  • Page 1: Network Camera

    Network Camera Installation Manual UD.6L0201A1681A02...
  • Page 2 Installation Manual of Network Camera Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. There is variety of structures of network cameras in our company. Installing instructions of all these cameras are listed in this manual.

  • Page 3: Safety Instruction

    Installation Manual of Network Camera Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
  • Page 4 Installation Manual of Network Camera Cautions:  Make sure the power supply voltage is correct before using the camera.  Do not drop the camera or subject it to physical shock.  Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it gently.

  • Page 5: Table Of Contents

    Installation Manual of Network Camera Table of Contents Chapter 1 Introduction ..............................7 Applications ................................. 7 Preparations ................................7 Chapter 2 Box Camera Installation ........................... 9 Type I Box Camera .............................. 9 2.1.1 Camera Description ............................. 9 2.1.2 Installation ..............................11 Type II Box Camera ............................
  • Page 6 Installation Manual of Network Camera 3.9.3 Camera Description of Type B Dome Camera................... 89 3.9.4 Installation of Type B Dome Camera ......................89 3.10 Type X Dome Camera ............................93 3.10.1 Camera Description ........................... 93 3.10.2 Remote Control ............................95 3.10.3 Installation ..............................
  • Page 7 Installation Manual of Network Camera 4.11 Type XI Bullet Camera ............................ 158 4.11.1 Camera Description ..........................158 4.11.2 Installation ............................... 159 4.12 Type XII Bullet Camera ........................... 162 4.12.1 Camera Description ..........................162 4.12.2 Installations for Type I Bullet Camera ..................... 164 4.12.3 Installations for Type II Bullet Camera ....................

  • Page 8: Chapter 1 Introduction

    Installation Manual of Network Camera Chapter 1 Introduction The network camera is a kind of embedded digital surveillance product that combines the features of both traditional analog camera and the encoder. With a built-in video server, the network camera is capable of providing real-time video stream compression, processing, video analysis and transmission simultaneously.
  • Page 9 Installation Manual of Network Camera  Make sure that the wall is strong enough to withstand three times the weight of the camera. For the camera that supports IR, you are required to pay attention to the following precautions to prevent IR reflection: ...

  • Page 10: Chapter 2 Box Camera Installation

    Installation Manual of Network Camera Chapter 2 Box Camera Installation 2.1 Type I Box Camera 2.1.1 Camera Description The overview of Type I box camera is shown below: Figure 2-1 Overview Table 2-1 Description Description Lens Mount Back Focus Ring SD Card Slot Auto-iris Interface 10M/100M Self-adaptive Ethernet Interface...
  • Page 11 Installation Manual of Network Camera D+, D-: RS-485 Interface Description IN, G: Alarm Input Interface 1A, 1B: Alarm Output Interface Grounding RESET: Reset Button Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 12: Installation

    Installation Manual of Network Camera 2.1.2 Installation Steps: 1. Fix the mounting bracket to the ceiling. Expansion Screw Figure 2-3 Fix Camera Mounting Bracket 2. Aim the screw hole on the camera at the bracket and rotate the camera tightly. 3.

  • Page 13: Type Ii Box Camera

    Installation Manual of Network Camera 1). Connect the VIDEO OUT interface of the camera to the debugging monitor. 2). Adjust the lens focus to obtain a perfect image on the monitor. Figure 2-5 Install the Lens 2.2 Type II Box Camera 2.2.1 Camera Description The overview of Type II box camera is shown below: Figure 2-6 Overview (1)
  • Page 14 Installation Manual of Network Camera Figure 2-7 Overview (2) The interfaces on the rear panel are shown below: Figure 2-8 Overview (3) Table 2-3 Description Description Description Lens Mount ¼-20 UNC Screw Hole Status Indicator Auto-iris Interface LAN(PoE) Power Outlet Reset...
  • Page 15 Installation Manual of Network Camera Micro SD Card Slot Video Out Grounding Alarm Out RS-232 RS-485 Alarm In Audio Out Audio In Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. The type of auto-iris interface is shown as below figure: Figure 2-9 Auto-iris Interface Table 2-4 Pins...

  • Page 16: Installation

    Installation Manual of Network Camera 2.2.2 Installation  Ceiling Mounting Steps: 1. Install the ceiling mount to the ceiling with the supplied expansion screws. Adjustable Nut Figure 2-10 Install the Mount 2. Fit the lens (not supplied) to the camera and rotate it to get it tightened. ●...
  • Page 17 Installation Manual of Network Camera Figure 2-11 Install the Lens 4. Align the screw hole on the camera with the ceiling mount and rotate the camera to get it fixed. 5. Adjust the surveillance angle. 1). Loosen the pan nut to adjust the pan angle [0° -360° ]. 2).
  • Page 18 Installation Manual of Network Camera 2. Plug the auto-iris cable to the auto-iris interface. Figure 2-13 Install the Lens 3. Loosen the lock screw on the mount and remove the tilt adjust table from the wall mount. Tilt Adjust Table Lock Screw Figure 2-14 Remove the Tilt Adjust Table 4.
  • Page 19 Installation Manual of Network Camera 5. Secure the wall mount to the wall with the supplied expansion screws. Figure 2-16 Install the Wall Mount 6. Install the camera to the wall mount and tighten the two lock screws. 7. Adjust the surveillance angle. 1).
  • Page 20 Installation Manual of Network Camera ● Push the inserted SD card slightly to get it sprung by its built-in springing to remove it. SD Card Figure 2-18 Install the SD Card...

  • Page 21: Chapter 3 Dome Camera Installation

    Installation Manual of Network Camera Chapter 3 Dome Camera Installation 3.1 Type I Dome Camera 3.1.1 Camera Description Figure 3-1 Overview Table 3-1 Description Description 10M/100M self-adaptive Ethernet interface Reset Button AUDIO OUT: Audio output interface MIC IN: Audio input interface D+, D-: RS-485 interface 1A, 1B, 2A, 2B: Alarm output interface IN1, GND, IN2, GND: Alarm input interface...

