USB-1616FS User's Guide

Mechanical

Card dimensions
Enclosure dimensions

Screw terminal connector type

Connector type
Wire gauge range

Screw terminal pin out

Board label
DIO 0
1
2
3
4
5
6
7
TRIG IN
5V
CHANNEL IN 0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
203.2 mm (L) x 121.9 mm (W) x 20.0 mm (H)
8.0" (L) x 4.8" (W) x 0.8" (H)
208.3 mm (L) x 129.6 mm (W) x 40.6 mm (H)
8.2" (L) x 5.2" (W)x 1.6" (H)
Screw terminal
14 AWG to 30 AWG
Signal name Board label
DIO 0 GND
DIO 1
DIO 2
DIO 3
DIO 4
DIO 5
DIO 6
DIO 7
TRIG IN CTR
5V SYNC
CH 0 AGND
CH 1
CH 2
CH 3
CH 3
CH 4
CH 5
CH 6
CH 8
CH 9
CH 10
CH 11
CH 12
CH 13
CH 14
CH 15
4-7
Signal name
0 GND 0
1 GND 1
2 GND 2
3 GND 3
4 GND 4
5 GND 5
6 GND 6
7 GND 7
CTR
SYNC
0 AGND 0
1 AGND 1
2 AGND 2
3 AGND 3
4 AGND 4
5 AGND 5
6 AGND 6
7 AGND 7
8 AGND 8
9 AGND 9
10 AGND 10
11 AGND 11
12 AGND 12
13 AGND 13
14 AGND 14
15 AGND 15
Specifications
