- Page 1 TOY-SC1 Toyota/Lexus/Scion SIRIUS Interface Installation Guide...
-
Page 2: Fcc Notice
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this device. Directed Electronics is not responsible for any radio or TV interference caused by unauthorized modifica- tions to this equipment. Such modifications could void the User’s authority to operate the equipment. -
Page 3: Table Of Contents
Troubleshooting Guide Warranty Copyrights & Trademarks 2007 SIRIUS Satellite Radio Inc. All Rights Reserved “SIRIUS”, "SiriusConnect", the SIRIUS dog logo, channel names and logos are trademarks of SIRIUS Satellite Radio Inc. All Rights Reserved © Directed Electronics, all rights reserved. -
Page 4: Warning And Safety Information
DO NOT EXPOSE THE UNIT TO HIGH LEVELS OF HUMIDITY, MOISTURE OR DUST. Doing so can result in electric Hold until beep to PLAY/PROG DISC- DISC+ Toggles save to a preset. shock or product failure. Scan mode SOUND SCAN © Directed Electronics, all rights reserved . AUDIO... - Page 5 CATEGORY Category XM1-1 CH-001 Channel control Control Preset 1-6. Hold until beep to PLAY/PROG DISC- DISC+ Toggles save to a preset. Scan mode SOUND SCAN AUDIO © Directed Electronics, all rights reserved.
-
Page 6: Congratulations And Package Contents
Congratulations Congratulations on the Purchase of your new TOY-SC1 SiriusConnect Interface! Your TOY-SC1 is designed to be com- patible with select vehicles that support Satellite Radio operation (requires additional purchase of & connection to a SiriusConnect tuner or dock). Your interface is designed to replace the factory satellite tuner in your Toyota, Lexus or Scion vehicle. -
Page 7: Compatibility And Features
Land Cruiser 2005+ w/Navigation Toyota Prius 2005+ All Note that the TOY-SC1 is not compatible with the factory satellite radio antenna that might be installed in the ve- Toyota Rav-4 2007+ JBL hicle. For best operation you must install a SIRIUS compat-... - Page 8 2004+ All Note: Number of characters displayed varies by headunit Features type (8 ~16 Characters). The TOY-SC1 is designed to emulate many of the factory SDAR (Satellite Digital Audio Radio) commands found in Text Scrolling Configuration your vehicle. Text Scrolling and/or Paging can be enabled or disabled during installation of the HON-SC1.
- Page 9 Note: The default settings from the factory are scroll "Off" and "16 characters". In order for text display configuration switch settings to take effect, you must disconnect power to the TOY-SC1 module then reconnect and turn ignition on again. © Directed Electronics, all rights reserved.
-
Page 10: Installation
Do not install the TOY-SC1 under the carpet or in a small enclosed area without proper ventilation. Doing so can result in damage to the tuner or the vehicle. -
Page 11: Connections
SOUND SCAN 1 For cars equipped with XM, locate tuner, disconnect it Note: XM tuner must always be disconnected for proper and connect factory cable to the TOY-SC1 interface using operation. AUDIO the supplied cable, provided the connectors match. CAUTION: Some receptacles on other modules such as the... - Page 12 Connections: When connecting to a SiriusConnect Dock (SCVDOC1). Connects to factory XM/Satellite harness if applicable Connects to rear of factory radio Connects to factory XM/Satellite harness if applicable To TOY-SC1 SC-VDOC1 (Detail) SIRIUS Antenna © Directed Electronics, all rights reserved .
-
Page 13: Mounting Instructions
Toyota/Lexus/Scion SIRIUS Interface Desktop Docking Station Mounting Instructions Mounting TOY-SC1 Bracket Assembly Mounting TOY-SC1 with SIRIUS SCC1 Bracket Assembly © Directed Electronics, all rights reserved. -
Page 14: Activating Your Installed Sirius Tuner
You can also call SIRIUS toll-free at 1-888-539-SIRIUS (1-888-539-7474). Once activated, you will be able to begin enjoying SIRIUS Satellite Radio’s digital entertainment and can tune to other channels. © Directed Electronics, all rights reserved . -
Page 15: Operating The System
Upon connection the “docked portable” message Sirius dock is bad, no tuner is connected or if vehicle will replace the “No tuner” followed by “Acquiring Signal” before content becomes available. ACC power is not cycled once after connecting the © Directed Electronics, all rights reserved. -
Page 16: Examples Of Factory Units
Press until beep to save /Channel Bank indicator Preset number to a preset. number Channel control SAT1 PUSH Channel seek Category within category Control Toggles Toggles Scan mode between text fields. Sat mode, bank selector © Directed Electronics, all rights reserved . - Page 17 Bank indicator Preset number /Cha to a preset. Bank indicator, Channel indicator, Channel name Category name Toggles between text © Directed Electronics, all rights reserved. fields. PWR VOL TUNE FILE Channel control SAT1 StarLite ch002 Pop Title and Artist text...
-
Page 18: Troubleshooting Guide
This interface module does not support clearing locked or skipped channels Note: When Channel Number is displayed, updates and error messages are hidden from view. The user must exit this mode by using the toggle "Text" switch to view messages. © Directed Electronics, all rights reserved . -
Page 19: Warranty
Limited One Year Consumer Warranty Directed Electronics (herein “DIRECTED”) promises to the original purchaser, to replace this product should it prove to be defective in workmanship or material under normal use, for a period of one-year from the date of purchase from the dealer as indicated by the date code marking of the product. - Page 20 TOY-SC1 2007-09 www.directedsirius.com © 2007 Directed Electronics, all rights reserved...