  • Page 22: Installation

    Installation Manual of Network Camera including the user name, password, IP address, port No., etc. 3.1.2 Installation  Ceiling Mounting Steps: Optional) use a plier to remove one clip or both two clips (marked in dotted line in Figure 3-2) on the side of the back box and then route cables through the opening to secure the cables on the ceiling.
  • Page 23 Installation Manual of Network Camera 3. Fix the mounting base to the ceiling; rotate the back box counterclockwise to secure it to the mounting base; use the lock screw to secure the dome camera. Figure 3-4 Mounting 4. Loosen the set screws with the hex key (supplied) to remove the bubble. Figure 3-5 Disassembling 5.
  • Page 24 Installation Manual of Network Camera Figure 3-6 Image Adjusting Figure 3-7 Image Adjusting 7. Reinstall the bubble and tighten the screws Figure 3-8 Reinstall...
  • Page 25 Installation Manual of Network Camera  In-ceiling mounting Steps: 1. Secure the mounting base to the in-ceiling mounting base with screws. In-ceiling Mounting base Mounting Base Figure 3-9 Mounting Base 2. Push the dome camera to the in-ceiling mounting base, rotate the dome camera for 10 degrees counterclockwise and then fasten the lock screws to fix the camera.
  • Page 26 Installation Manual of Network Camera The thickness of the ceiling should be less than 30 mm. Figure 3-11 Installing 4. It is strongly recommended that you use a safety rope to secure the in-ceiling mounting base to the roof. Safety Rope Figure 3-12 Safety Rope 5.
  • Page 27 Installation Manual of Network Camera Lock Screw Figure 3-13 Fasten Screws 6. Remove the bubble and connect the RCA analog video output with a monitor to view the image of the camera. Loosen the lens set screw and pan, tilt or rotate the lens to get a desired surveillance angle.

  • Page 28: Type Ii Dome Camera

    Installation Manual of Network Camera Figure 3-15 Trim Plate Installing 3.2 Type II Dome Camera 3.2.1 Camera Description Figure 3-16 Overview Table 3-2 Physical Description Description Cover Lens Power LED indicator, It turns solid red when power is connected.

  • Page 29: Installation

    Installation Manual of Network Camera Description Base plate Set screw hole Set screw of lens S & L: Network status indicator. When the network is connected, the “S” LED is solid yellow, while the “L” LED flashes orange. RESET Button Press RESET button about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
  • Page 30 Installation Manual of Network Camera Figure 3-18 Remove the Cover 3. Fix the camera to the ceiling with the supplied screws. Figure 3-19 Fix the Camera 4. View the video image of the camera over the network. 5. Loosen the lens set screws.
  • Page 31 Installation Manual of Network Camera Figure 3-20 Loosen the Lens Set Screws 6. Insert the hex key into the hole marked in the picture and rotate the hex key to adjust the panning position and tilting position until getting the desired surveillance angle. Tighten the set screws. Figure 3-21 Adjust Panning Position...
  • Page 32 Installation Manual of Network Camera Figure 3-22 Adjust Tilting Position As the lens of camera has already been factory adjusted to the best imaging effect, you just need to adjust the panning position and tilting position to get the desired surveillance angle. 7.

  • Page 33: Type Iii Dome Camera

    Installation Manual of Network Camera 3.3 Type III Dome Camera 3.3.1 Camera Description Figure 3-24 Overview Table 3-3 Description Description Ceiling Mount Lock Button Mounting Base SD Card Slot Lens IR LED Bubble Status Indicator RCA Analog Video Output Debug...

  • Page 34: Installation

    Installation Manual of Network Camera Reset Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. 3.3.2 Installation Steps: 1. Drill the screw holes and the cable hole in the ceiling according to the supplied drill template. Figure 3-25 Drill Template 2.
  • Page 35 Installation Manual of Network Camera Ceiling Ceiling Mount Figure 3-26 Fix the Ceiling Mount 3. Route the cables through the cable hole on the ceiling. If required, you can rotate the side outlet on the mounting base to remove it and route the cables through the side outlet.
  • Page 36 Installation Manual of Network Camera Hole Screw Unlock Button Figure 3-28 Install the Dome Camera To uninstall the dome camera, press the lock button and rotate the mounting base counterclockwise. Figure 3-29 Uninstall the Dome Camera 6. Loosen the set screws with a hex key (supplied) to remove the bubble.
  • Page 37 Installation Manual of Network Camera Figure 3-30 Remove the Bubble 7. Connect the RCA analog video output with a monitor to view the image. 8. Loosen the set screw and adjust the panning position and tilting position until you get the desired surveillance angle.

  • Page 38: Type Iv Dome Camera

    Installation Manual of Network Camera Figure 3-32 Reinstallation 3.4 Type IV Dome Camera 3.4.1 Camera Description 2 3 4 Figure 3-33 Overview Table 3-4 Physical Description Description Video output interface...

  • Page 39: Installation

    Installation Manual of Network Camera LINK: Indicator is solid yellow when network is connected. ACT: Indicator flashes blue when network connection is functioning properly. PWR: Indicator is solid red when the device is powered on. Micro SD slot RESET: Reset the camera. 10M/100M self-adaptive Ethernet interface Power supply interface ...
  • Page 40 Installation Manual of Network Camera Figure 3-35 Mount Back Box 3. Loosen the set screws with the hex key (supplied) to remove the bubble; remove the black liner. Figure 3-36 Disassembling 4. Install the dome drive to the back box and pull the cables through the cable outlet on the bottom of the back box.
  • Page 41 Installation Manual of Network Camera Figure 3-37 Dome Drive Installing If you need to pull the cable through the side outlet of the camera, please remove the cover and use water-proof joints and water-proof pipe to route the cables. Outlet Figure 3-38 Side Cable Routing 5.
  • Page 42 Installation Manual of Network Camera Tilt Lock Screw Rotate Figure 3-39 Angle Adjusting 6. Reinstall the black liner and bubble to finish the installation. Figure 3-40 Reinstall  In-ceiling Mounting: Steps: 1. Drill the screw holes and the cable hole on the ceiling according to the supplied drill template.
  • Page 43 Installation Manual of Network Camera Drill Template Hole A: for the recessed part of the camera body Screw hole 1: for Toggle bolt Code:190600840 Figure 3-41 Drill Template 2. Loosen the set screws with the hex key (supplied) to remove the bubble; and remove the black liner.
  • Page 44 Installation Manual of Network Camera Toggle Bolt Figure 3-43 Dome Drive Installing 6. Fasten the toggle bolt and the toggle will automatically secure the dome drive to the ceiling. Ceiling Figure 3-44 Fasten Toggle Bolt 7. Connecting the network cable and power cable. 8.
  • Page 45 Installation Manual of Network Camera Tilt Lock Screw Rotate Figure 3-45 Angle Adjusting 11. Reinstall the black liner and dome drive to finish the installation. Figure 3-46 Complete the Installation...
  • Page 46 Installation Manual of Network Camera  Wall mounting: Steps: 1. Drill the screw holes and the cable hole on the wall according to the supplied drill template. Drill Template Hole A: for cables routed Screw hole 3: for through the ceiling Mounting Base Code:190600839 Figure 3-47 Drilling Template...
  • Page 47 Installation Manual of Network Camera Figure 3-49 Disassembling 4. Install the dome drive to the back box and pull the cables through the side outlet on the bottom of the back box. If you need to pull the cable through the cable outlet from the side of the camera, please remove the cover and use water-proof joints and water-proof pipe to route the cables.
  • Page 48 Installation Manual of Network Camera 5. Connecting the network cable and power cable. 6. View the camera image over the network. 7. Loosen the lock screws to adjust the panning position and tilting position, and rotate the lens to get the desired surveillance angle.

