Module programming
Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Connect the 10-pin, 12-pin and 14-pin harnesses to DB3, then wait until the LED turns
1
ON solid red.
2
Press 5 times on the programming button. The LED flashes orange.
Turnthe key to the ON position. The LED turns ON solid orange for 3 seconds, then
3
shuts OFF.
4
Turn the key to OFF and remove it from the ignition barrel.
You have successfully completed the module programming sequence.
12
403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
