Directed Electronics DB3 Installation Manual page 14

Active Ground When Running (Status)
LED Description
Ground When Running (Status) command
received.
Flashes green
Ignition ON command received.
Flashes red &
orange
Start ON command received.
Flashes green
quickly
PTS shutdown error.
Flashes red x 10
CAN bus incorrectly detected.
Flashes red x 21
Commands
LED Description
LOCK command received.
Flashes orange x 1
UNLOCK command received.
Flashes orange x 2
TRUNK command received.
Flashes orange x 3
AUX1 command received.
Flashes orange x 4
AUX2 command received.
Flashes orange x 5
AUX3 command received.
Flashes orange x 6
Shutdown Codes
LED Description
Takeover successful.
Flashes green x 1
Runsafe was not disabled.
Flashes red x 1
Brake was not detected.
Flashes red x 2
Smart key was not detected.
Flashes red x 3
Speed was detected.
Flashes red x 4
RXT Error Codes
LED Description
Start command received.
Flashes green x 7
Stop command received.
Flashes green x 8
Start fail.
Flashes red x 5
Stop fail.
Flashes red x 6
RFTD disabled.
Flashes red x 7
OEM RS disabled.
Flashes red x 8
14
Troubleshooting
The module has initialized the remote start sequence.
The module has received the Ignition ON command and is processing the remote start sequence.
The module has received the Start ON command and is processing the remote start sequence.
The PTS output from the module was not activated due to safety protection.
Verify the CAN1 and CAN2 connections. Refer to "Installation (wiring diagrams & vehicle wiring
reference charts)" to check the connections.
Troubleshooting
If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Troubleshooting
Normal operation.
No UNLOCK command was received prior to opening the door, or the 45 second timer expired
in takeover mode.
The brakes were not detected, which prevents the system from shutting down the vehicle.
The smart key was not detected, which prevents the system from shutting down the vehicle.
The vehicle was detected as moving, which prevents the system from shutting it down.
Troubleshooting
If the module fails to flash, it did not receive the signal.
If the module fails to flash, it did not receive the signal.
The RXT start/stop message was received by the module, but not executed on the vehicle.
The RXT start/stop message was received by the module, but not executed on the vehicle.
OEM Remote Start Activation was attempted while the RFTD feature is disabled. Make sure RXT is
selected from the web in the flashing process.
The factory remote start option is disabled. Refer to the vehicle's owner manual to reactivate the
factory remote starter.