  • Page 49: Type V Dome Camera

    Installation Manual of Network Camera 3.5 Type V Dome Camera 3.5.1 Camera Description There are two types of camera appearance for this series of camera according to the different models. Figure 3-53 Overview of Type I Camera Figure 3-54 Overview Of Type II Camera...

  • Page 50: Installation

    Installation Manual of Network Camera Table 3-5 Description of Type I/II Camera Description Mounting Base Horizontal Stand Vertical Stand Bubble Network Interface Power Interface IR LED Lens Black Liner Safety Rope Audio Interface (Only supported by the camera with “-S” in its model) Alarm Interface (Only supported by the camera with “-S”...
  • Page 51 Installation Manual of Network Camera Screw Hole Ceiling Mounting Screw Hole Screw Hole Figure 3-55 Drilling Template 2. Loosen the set screws with a hex key (supplied) to remove the bubble. Figure 3-56 Remove the Bubble 3. Fix the mounting base on the ceiling with screws. Figure 3-57 Fix the Mounting Base...
  • Page 52 Installation Manual of Network Camera If required, you can route cables through the side opening on the side of the mounting base. Side Opening Figure 3-58 Side Opening 4. Loosen the tilt lock screws, adjust the tilting position in a range of 65 degrees, and tighten the tilt lock screws.
  • Page 53 Installation Manual of Network Camera Figure 3-60 Bubble Reinstallation  Micro SD Card Installation Steps: 1. Loosen the lock screws on the bubble to disassemble the camera. Figure 3-61 Disassemble the Camera 2. Insert the micro SD card to the card slot. 3.
  • Page 54 Installation Manual of Network Camera Figure 3-62 Insert the Micro SD Card 4. Install the bubble back, and tighten the lock screws on it. Figure 3-63 Install the Bubble...

  • Page 55: Type Vi Dome Camera

    Installation Manual of Network Camera 3.6 Type VI Dome Camera 3.6.1 Camera Description The overview of the network dome camera is shown below. Figure 3-64 Overview Table 3-6 Overview...
  • Page 56 Installation Manual of Network Camera Description Bubble Black Liner Lens Mounting Base Reset Auxiliary Video Output Serial Port Micro SD Card Slot Network Cable Power Cable Audio/Alarm Interface  Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 57: Installation

    Installation Manual of Network Camera Figure 3-65 Audio and Alarm Interfaces 3.6.2 Installation  Ceiling mounting Steps: 1. Loosen the three screws on the edge of the bubble with the screw driver. 2. Open the bubble and remove the inner black liner. Screw Hole Black Liner Bubble...
  • Page 58 Installation Manual of Network Camera 5. If you want to route the cables inside the ceiling, drill a cable hole in the ceiling according to the drill template. Skip this step if you want to route the cables on the surface of the ceiling. Refer to Conduit Installation on the Side for side cable routing.
  • Page 59 Installation Manual of Network Camera  Conduit Installation on the Side If you want to route the cables from side of the camera, you need to follow the steps below to install a conduit for cable routing. Steps: 1. Rotate the water-proof plug counterclockwise to remove it from the camera. Water-proof Plug Side Cable Outlet Figure 3-70 Remove the water-proof plug...

  • Page 60: Ceiling Mounting With Gang Box

    Installation Manual of Network Camera Downward Figure 3-72 Side Outlet Direction  Ceiling Mounting With Gang Box Steps: 1. Disassemble the camera. 2. Install the gang box in the ceiling. 3. Attach the mounting base to the gang box with two screws. Mounting Base Figure 3-73 In-ceiling Mount 4.
  • Page 61 Installation Manual of Network Camera Figure 3-74 Secure Camera 9. Install the inner black liner back to the camera. 10. Align the bubble with the camera. 11. Tighten the screws to secure the bubble with the camera as shown below. Figure 3-75 Secure the Bubble ...
  • Page 62 Installation Manual of Network Camera Mounting Adapter Mounting Base Figure 3-76 Secure Mounting Base 5. Route the cables through the hole in the center of the wall mount. 6. Align the camera with the mounting base. 7. Tighten the set screws to secure the camera with the mounting base. 8.

  • Page 63: Image And Focus Adjusting

    Installation Manual of Network Camera 12. Tighten the screws to secure the bubble with the camera. Figure 3-78 Secure Black Liner and Bubble  Image and Focus Adjusting Steps: 1. View the camera image using the monitor. 2. Rotate the panning table to adjust the panning position of the camera. 3.

  • Page 64: Type Vii Dome Camera

    Installation Manual of Network Camera 4). Loosen the focus lever and move the lever between F (Far) and N (Near) to obtain the optimum focus. 5). Tighten the focus lever. Zoom/Focus Lever Figure 3-80 Lens Adjustment 3.7 Type VII Dome Camera 3.7.1 Camera Description The overview of the dome camera is shown below: Figure 3-81 Overview...
  • Page 65 Installation Manual of Network Camera Figure 3-82 Overview (2) The interfaces on the rear panel are shown below: Figure 3-83 Overview (3)
  • Page 66 Installation Manual of Network Camera Figure 3-84 Overview (4) Table 3-7 Description of Overview (2~3) Description Description Black Liner Bubble Lens BNC Interface Reset Status Indicator Test Serial Port Micro SD Card Slot Adapter Plate Side Outlet Table 3-8 Description of Overview (4) Name Description 10M/100M Self-adaptive Ethernet Port(PoE...

  • Page 67: Installation

    Installation Manual of Network Camera Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. 3.7.2 Installation Steps: 1. Drill the screw holes and the cable hole according to the supplied drill template. Hole BOTTOM Figure 3-85 Drill Template...
  • Page 68 Installation Manual of Network Camera Figure 3-86 Side Outlet 2. Fix the adapter plate to the ceiling with the supplied screws. Figure 3-87 Install the Adapter Plate 3. Align the mounting base with the adapter plate and route the mounting base anticlockwise to get it fitted with the adapter plate, and then fix it by tightening the lock screw.
  • Page 69 Installation Manual of Network Camera 0~80° 0~355° 0~355° Figure 3-89 3-axis Adjustment 5. Adjust the focus and zoom. 1). Connect the VIDEO OUT interface of the camera to the debugging monitor. 2). Set the iris type to MANUAL first. 3). Adjust the No.1 Zoom Lever (T~W) to select a proper angle of view. 4).
  • Page 70 Installation Manual of Network Camera adjust it from the PTZ control interface. Figure 3-91 Zoom and Focus Adjustment of Electronic Lens 6. Attach the black liner to the dome drive. 7. Attach the bubble to the dome drive and rotate it to get tightened. Bubble Dome Drive Black Liner...

