PureLink HE101-U Owner's Manual page 4

Hdmi 2.0 ultra hd/4k cable repeater
Table of Contents

Advertisement

Multi-channel Audio
HDR support
CEC support
EDID
Power
Dimension (WxDxH)
Weight
Connector Pin Assignment
Part No.
HDMI 19pin
PureLink by Dtrovision
HDMI (via HDMI pin# 18) or Micro USB DC +5V , 2A, Max 10W
* Micro USB is an optional, does not come with the unit
Pin No.
Description
1
TMDS DATA 2P
2
TMDS DATA 2 Shield
3
TMDS DATA 2M
4
TMDS DATA 1P
5
TMDS DATA 1 Shield
6
TMDS DATA 1M
7
TMDS DATA 0P
8
TMDS DATA 0 Shield
9
TMDS DATA 0M
10
TMDS Clock P
11
TMDS Clock Shield
12
TMDS Clock M
13
14
RESERVED
15
DDC Clock
16
DDC DATA
17
18
19
Hot Plug Detect
Yes, Pass thru
Yes, Pass thru
Yes, Pass thru
Pass thru
1.1" x 2.0" x 0.8" (28 x 52 x 21 mm)
0.50 lbs (0.2 kg)
CEC
GND
+5v
4
Remarks
