VLT AQUA Drive
Operating Instructions
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
[32] Pulse input
[34] Ramp bit 0
[36] Mains failure inverse
[52] Run Permissive
[53] Hand start
[54] Auto start
[55] DigiPot Increase
[56] DigiPot Decrease
[57] DigiPot Clear
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[66] Sleep Mode
[78] Reset Preventive Maintenance Word Resets all data in par. 16-96, Preventive Maintenance Word, to 0.
Freezes actual motor frequency (Hz). The frozen motor frequency is now the point of enable/con-
dition for Speed up and Speed down to be used. If Speed up/down is used, the speed change always
follows ramp 2 (par. 3-51 and 3-52) in the range 0 - par. 1-23
NB!
When Freeze output is active, the frequency converter cannot be stopped via a
low 'start [13]' signal. Stop the frequency converter via a terminal programmed
for Coasting inverse [2] or Coast and reset, inverse [3].
For digital control of the up/down speed is desired (motor potentiometer). Activate this function by
selecting either Freeze reference or Freeze output. When Speed up is activated for less than 400
msec. the resulting reference will be increased by 0.1 %. If Speed up is activated for more than 400
msec. the resulting reference will ramp according to Ramp 1in par. 3-41.
Same as Speed up [21].
Selects one of the four set-ups. Set par. 0-10
Same as Set-up select bit 0 [23].
(Default Digital input 32)
Select Pulse input when using a pulse sequence as either reference or feedback. Scaling is done in
par. group 5-5*.
Select which ramp to use. Logic "0" will select ramp 1 while logic "1" will select ramp 2.
Activates par. 14-10 Mains Failure . Mains failure inverse is active in the Logic "0" situation.
The input terminal, for which the Run permissive has been programmed must be logic "1" before a
start command can be accepted. Run permissive has a logic 'AND' function related to the terminal
which is programmed for START [8],
start running the motor, both conditions must be fulfilled. If Run Permissive is programmed on
multiple terminals, Run permissive needs only be logic '1' on one of the terminals for the function
to be carried out. The digital output signal for Run Request (
[20]) programmed in par. 5-3* Digital outputs, or par. 5-4* Relays, will not be affected by Run
Permissive.
A signal applied will put the frequency converter into Hand mode as if button
has been pressed and a normal stop command will be overridden. If disconnecting the signal, the
motor will stop. To make any other start commands valid, another digital input must be assign to
Auto Start and a signal applied to this. The
Off
The button on the LCP will override
On Hand Start
button to make and
Auto Start
, the motor will stop regardless of any normal Start command applied. If signal applied
Hand Start Auto Start
to both and , the function will be
LCP the motor will stop regardless of signals on
A signal applied will put the frequency converter into Auto mode as if the LCP button
Hand Start
been pressed. See also
Uses the input as an INCREASE signal to the Digital Potentiometer function described in parameter
group 3-9*
Uses the input as a DECREASE signal to the Digital Potentiometer function described in parameter
group 3-9*
Uses the input to CLEAR the Digital Potentiometer reference described in parameter group 3-9*
(Terminal 29 or 33 only) Input for increment counting in the SLC counter.
(Terminal 29 or 33 only) Input for decrement counting in the SLC counter.
Input for reset of counter A.
(Terminal 29 and 33 only) Input for increment counting in the SLC counter.
(Terminal 29 and 33 only) Input for decrement counting in the SLC counter.
Input for reset of counter B.
Forces frequency converter into Sleep Mode (see par. 22-4*, Sleep Mode). Reacts on the rising edge
of signal applied!
®
MG.20.M5.02 - VLT is a registered Danfoss trademark
8. How to programme the frequency converter
Motor Frequency
Active Set-up to Multi Set-up.
Jog [14] or Freeze Output [20], which means that in order to
Start
[8],
Hand On and Auto On buttons on the LCP has no impact.
Hand Start Auto Start
and . Press either the
Auto Start
active again. If no signal on neither
Auto Start
. If pressing the
Hand Start Auto Start
and
[53]
.
8
Jog Freeze output
[14] or
Hand On
on the LCP
Hand On Auto
or
Hand Start
nor
Off
button on the
.
Auto On
has