  • Page 71: Type Viii Dome Camera

    Installation Manual of Network Camera 3.8 Type VIII Dome Camera 3.8.1 Camera Description of Type A Dome Camera The overview of the outdoor dome camera is shown below: Figure 3-94 Overview (1) Figure 3-95 Overview (2) Table 3-9 Description of Overview (1~2) Description Description...

  • Page 72: Installation Of Type A Dome Camera

    Installation Manual of Network Camera Black Liner Reset Bubble Power Cable 10/100M Self-adaptive Mounting Base Ethernet Interface SD Card Slot Lens Video Out Audio and Alarm Cables 3.8.2 Installation of Type A Dome Camera Steps: 1. Drill the screw holes and the cable hole according to the supplied drill template. Drill Tempalte Hole A: for cables routed Screw Hole 3: for...
  • Page 73 Installation Manual of Network Camera Figure 3-97 Install the Mounting Base 3. Connect the corresponding power cable, network cable, audio and alarm cables. 4. Install the dome drive to the mounting base. Dome Drive Figure 3-98 Install the Dome Drive 5.
  • Page 74 Installation Manual of Network Camera Tilt 0~80° Pan 0~350° Rotation 0~350° Figure 3-99 3-axis Adjustment 6. Adjust the Lens. 1). Connect the VIDEO OUT interface of the camera to the debugging monitor. 2). Set the iris type to MANUAL first. 3).

  • Page 75: Camera Description Of Type B Dome Camera

    Installation Manual of Network Camera Figure 3-101 Install the Black Liner and Bubble 3.8.3 Camera Description of Type B Dome Camera Figure 3-102 Overview of Type B Dome Camera Table 3-10 Description of Type B Dome Camera Description Description 10/100M Self-adaptive Bubble Ethernet Interface...

  • Page 76: Installation Of Type B Dome Camera

    Installation Manual of Network Camera SD Card Slot Lens Video Out Interface Audio/Alarm Cables Reset Mounting Base Power Cable ● The most distinguish difference between type A and type B dome camera is type B dome camera has an internal PT (Pan and Tilt) unit, and you can adjust the pan and tilt angle of the camera from the client software or via web browser.
  • Page 77 Installation Manual of Network Camera Figure 3-104 Install the Mounting Base 3. Connect the corresponding power cable, network cable, audio and alarm cables. 4. Install the dome drive to the mounting base. Figure 3-105 Install the Dome Drive The surveillance angle of the camera is well- adjusted by default. If the pan and tilt angle is required to adjusted according to the different installation environment, go to the live view interface via web browser or client software after the installation is completed.
  • Page 78 Installation Manual of Network Camera Figure 3-106 Pan and Tilt Adjustment Interface 5. Install the bubble to complete the installation. Figure 3-107 Install the Bubble...

  • Page 79: Type Ix Dome Camera

    Installation Manual of Network Camera 3.9 Type IX Dome Camera 3.9.1 Camera Description of Type A Dome Camera Figure 3-108 Overview (1) Figure 3-109 Overview (2) Table 3-11 Physical Description Description Front Cover Dome Drive Micro SD Card Slot Network Cable...
  • Page 80 Installation Manual of Network Camera Description Lens IR LED Power Cable Audio/Alarm Cables Wi-Fi Antenna Serial Port Interface Hex Screw RESET/WPS Button  Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. ...

  • Page 81: Installation Of Type A Dome Camera

    Installation Manual of Network Camera 3.9.2 Installation of Type A Dome Camera Steps: 1. Drill the screw holes and the cable hole in the ceiling according to the supplied drill template. Drill Template Hole A:for cables routed through the ceiling Screw hole 1:for Mounting Base FRONT Figure 3-110 Type I Drill Template...
  • Page 82 Installation Manual of Network Camera Figure 3-112 Disassemble the Camera 3. Fix the adapter plate to the ceiling with the supplied expansion screws. Adapter Plate Side Outlet Figure 3-113 Fix the Adapter Plate If the supplied drill template is type II drill template, you can skip step 3 and go straight to step 4. 4.
  • Page 83 Installation Manual of Network Camera Figure 3-114 Fix the Dome Drive 5. Connect the power cable, network cable, and the alarm/audio cable. Use a plier to remove the removable part and route the cables via side outlet (as shown in Figure 3-113) if no cable hole is drilled in step 1, and connect the corresponding cables.
  • Page 84 Installation Manual of Network Camera Adjusting Tool Rotation Tilt Figure 3-116 3-axis Adjustment 9. Tighten the hex screw to fix the well-adjusted surveillance angle. 10. Align the front cover to the dome drive and tighten the set screws on the front cover to complete the installation.
  • Page 85 Installation Manual of Network Camera Figure 3-118 Fix the Adapter Plate 2. Fix the dome drive to the adapter plate with the supplied PM4x8 screws. Figure 3-119 Fix the Dome Drive 3. Connect the power cable, network cable, and the alarm/audio cables. 4.
  • Page 86 Installation Manual of Network Camera ceiling bracket mounting is adopted. 2. Fix the adapter plate to the ceiling bracket with the supplied PM4x8 screws. Figure 3-121 Fix the Adapter Plate 3. Install the dome drive to the adapter plate. Figure 3-122 Fix the Dome Drive...
  • Page 87 Installation Manual of Network Camera 4. Align the front cover to the dome drive and tighten the set screws on the front cover to complete the installation. Figure 3-123 Install the Front Cover  Wall Bracket Mounting Steps: 1. Install the wall bracket to the wall with the supplied screws in the wall bracket package. The matched ceiling bracket model is DS-1272ZJ-120B, and you need to purchases it separately if wall bracket mounting is adopted.
  • Page 88 Installation Manual of Network Camera Figure 3-125 Fix the Adapter Plate 3. Fix the dome drive to the wall bracket with the supplied screws. Figure 3-126 Fix the Camera 4. Align the front cover to the dome drive and tighten the set screws on the front cover to complete the installation.
  • Page 89 Installation Manual of Network Camera Figure 3-127 Install the Front Cover  Install the Micro SD Card This series of camera supports local storage, please refer to the following steps to install the micro SD card. Steps: 1. Remove the front cover by loosening the set screws on it. Figure 3-128 Remove the Front Cover 2.

  • Page 90: Installation Manual Of Network Camera

    Installation Manual of Network Camera 3.9.3 Camera Description of Type B Dome Camera Figure 3-130 Overview Table 3-12 Physical Description Description Cover Lens Power LED indicator, It turns solid red when power is connected. Base Plate Set Screw Hole Set Screw of Lens S &...
  • Page 91 Installation Manual of Network Camera 1. (Optional) Use a plier to remove the clip (marked in dotted line in the figure below) on the side of the back box and then route the cables through the opening instead of the cable hole. Figure 3-131 Side Clip 2.
  • Page 92 Installation Manual of Network Camera 4. Fix the camera to the ceiling with the supplied screws. Figure 3-134 Fix the Camera 5. View the video image of the camera over the network. 6. Loosen the lens set screws. Figure 3-135 Loosen the Lens Set Screws 7.
  • Page 93 Installation Manual of Network Camera Figure 3-136 Adjust Panning Position Figure 3-137 Adjust Tilting Position As the lens of camera has already been factory adjusted to the best imaging effect, you just need to adjust the panning position and tilting position to get the desired surveillance angle. 8.

