Feature and option list

It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing
page at www.directechs.com. The web offers more options; however, manual configuration of the features is possible using the
information on this page.
* Default option
Feat. Operation
1 RFTD Output
Type
2 Unlock Driver
Priority
3 Trunk
4 Aux1
5 Smart OEM
Alarm Control
19
Flashes / Option Description
1. No RF Output* Module is connected to a remote starter using a standard installation.
Module is connected to an XL202 using an RSR or RXT installation (when
2. RFTD Output
available).
Module is connected to SmartStart using an RSR or RXT installation (when
3. SmartStart
available).
Unlocks only the driver door when the button is first pressed, and unlocks all
1. Driver priority*
doors when it is pressed a second time within 5 seconds.
2. All Unlocks all doors when the button is first pressed.
1. Trunk* Will pop the trunk if available.
2. Tail Glass
Will open the tail glass if available.
Opening
1. Trunk Will pop the trunk if available.
The OEM alarm will not be controlled by the interface upon remote start. No
1. Disabled disarm or arm command will be executed at the beginning or end of the
sequence; it must be controlled by the Remote Starter.
Smart OEM Alarm Control will behave like a standard Safelock feature on a
2. Safelock remote starter. It will unlock at the beginning of the sequence, and relock after
start and shutdown.
403.TL1 5.02 2010 Toyota Camry (Smart Key)
