Safety Information

Be sure to park the trailer on solid, level ground. Ensure all jack landing locations are cleared of debris and
obstructions and also free of depressions. People and pets should be clear of trailer while operating the leveling
system. Ensure the battery of the trailer is fully charged or that the trailer is plugged into shore power prior to
attempting to operate the system. Ground Control 3.0 requires a minimum of 12.75V DC from the battery for proper
operation.
Lippert Components Inc. recommends that a trained professional be employed to change the tires on the trailer.
Ensure that the trailer is properly supported with jack stands or other adequate devices under the frame of the
trailer prior to commencing any service or repair procedure. Any attempts to change the tires or perform other
service while trailer is supported solely by the Ground Control 3.0 jacks could

Touch Panel Diagram - Auto Leveling Control Touch Panel

B
C
Callout Description
A Red/Green LED - Indicates the status of the system.
B Up Arrow - Extends front jacks (landing gear).
C Down Arrow - Retracts front jacks (landing gear).
D Auto Level Button - Places leveling system into auto level mode.
E Hitch Height Button - Initiates the Hitch Recognition feature.
F Retract All Button - Places leveling system into full retract mode.
Rev: 03.02.2017
result in death, serious injury, trailer or property damage.
Fig. 1
A
D
To turn on the touch panel, press the Up
and Down arrow buttons at the same time.
Page 3
E
F
Ground Control 3.0 with OneControl