  • Page 94: Type X Dome Camera

    Installation Manual of Network Camera Figure 3-138 Install the Back Box 3.10 Type X Dome Camera 3.10.1 Camera Description Two types of network Mini PT cameras are shown below. Type I: Wi-Fi network transmission is supported for the Type I network Mini PT camera. Figure 3-139 Overview (1)-Type I...
  • Page 95 Installation Manual of Network Camera Figure 3-140 Overview (2)-Type I Figure 3-141 Overview (3)-Type I Table 3-13 Description of Type I Network Mini PT Camera Description Silicone Gasket Dome Drive WPS(Wi-Fi Protected Setup) Button Micro SD Card Slot Photic Cover Lens Lens Ring PIR(Passive Infrared) sensor...

  • Page 96: Remote Control

    Installation Manual of Network Camera Description Speaker Solid blue: Network is connected, and camera is unarmed. Flicking blue: No network connection. Status LED Solid red: Camera is armed. Flicking red: Camera is not working properly. Solid green: Camera is connected to the platform. ...

  • Page 97: Installation

    Installation Manual of Network Camera Figure 3-142 Remote Control Table 3-14 Description of Remote Control Button Description Press the button to arm the camera. In arming status, the alarm function, such Arm Button as the wireless alarm and the PIR alarm is enabled. Disarm Press the button to disarm the camera.
  • Page 98 Installation Manual of Network Camera Figure 3-143 Drill Template 3. Align the screw holes on the ceiling and adapter plate, and then fix the adapter plate to the ceiling with the supplied screws. Bayonet Joint Figure 3-144 Install the Adapter Plate For cement wall, you need to use the expansion screw to fix the mount;...
  • Page 99 Installation Manual of Network Camera OPEN LOCK Figure 3-145 Install the Camera 5. Adjust surveillance view angle. 1) Hold and rotate the main camera body to adjust the view angle in the pan direction: [0° ~355° ]. 2) Move the dome drive upwards or downwards to adjust the view angle in the tilt direction: [-20°...

  • Page 100: Type Xi Dome Camera

    Installation Manual of Network Camera 1. Pull the removable cover on the mounting base outwards and move it aside. 2. Insert the SIM card into the SIM card slot. SIM card slot is only available for some certain camera models. 3.
  • Page 101 Installation Manual of Network Camera 4 5 6 7 8 9 Figure 3-149 Detailed Components Table 3-15 Description Description Black Liner Bubble Power Cable Interface Alarm Output A Alarm Output B Grounding Alarm Input Audio In Audio Out Reset Button CVBS Interface SD Card Slot Mounting Base...

  • Page 102: Installation

    Installation Manual of Network Camera 3.11.2 Installation  Ceiling Mounting Steps: 2. Drill the screw holes and the cable hole in the ceiling according to the supplied drill template. Cable Outlet Drilling Template Screw hole 1:for Mounting Base Hole A:for cables routed through the ceiling FRONT Figure 3-150 Drill Template 3.
  • Page 103 Installation Manual of Network Camera 4. Use a hexagonal screwdriver to loosen the lock screw on the bubble, and remove the black liner. 5. Route the cables from the cable hole, and connect the corresponding cables. You can select to route the cables from the side outlet instead of the cable hole in the ceiling. See Figure below.
  • Page 104 Installation Manual of Network Camera Figure 3-153 Install the Black Liner and Bubble 9. Tighten the lock screw on the bubble. Figure 3-154 Tighten the Lock Screw  Wall Mounting You need to purchase a wall bracket separately if wall mounting is selected. 1.
  • Page 105 Installation Manual of Network Camera Please insert the expansion screws first if the camera is mounted to the cement wall, and you can use the self-tapping screws directly if camera is mounted to the wooden wall. 2. Install the bowl-shape cover to the wall bracket. Figure 3-155 Install the Wall Bracket 3.
  • Page 106 Installation Manual of Network Camera Figure 3-157 Install the Black Liner and Bubble 7. Tighten the lock screw on the bubble. Lock Screw Figure 3-158 Tighten the Lock Screw  3-axis Adjustment and Lens Adjustment 3-axis Adjustment This series of camera supports 3-axis adjustment, and you can adjust the camera to the desired...

  • Page 107: Lens Adjustment

    Installation Manual of Network Camera surveillance angle after the black liner is installed. 0°~80° 0°~355° 0°~355° Figure 3-159 3-axis Adjustment Lens Adjustment The camera with letter “Z” in its model suffix support electronic lens. You can adjust the lens via the zoom button or focus button on the PTZ control interface after you login to a camera.

  • Page 108: Type Xii Dome Camera

    Installation Manual of Network Camera Figure 3-161 Lens Adjustment 3.12 Type XII Dome Camera 3.12.1 Camera Description The overview of type XII dome camera is shown below. Figure 3-162 Overview(1)

  • Page 109: Description

    Installation Manual of Network Camera Figure 3-163 Overview (2) Figure 3-164 Overview(3) Table 3-16 Description of Overview Description Bubble Lens Micro SD Card Slot WPS (Wi-Fi Protected Setup) / Reset Button Power Supply Interface (12 VDC) 10M / 100M self-adaptive Ethernet interface & PoE...

  • Page 110: Installation

    Installation Manual of Network Camera 3.12.2 Installation  Ceiling Mounting Steps: 1. Drill the hole according to the supplied drill template. Figure 3-165 Drill Template 2. Hold and remove the bubble from the camera body. The bubble is attached to the camera body via magnetic force. Be gentle but firm when removing Figure 3-166 Remove the Bubble 3.
  • Page 111 Installation Manual of Network Camera 4. Gather together the brackets, as shown below, and push the brackets and camera body upward through the mounting hole. The brackets will automatically expand under the spring force and fix the camera body to the wall. Ceiling Push Upward Figure 3-167 Fix the Camera Body...
  • Page 112 Installation Manual of Network Camera 6. Re-install the bubble. The bubble will be automatically attached to the camera body under the magnetic force. Ceiling Re-install Bubble Figure 3-169 Re-install the Bubble 7. The installation is complete.  Install SD Card Steps: 1.
  • Page 113 Installation Manual of Network Camera  Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.  A wireless router with the WPS function is required to enable the WPS function of the camera. Refer to the steps below.

