Introduction

DB3 is an all-in-one door lock and override module. This guide supports the installation of a DB3 in Range
Extender Ready (RXT) mode with an RF System or a SmartStart (both sold separately).
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to "Connecting the module" for more information.
This solution is compatible with the 2016 Dodge/Ram 1500 and offers the following features:
• AV-Panic Mode Activation
• AV-Parking Lights Control
• DL-Arm Factory Security
• DL-Disarm Factory Security
• DL-Door Lock Control
• DL-Door Unlock
• DL-Driver Priority Unlock
• FOB-Control of aftermarket alarm with OEM remote
• Key2GO
• PK-Immobilizer Bypass-Data No Key Req'd
• RS-3x LOCK START (Start control using OEM Remote)
• RS-OEM Remote Start Activation using XL-202 or RF kit
• RS-RAP Shut Down (Retained ACC Power)
• RS-Remote Start Ready
• RS-SmartStart
• RS-Tach / RPM Output
• SS-Entry Monitoring ALL Door Pins
• SS-Entry Monitoring Hood Pin
• SS-Factory Alarm Trigger Monitoring
• ST-Brake Status (foot brake)
• ST-Door Locks Status
• ST-E-Brake Status
• ST-Ignition Status
4
403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
