Setting EQ Routing

EQ may be applied either pre- or post-fade. This setting globally affects all in-
puts.
To set EQ routing:
1. Press MENU.
2. Select CL-12 > EQ > EQ Routing. Options include: Pre-fade or Post-fade.

Using High-pass Filters

The High-pass Filter (HPF) button on the CL-12 is a toggle, which turns the
high-pass filter off or on for the selected input.
On the 664, since inputs 1-6 are analog, the CL-12's HPF button toggles on or
off high-pass filtering for inputs 7-12 only at the fixed frequency of 150 Hz.
On the 688 and 633, the high-pass filter may be adjusted for all inputs to other
frequencies.
To turn on and adjust an input's high-pass filter:
1. Select an input, using the input's SEL button.
2. Press the HPF button.
If inputs 1-6 are selected on the 664 when the CL-12's HPF button is pressed, a
i
message will appear: "Use the low-cut control on the 664 front panel."
The HPF button illuminates when high-pass filtering is on.
3. (633 & 688 only) Adjust the HPF value via the Input Settings screen.
When high-pass filtering is on, the HPF value is fixed at 150 Hz on the 664,
but may be changed via in the Input Settings screen on the 633 or 688.
Also, on the 688, the EQ screen appears on the mixer's LCD. The Head-
phone encoder may be used as an alternative way to adjust the HPF value
displayed on the EQ screen.
Press the HPF button again to turn off the high-pass filter.
i

Naming Tracks

Since inputs are hard-wired to their respective tracks, the input name is the
same as the track name. Naming functionality only applies to one selected
input at a time. Attempting to do so with multiple inputs selected will result in a
message instructing the user to select a single input before continuing.
While recording, the current take's track name may be modified. Edits to
the track name in the current take will also be applied to the next take and
subsequent recordings that follow. The next take's track name may be edited so
long as recording is stopped.