  • Page 114: Chapter 4 Bullet Camera Installation

    Installation Manual of Network Camera Chapter 4 Bullet Camera Installation 4.1 Type I Bullet Camera 4.1.1 Camera Description The camera overview is shown as follows: Figure 4-1 Overview Figure 4-2 Overview Table 4-1 Description Description 10M/100M self-adaptive Ethernet interface Power Supply Sun Shield Adjusting Screw...

  • Page 115: Installation

    Installation Manual of Network Camera 4.1.2 Installation Steps: 1. Attach the wall mount (not provided) to the wall and tighten the screws to fix it. Figure 4-3 Install the Wall Mount 2. Secure the camera to the wall mount with set screws. 3.

  • Page 116: Type Ii Bullet Camera

    Installation Manual of Network Camera Figure 4-5 Panning 5. Loosen the tilting lock screw to adjust the tilting angle [0~90° ]. Figure 4-6 Tilting 4.2 Type II Bullet Camera 4.2.1 Camera Description Two types of camera rear panel are shown in Figure 4-7 and Figure 4-8. Choose the right figure according to your purchased product.

  • Page 117: Installation

    Installation Manual of Network Camera Figure 4-7 Overview Figure 4-8 Overview Table 4-2 Physical Description Description 10M/100M Self-adaptive Ethernet Interface Power Supply Interface IN, G: Alarm input interface 1A, 1B: Alarm output interface D+, D-: RS-485 interface AUDIO IN, G: Audio input interface AUDIO OUT, G: Audio output interface 4.2.2 Installation Steps:...
  • Page 118 Installation Manual of Network Camera Mounting Base Figure 4-9 Fix the Mounting Base 2. Fix the mounting bracket with the camera to the mounting base. The “bottom” mark on the mounting base should align with the “bottom” mark on the mounting bracket.
  • Page 119 Installation Manual of Network Camera 5. Adjust the camera to the desired surveillance angle and then tighten the screws on bracket to fix the camera. Rotation Panning Screw Screw Tilting Screw Figure 4-11 Adjust Monitoring Angle 6. Loosen the lock screw on the sun shield and slide the sun shield until you can remove it. Remove the sun shield.
  • Page 120 Installation Manual of Network Camera Adjust the Lens Front Cover Figure 4-13 Adjust the Lens 8. Fix the lens; reinstall the front cover and the sun shield to finish the installation. Figure 4-14 Complete the Installation...

  • Page 121: Type Iii Bullet Camera

    Installation Manual of Network Camera 4.3 Type III Bullet Camera 4.3.1 Camera Description Figure 4-15 Bullet Camera Overview Table 4-3 Description Description Sun Shield Back Box Grounding Screw Adjustable Bracket Mounting Base Reset 4.3.2 Installation Steps: 1. Attach the drill template on the wall.
  • Page 122 Installation Manual of Network Camera Screw Hole Template Figure 4-16 Attach the template 2. Secure the camera to the ceiling with the supplied expansion screws. Figure 4-17 Secure the Camera to the Ceiling 3. Adjust the Lens. Loosen the adjustable nut on the bracket. Adjust the panning angle [0~360°...

  • Page 123: Type Iv Bullet Camera

    Installation Manual of Network Camera T Direction R Direction P Direction Adjustable Figure 4-18 3-axis Adjustment 4.4 Type IV Bullet Camera 4.4.1 Camera Description Figure 4-19 Bullet Camera Overview Table 4-4 Description Description Lens IR LED Sun Shield Adjusting Screw Network Cable...

  • Page 124: Installation

    Installation Manual of Network Camera Power Cable 4.4.2 Installation Steps: 1. Drill the cable hole and the screw hole in the ceiling according to the supplied drill template. Ceiling Mounting 1:Screw Hole for 2:Screw Hole for Bracket Mounting Base Figure 4-20 The Drill Template 2.

  • Page 125: Type V Bullet Camera

    Installation Manual of Network Camera 1). Loosen No.1 adjusting screw to adjust the panning position [0° ~ 360° ]. 2). Tighten No.1 adjusting screw. 3). Loosen the No.2 adjusting screw to adjust the tilting position [0° ~ 100° ]. 4). Tighten No.2 adjusting screw. 5).

  • Page 126: Front Cover

    Installation Manual of Network Camera Figure 4-23 Overview Table 4-5 Overview Description Sun Shield Front Cover Zoom and Focus Lever IR LED Lens Air Vent Video Output Interface Integrated Bracket Reset Button Micro SD Card Slot Power Interface Network Interface ...

  • Page 127: Installation

    Installation Manual of Network Camera  Some of the models support audio and alarm functions. The interfaces are shown as follows. Audio Cable Alarm Cables Figure 4-24 Audio and Alarm Interfaces 4.5.2 Installation  SD Card Installation Steps: 1. Loosen the lock screw on the sun shield to slide the sun shield according to the arrow direction as shown in Figure 4-25 (left).
  • Page 128 Installation Manual of Network Camera Figure 4-26 Install the SD Card 6. Slide the sun shield according to the arrow direction as shown in Figure 4-27(left). 7. Tighten the lock screw on the sun shield. Rotating Label Figure 4-27 Assemble the Camera For water-proof, please align the rotating label on the front cover with that on the camera when you rotate the front cover clockwise.
  • Page 129 Installation Manual of Network Camera 5. Drill screw holes in the wall according to the No.1 hole of the drill template. Ceiling Mounting 1:Screw Hole for 2:Screw Hole for Bracket Mounting Base Figure 4-28 Drilling Holes in the Wall 6. If you need to route cables through the wall (or ceiling), cut a cable hole according to the drill template.
  • Page 130 Installation Manual of Network Camera 4. Secure the junction box to the wall with expansion screws. 5. Route the cables of the camera. 9. Connect the video output connector to the monitor. Connect the power connector to the power supply. 10.
  • Page 131 Installation Manual of Network Camera Gang Box Camera Attachment Figure 4-31 Secure the Camera  View Angle Adjusting Purpose: 3-axis (pan/tilt/rotation) adjusting allows adjustment for optimum camera rotation and placement. Pan Adjustment Steps: 1. Loosen the lock screw-1. 2. Adjust the panning position of the camera. The adjusting range is from 0 degrees to 360 degrees. 3.
  • Page 132 Installation Manual of Network Camera Panning Rotation Tilting Figure 4-32 Lens Adjustment  Zoom and Focus Adjusting Purpose: You can use the zoom lever and focus lever to adjust the zoom value and focus value. Steps: 1. Disassemble the camera. 2.

