Pin Signal name Pin description
1 P0D0 Port 0 bit 0
3 P0D2 Port 0 bit 2
5 GND Ground
7 P0D5 Port 0 bit 5
9 P0D7 Port 0 bit 7
11 GND Ground
13 P2D1 Port 2 bit 1
15 P2D3 Port 2 bit 3
Pin Signal name Pin description
1 P1D0 Port 1 bit 0
3 P1D2 Port 1 bit 2
5 GND Ground
7 P1D5 Port 1 bit 5
9 P1D7 Port 1 bit 7
11 GND Ground
13 P2D5 Port 2 bit 5
15 P2D7 Port 2 bit 7 / Counter

Screw terminal connector (not populated)

Parameter
Connector type
J1
Pin Signal name Pin description
5 P1D0
4 P1D1
3 P1D2
2 P1D3
1 GND
J2
Pin Signal name
5 P1D4
4 P1D5
3 P1D6
2 P1D7
1 +VO
J3
Pin Signal name
6 GND
5 P2D4
4 P2D5
3 P2D6
2 P2D7
1 GND
Table 13. W6 pinout
Table 14. W2 pinout
Table 15. Screw terminal connector specifications
Specification
3.51 mm screw terminal footprints (not populated), labeled J1, J2, J3, J7, J8, J9
Table 16. Screw terminal pinout
Port 1 bit 0
Port 1 bit 1
Port 1 bit 2
Port 1 bit 3
Ground
Pin description
Port 1 bit 4
Port 1 bit 5
Port 1 bit 6
Port 1 bit 7
User voltage output
Pin description
Digital ground
Port 2 bit 4
Port 2 bit 5
Port 2 bit 6
Port 2 bit 7 / Counter
Ground
Pin Signal name
2 P0D1
4 P0D3
6 P0D4
8 P0D6
10 GND
12 P2D0
14 P2D2
16 GND
Pin Signal name
2 P1D1
4 P1D3
6 P1D4
8 P1D6
10 +VO
12 P2D4
14 P2D6
16 GND
J7
Pin Signal name
1 P0D0
2 P0D1
3 P0D2
4 P0D3
5 GND
6 P0D4
J8
Pin Signal name
1 P0D5
2 P0D6
3 P0D7
4 GND
5 GND
J9
Pin Signal name
1 P2D0
2 P2D1
3 P2D2
4 P2D3
5 GND
19
Specifications
Pin description
Port 0 bit 1
Port 0 bit 3
Port 0 bit 4
Port 0 bit 6
Ground
Port 2 bit 0
Port 2 bit 2
Ground
Pin description
Port 1 bit 1
Port 1 bit 3
Port 1 bit 4
Port 1 bit 6
User voltage output
Port 2 bit 4
Port 2 bit 6
Ground
Pin description
Port 0 bit 0
Port 0 bit 1
Port 0 bit 2
Port 0 bit 3
Ground
Port 0 bit 4
Pin description
Port 0 bit 5
Port 0 bit 6
Port 0 bit 7
Ground
Ground
Pin description
Port 2 bit 0
Port 2 bit 1
Port 2 bit 2
Port 2 bit 3
Ground
