USB-1208FS User's Guide

Screw terminal connector

Parameter
Connector type
Wire gauge range

Differential mode pinout

Pin
Signal Name
1
CH0 IN HI
2
CH0 IN LO
3
AGND
4
CH1 IN HI
5
CH1 IN LO
6
AGND
7
CH2 IN HI
8
CH2 IN LO
9
AGND
10
CH3 IN HI
11
CH3 IN LO
12
AGND
13
D/A OUT 0
14
D/A OUT 1
15
AGND
16
CAL
17
GND
18
TRIG_IN
19
SYNC
20
CTR
Table 21. Screw terminal specifications
Specification
Screw terminal
16 AWG to 30 AWG
Table 22. 4-channel differential mode pinout
Pin
Signal Name
21
Port A0
22
Port A1
23
Port A2
24
Port A3
25
Port A4
26
Port A5
27
Port A6
28
Port A7
29
GND
30
PC +5V
31
GND
32
Port B0
33
Port B1
34
Port B2
35
Port B3
36
Port B4
37
Port B5
38
Port B6
39
Port B7
40
GND
26
Specifications
