User's Guide

Screw terminal connector

Parameter
Connector type
Wire gauge range
Pin Signal Name
1 VOUT0
2 IOUT0
3 VOUT2
4 IOUT2
5 AGND
6 VOUT4
7 IOUT4
8 VOUT6
9 IOUT6
10 AGND
11 NC
12 NC
13 NC
14 NC
15 AGND
16 NC
17 NC
18 NC
19 NC
20 AGND
21 DIO0
22 DIO1
23 DIO2
24 DIO3
25 DIO4
26 DIO5
27 DIO6
28 DIO7
Table 16. Main connector specifications
Specification
Screw terminal
16 AWG to 30 AWG
Pin Signal Name
29 VOUT1
30 IOUT1
31 VOUT3
32 IOUT3
33 AGND
34 VOUT5
35 IOUT5
36 VOUT7
37 IOUT7
38 AGND
39 NC
40 NC
41 NC
42 NC
43 AGND
44 NC
45 NC
46 NC
47 NC
48 AGND
49 SYNCLD
50 DGND
51 ITEST
52 CTR
53 DGND
54 DIO CTL
55 DGND
56 +5V
20
Specifications