  • Page 133: Type Vi Bullet Camera

    Installation Manual of Network Camera 4.6 Type VI Bullet Camera 4.6.1 Camera Description The overview of the network bullet camera is shown below: Figure 4-34 Overview Table 4-6 Description Description Description Sun Shield Bracket Junction Box Reset SD Card Slot Front Box Analog Video Output 4.6.2 Installation...
  • Page 134 Installation Manual of Network Camera Cable Hole Figure 4-35 Drill Template 2. Drill one cable hole according to the sign shown on the drill template. If you want to route the cables through the side of the junction box, you can skip this step. 3.
  • Page 135 Installation Manual of Network Camera 5. Hook the camera to the junction box with the safety rope. 6. Tighten the screws to fix the camera to the junction box. Figure 4-37 Fix the Camera to the Junction Box 7. Adjust the camera to the desired surveillance angle and then tighten the screws on bracket to fix the camera.
  • Page 136 Installation Manual of Network Camera (purchased separately) to the foldable position of the bracket to protect it from water. 8. Loosen the lock screw on the sun shield and remove the sun shield. 9. Rotate to remove the front box from camera and adjust the zoom lever and focus lever to get a clear image.

  • Page 137: Type Vii Bullet Camera

    Installation Manual of Network Camera 4.7 Type VII Bullet Camera 4.7.1 Camera Description 13 14 9 10 11 VIN1 AUDIO AUDIO LAN(PoE) RXD TXD GND IN1 1B 1A DC 12V RESET 16 17 Figure 4-41 The Overview of Covert Camera with Cylindrical Sensor Unit 13 14 9 10 11 VIN1...

  • Page 138: Installation

    Installation Manual of Network Camera Mounting Rail LINK Indicator LED Block-Shaped Sensor Unit Audio Interface Cover RJ-12 Interface Straight Mounting Bracket Micro SD Card Slot Cylindrical Sensor Unit RESET Button RJ-12 Cable Power Interface Round Rail Mounting Bracket PoE & Network POWER Indicator LED RS-232 &Alarm Interface Press RESET button about 10s when the camera is powering on or rebooting to restore the default...
  • Page 139 Installation Manual of Network Camera Figure 4-43 Fix the Standard Mounting Rail  For cement surface mounting, you need to use the expansion screw to fix the camera.  For wooden surface mounting, you can just use the self-tapping screw to fix the camera. 2.
  • Page 140 Installation Manual of Network Camera Figure 4-45 Buckle the Main Unit onto Standard Rail  Installation of Block-Shaped Sensor Unit This series of camera support concealed mounting and exposed mounting with a decorative cover.  Concealed Mounting Please make sure that the mounting surface is suitable for adhesive pasting. Steps: 1.
  • Page 141 Installation Manual of Network Camera Figure 4-47 Paste the Bracket 3. Install the Block-shaped sensor unit into the bracket and make it to be buckled. 4. Tighten the fastening screw on the top of the bracket. Figure 4-48 Insert the Block-shaped Sensor Unit ...
  • Page 142 Installation Manual of Network Camera Figure 4-49 Fix the Block-shaped Sensor Unit ● For cement surface mounting, you need to use the expansion screw to fix the camera. ● For wooden surface mounting, you can just use the self-tapping screw to fix the camera. 2.
  • Page 143 Installation Manual of Network Camera Please make sure that the mounting surface is suitable for adhesive pasting. Steps: 1. Drill on the mounting surface. As shown in Figure 4-51. Figure 4-51 Drill on the Surface Make sure that the drilling hole is big enough for the camera lens. 2.

  • Page 144: Type Viii Bullet Camera

    Installation Manual of Network Camera Figure 4-53 Install the Cylindrical Sensor 4.8 Type VIII Bullet Camera 4.8.1 Camera Description The overview of the network bullet camera is shown below. Figure 4-54 Overview Table 4-9 Description Description Photoresistor Lens Sun Shield Power Interface Network Interface...

  • Page 145: Installation

    Installation Manual of Network Camera Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. 4.8.2 Installation  Ceiling Mounting Steps: 1. Drill the screw holes and the cable hole in the ceiling according to the supplied drill template. Ceiling Mounting 1:Screw Hole for 2:Screw Hole for...
  • Page 146 Installation Manual of Network Camera Figure 4-56 Install the Camera 3. Adjust the surveillance angle. Loosen No.1 lock screw to adjust the tilt angle [0 ° ~100° ]. Loosen No.2 lock screw to adjust the pan angle [0° ~360° ]. Loosen No.3 lock screw to rotate the camera [0°...
  • Page 147 Installation Manual of Network Camera 3. Route the cables. 4. Fix the camera to the junction box with screws. 5. Adjust the surveillance angle according to step 3 in ceiling mounting. Drill Template Figure 4-58 Installation with a Junction Box ...

  • Page 148: Type Ix Bullet Camera

    Installation Manual of Network Camera Figure 4-59 Installation with a Gang Box 4.9 Type IX Bullet Camera 4.9.1 Camera Description The overview of the network bullet camera is shown below. Figure 4-60 Overview(1) Figure 4-61 Overview (2) Table 4-10 Description...

  • Page 149: Installation

    Installation Manual of Network Camera Description Sun Shield Camera Body Bracket Tray Bracket Hinge Bracket Bearing Mounting Base Seal Ring Junction Box Network Cable Interface Power Cable Interface Alarm Interface IN, G: Alarm In 1A,1B: Alarm Out RS-485 Communication Interface Audio Input Audio Output SD Card Slot...
  • Page 150 Installation Manual of Network Camera Drill Template 1 1:Screw Hole for Mounting Base Figure 4-62 Drill Template 2. Fix the junction box to the ceiling with the supplied screws. Please insert the expansion screws first if the camera is mounted to the cement ceiling. And you can use the self-tapping screws directly if camera is mounted to the wooden ceiling.
  • Page 151 Installation Manual of Network Camera Figure 4-64 Install Camera 5. Tighten the lock screw on the camera to complete installation. Figure 4-65 Tighten the Lock Screw  Wall Mounting 1. Drill the screw hold and the cable hole according to the supplied drill template.
  • Page 152 Installation Manual of Network Camera Drill Template 1 1:Screw Hole for Mounting Base Figure 4-66 Drill Template 2. Fix the junction box to the wall with the supplied screws. Please insert the expansion screws first if the camera is mounted to the cement wall. And you can use the self-tapping screws directly if camera is mounted to the wooden wall.

  • Page 153: Axis Adjustment

    Installation Manual of Network Camera Figure 4-68 Install Camera 5. Tighten the lock screw on the camera to complete installation. Figure 4-69 Tighten the Lock Screw  3-axis Adjustment This series of camera supports 3-axis adjustment, and you can follow the steps below to adjust the camera to the desired surveillance angle.
  • Page 154 Installation Manual of Network Camera -180°~+180° Figure 4-70 Adjust Pan Angle 2. Loosen No.2 lock screw to adjust the tilt angle [± 180° ]. -180°~+180° Figure 4-71 Adjust Tilt Angle 3. Loosen No.3 lock screw, and rotate the camera body [0° ~105° ] to adjust the camera to the desired angle of view.

