Sirius tuner or Sirius dock is bad, no tuner is connected or if vehicle ACC power is not cycled once after connecting the © Directed Electronics, all rights reserved. Desktop Docking Station Honda/Acura SIRIUS Interface interface. -
Page 16: Examples Of Factory Units
DISC+ SOUND SCAN AUDIO Channel and text Indicator fields Text selector. Hold for 10sec to toggle channel or category tune modes. Channel control Preset 1-6. Hold until beep to save to a preset. © Directed Electronics, all rights reserved. AUTO... - Page 17 Toggles between channel and category modes Toggles Scan mode Sat mode and bank selector © Directed Electronics, all rights reserved. Desktop Docking Station Honda/Acura SIRIUS Interface Bank and Channel and text present Indicator fields indicator XM1-1 001 - HITS1...
-
Page 18: Troubleshooting Guide
This interface module does not support clearing locked or skipped channels Note: When Channel Number is displayed, updates and error messages are hidden from view. The user must exit this mode by using the toggle text "DIsp/Mode" switch to view messages. © Directed Electronics, all rights reserved. -
Page 19: Warranty
Limited One Year Consumer Warranty Directed Electronics (herein “DIRECTED”) promises to the original purchaser, to replace this product should it prove to be defective in workmanship or material under normal use, for a period of one-year from the date of purchase from the dealer as indicated by the date code marking of the product. - Page 20 HON-SC1 2007-09 www.directedsirius.com © 2007 Directed Electronics, all rights reserved...
