MODEL: pljx
DL
doorlock
INTERFACE
MODEL: PLJX
GM PASSLOCK 1 & 2 & VATS & ION
SELF LEARNING DIGITAL
INTERFACE: JUMPER SELECTION
INSTALLATION GUIDE
PLJX is a "Self Learning" unit designed to bypass all GM vehicles equipped with Passlock I, Passlock II, VATS,
and the new style Passlock immobilizer found in the Saturn Ion & GM Colorado, Canyon, Cobalt, and Pursuit.
No measuring and matching of resistance values, PLJX automatically learns the resistor code value of any GM
and generates the value on demand when remote starting. One simple jumper allows you to easily select the
appropriate Passlock type. PLJX programs in one easy step.
Compatible with any remote car starter
-
Compatible with manufacturer's anti-theft & content theft security system
-
Maintains integrity of manufacturer's anti-theft immobilizer system
-
Maintains integrity of manufacturer's security and convenience functions
-
Compact design, easy to mount
-
No Key Required for operation (NKR)
-
Simple programming
-
All temperature operation
-
PRODUCT DESCRIPTION
PRODUCT FEATURES
† Buick, Cadillac, GM, Oldsmobile, Saturn, Hummer, Chevrolet, Isuzu and Pontiac are registered trademarks and property of their respective companies.
© 2011 Directed Electronics. All rights reserved.
Rev.: 20111017
Advertisement
Table of Contents
Related Manuals for Directed Electronics Xpresskit Solex PLJX
Summary of Contents for Directed Electronics Xpresskit Solex PLJX
- Page 1 Compact design, easy to mount No Key Required for operation (NKR) Simple programming All temperature operation † Buick, Cadillac, GM, Oldsmobile, Saturn, Hummer, Chevrolet, Isuzu and Pontiac are registered trademarks and property of their respective companies. © 2011 Directed Electronics. All rights reserved.
- Page 2 MODEL: pljx Rev.: 20111017 COMPATIBILITY: - EQUIPPED WITH PASSLOCK 1 - EQUIPPED WITH PASSLOCK 2 - EQUIPPED WITH VATS - EQUIPPED WITH ION PASSLOCK TYPE © 2011 Directed Electronics. All rights reserved.
- Page 3 MODEL: pljx Rev.: 20111017 ION, CANYON, COLORADO, COBALT, PURSUIT SYSTEM PRESET TO OVERRIDE THE FOLLOWING ION PASSLOCK TYPE use on: SATURN ION, CHEVY COLORADO, 2005 COBALT, GMC CANYON, 2005 PONTIAC PURSUIT Remote Control System © 2011 Directed Electronics. All rights reserved.
- Page 4 This will prevent the vehicle from starting for a period of 10 minutes. In this event, turn key to the “ON” position and let vehicle rest until the GM Security light stops flashing. © 2011 Directed Electronics. All rights reserved.
- Page 5 MODEL: pljx Rev.: 20111017 PASSLOCK 1 CONNECTION OVERRIDE THE FOLLOWING GM PASSLOCK TYPES: PASSLOCK 1 Remote Control System © 2011 Directed Electronics. All rights reserved.
- Page 6 MODEL: pljx Rev.: 20111017 PASSLOCK 2 & VATS CONNECTION OVERRIDE THE FOLLOWING GM PASSLOCK TYPES: PASSLOCK 2 & VATS Remote Control System © 2011 Directed Electronics. All rights reserved.
- Page 7 STARTER KILL “CLUTCH SWITCH” USE 1 RELAY SPDT TYPE (OPTIONNAL) (MANUAL CAR) Make connection closest to (OPTIONNAL) (MANUAL CAR) Make connection closest to firewall VIOLET VIOLET firewall “STARTER” WIRE STARTER “STARTER” WIRE STARTER © 2011 Directed Electronics. All rights reserved.
- Page 8 Rev.: 20111017 LIMITED ONE-YEAR CONSUMER WARRANTY For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed Electronics. (“DIRECTED”) promises to the original purchaser, to repair or replace with a comparable reconditioned piece, the security or remote start accessory piece (hereinafter the “Part”),...
