8. How to programme the frequency converter
8.2.11. Timed Actions, 23-0*
Timed Actions
Use for actions needing to be performed on a daily or weekly basis, e.g. different references for working hours / non-working hours. Up
to 10 Timed Actions can be programmed in the frequency converter. The Timed Action number is selected from the list when entering parameter group
23-0* from the Local Control Panel. par. 23-00
divided into an ON time and an OFF time, in which two different actions may be performed.
NB!
The clock (parameter group 0-7*) must be correctly programmed for Timed Actions to function correctly.
NB!
When mounting an Analog I/O MCB109 option card, a battery back up of the date and time is included.
23-00 ON Time
Array [10]
Range:
0 N/A* [0 - 0 N/A]
8
23-01 ON Action
Arra [10]
Option:
[0] * Disabled
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
104
ON Time Occurrence
– par. 23-04 then refer to the selected Timed Action number. Each Timed Action is
Function:
Sets the ON time for the Timed Action.
NB!
The frequency converter has no back up of the clock function and the set date/
time will reset to default (2000-01-01 00:00) after a power down unless a Real
Time Clock module with back up is installed. In par. 0-79 Clock
to program for a Warning in case clock has not been set properly, e.g. after a
power down.
Function:
Select the action during ON Time. See par. 13-52 SL
®
MG.20.M5.02 - VLT is a registered Danfoss trademark
VLT
Operating Instructions
Fault
it is possible
Controller Action for descriptions of the options.
®
