Preset List.
The Headphone Preset List will be displayed; presets with a blue back-
ground are visible, and presets with a black background are hidden.
3. Turn and press the Headphone encoder to toggle visibility of each preset.

Defining Custom Headphone Presets

In addition to the six predefined headphone sources, 10 options are available as
custom headphone presets.
To customize a headphone preset:
1. Press the Headphone encoder to display the list of available sources.
2. Turn the encoder to choose one of the 10 customizable preset options, such
as HP Preset(1).
3. Slide the MIC/TONE switch left or right.
The Headphone Preset Editing screen appears.
Unassigned source
4. Do one of the following:
Turn the Headphone encoder to move the orange highlight horizontally.
X
Turn the Select encoder to move the orange highlight vertically.
X
5. Press the Headphone or Select encoder to change the selected source
between Off (black) and Assigned (blue).
6. (Optional) Do any of the following:
Slide the A B/C switch left to toggle MS decoding for this headphone
X
preset.
Slide the A B/C switch right to toggle mono summing for this head-
X
phone preset. (All active sources will be summed into both headphone
channels).
Slide the MIC/TONE switch left to name the headphone preset.
X
7. Press MENU or METERS to save the preset and exit the Headphone Preset
Editing screen.
Left HP
Assigned source
Highlight
HEADPHONE MONITORING
Right HP
