VLT AQUA Drive
Operating Instructions
6-10 Terminal 53 Low Voltage
Range:
0.07 V* [0.00 - par. 6-11 V]
6-11 Terminal 53 High Voltage
Range:
10.00 V* [par. 6-10 - 10.00 V]
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
50.000 N/ [-999999.999 - 999999.999 N/A]
A*
6-20 Terminal 54 Low Voltage
Range:
0.07 V* [0.00 - par. 6-21 V]
6-21 Terminal 54 High Voltage
Range:
10.00 V* [par. 6-20 - 10.00 V]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Terminal 53 Low Ref./Feedb. Value
feedback value set in par. 6-14
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 6-15
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current set in par.
6-10 Terminal 53 Low Voltage and par. 6-12 Terminal
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
par. 6-11 Terminal 53 High Voltage
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Terminal 54 Low Ref./Feedb. Value
feedback value, set in par. 6-24
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 6-25
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current value set in
Terminal 54 Low Voltage
par. 6-20
®
MG.20.M5.02 - VLT is a registered Danfoss trademark
8. How to programme the frequency converter
.
Terminal 53 High Ref./Feedb. Value
53 Low Current .
and par. 6-13 Terminal 53 High Current
.
Terminal 54 High Ref./Feedb. Value
54 Low Current
and par. 6-22 Terminal
