USB-234 User's Guide

Environmental

Parameter
Operating temperature range
Storage temperature range
Operating humidity range
Storage humidity range
Pollution degree (IEC 60664)
Maximum altitude

Mechanical

Parameter
Dimensions (L × W × H)
Weight

Screw terminal connector

Parameter
Connector type
Wire gauge range
Torque for screw terminals
Table 12. Environmental specifications (Indoor use only)
Specification
0 °C to 45 C
–40 °C to 85 °C
5% to 95% RH, non-condensing
5% to 90% RH, non-condensing
2
2,000 m
Table 13. Mechanical specifications
Conditions
With screw terminal connector plugs
Without screw terminals
With screw terminal connector plugs
Without screw terminals
Table 14. Screw terminal connector specifications
Specification
16-position screw terminal plugs
16 AWG to 28 AWG (1.31 to 0.08 mm
0.22 - 0.25 N · m (2.0 - 2.2 lb. · in.)
Specification
93.2 × 86.2 × 23.6 mm
(3.67 ×3.40 × 0.93 in.)
75.4 × 86.2 × 23.6 mm
(2.97 ×3.40 × 0.93 in.)
105 g (3.70 oz)
83 g (2.93 oz)
2
)
26
Specifications
