Directed Electronics DB3 Installation Manual page 9

Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Black/White
H3/2 Green/Black
H3/3 Green/White
H3/4 Red/Black
H3/5 Violet/White
H3/6 Gray
H3/7 Gray/Black
H3/8 Violet/Green
H3/9 Violet/Brown
H3/10 Yellow/Black
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
9
Description
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
No Connection
No Connection
(+/-) Wire Color Ref.
403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