  • Page 155: Type X Bullet Camera

    Installation Manual of Network Camera Figure 4-72 Adjust the Rotation Angle 4. Tighten the screws after the adjustment is completed. 4.10 Type X Bullet Camera 4.10.1 Camera Description The overview of the network bullet camera is shown below. Figure 4-73 Overview Table 4-11 Description Description Photoresistor...

  • Page 156: Installation

    Installation Manual of Network Camera RS-485 Interface Audio In/out Micro SD Card Slot Reset Button Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. 4.10.2 Installation ...
  • Page 157 Installation Manual of Network Camera Figure 4-75 Fix the Wall Mount Fit the removed tilt adjust table to the camera, and fix it with two screws. Figure 4-76 Install the Tilt Adjust Table 4. Install the camera to the wall mount and tighten the two lock screws. 5.

  • Page 158: Micro Sd Card Installation

    Installation Manual of Network Camera Figure 4-77 Adjust the Surveillance Angle 6. Install water-proof case of RJ-45 plug. A water-proof case of RJ-45 plug is provided to avoid the short-circuit fault caused by water. Please install the protective case as the figure below. Figure 4-78 Install the Water-proof Case ...

  • Page 159: Type Xi Bullet Camera

    Installation Manual of Network Camera 3. Insert the micro SD card to the card slot. 4. (Optional) Push the inserted micro SD card slightly to get it sprung by its built-in springing to remove it. 5. Install the back cover and sun shield back. Figure 4-81 Install the Back Cover and Sun Shield 4.11 Type XI Bullet Camera 4.11.1 Camera Description...

  • Page 160: Installation

    Installation Manual of Network Camera Table 4-12 Description Description Photoresistor Lens Sun Shield 3-axis Bracket Network Cable Interface Power Cable Interface Alarm Cable Interface Video Cable Interface Audio Out Audio In Reset Button Micro SD Card Slot Serial Port Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
  • Page 161 Installation Manual of Network Camera Ceiling Mounting 1:Screw Hole for 2:Screw Hole for Bracket Mounting Base Figure 4-83 Drill Template 2. Fix the camera to the wall with the supplied screws. Please insert the expansion screws first if the camera is mounted to the cement ceiling. And you can use the self-tapping screws directly if camera is mounted to the wooden ceiling.
  • Page 162 Installation Manual of Network Camera 0° ~ 360° 0° ~ 360° 0° ~ 100° Figure 4-85 Adjust the Surveillance Angle  Wall Mounting with a Junction Box 1. Drill the screw hole and cable hole according to the supplied drill template (as shown in Figure 4-90).

  • Page 163: Type Xii Bullet Camera

    Installation Manual of Network Camera 1. Install the adapter plate to the gang box. 2. Route the cables. 3. Fix the camera to the adapter plate with screws. 4. Adjust the surveillance angle according to step 3 in ceiling mounting. Adapter Plate Figure 4-87 Installation with a Gang Box 4.12 Type XII Bullet Camera...
  • Page 164 Installation Manual of Network Camera Figure 4-89 Overview-Type II Table 4-13 Description Description Photoresistor Lens Sun Shield Power Interface Network Interface WPS (Wi-Fi Protected Setup) / Reset Button 4G Card Slot...

  • Page 165: Installations For Type I Bullet Camera

    Installation Manual of Network Camera SD Card Slot Indicators PoE (Power over Ethernet) Connection Cable, optional  The figures shown in this manual are for reference only. The appearance and interfaces of the camera are subject to the actual model. ...
  • Page 166 Installation Manual of Network Camera Ceiling Mounting 1:Screw Hole for 2:Screw Hole for Bracket Mounting Base Figure 4-91 Drill Template 2. Fix the camera to the wall with the supplied screws. Please insert the expansion screws first if the camera is mounted to the cement ceiling. And you can use the self-tapping screws directly if camera is mounted to the wooden ceiling.
  • Page 167 Installation Manual of Network Camera 0° ~ 360° 0° ~ 360° 0° ~ 100° Figure 4-93 Adjust the View Angle 4. (Optional) Install the water-proof jacket for network interface. It is recommended to adopt the water-proof jacket (supplied) for the network interface when the camera is installed outdoor.
  • Page 168 Installation Manual of Network Camera  Wall Mounting with a Junction Box This section is applicable to the Type I bullet camera. 1. Drill the screw hole and cable hole according to the supplied drill template (shown as Figure 4-91). 2.

  • Page 169: Installations For Type Ii Bullet Camera

    Installation Manual of Network Camera 7. Fix the camera to the adapter plate with screws. 8. Adjust the view angle. For details, refer to Step 3 in Chapter 4.12.2. 9. (Optional) Install the water-proof jacket for network interface. For details, refer to Step 4 in Chapter 4.12.2.
  • Page 170 Installation Manual of Network Camera Tilt Adjust Table Tilt Adjust Screw Figure 4-97 Remove the Tilt Adjust Table 2. Secure the wall bracket to the wall with the screws. Wall Figure 4-98 Secure the Wall Bracket 3. Fit the tilt adjust table to bottom of the bullet camera, and then fix it with two set screws. Set Screw Set Screw Tilt Adjust Table...
  • Page 171 Installation Manual of Network Camera Tilt Adjust Screw Figure 4-100 Install the Camera Body 5. Adjust the view angle. 1). Loosen the pan adjust screw to adjust the panning view angle [0° ~360° ]. 2). Loosen the tilt adjust screw to adjust the tilting view angle [0° ~± 45° ]. 3).
  • Page 172 Installation Manual of Network Camera 1. Fix the pendant bracket to the ceiling with the supplied screws. Ceiling Figure 4-102 Fix the Pendant Bracket 2. Loosen and remove the set screw on the sun shield of the camera. 3. Aim the screwed hole on the camera at the top of the pendant bracket, and then rotate the camera until it is secured tightly.
  • Page 173 Installation Manual of Network Camera Knob on Bracket Tilt: 0°~90° Pan: 0°~360° Figure 4-104 Adjust the View Angle 5. (Optional) Install the water-proof jacket for network interface. For details, refer to the Step 4 in Chapter 4.12.2...

  • Page 174: Chapter 5 Turret Camera Installation

    Installation Manual of Network Camera Chapter 5 Turret Camera Installation 5.1 Camera Description Figure 5-1 Overview Table 5-1 Description Description 10M/100M self-adaptive Ethernet interface Power Cable Trim Ring Lens IR LED Enclosure Dome Drive Please make sure that the power adapter is compatible with the camera. This series of camera supports Power over Ethernet (PoE), and the standard power supply is 12 VDC.

  • Page 175: Dome Drive

    Installation Manual of Network Camera Trim Ring Dome Drive Figure 5-2 Dissemble the Camera 2. Drill the screw holes and the cable hole on the ceiling according to the drill template. Figure 5-3 The Drill Template There are two cable outlet methods. One is to route the cables through the cable hole, and the other is to route the cables through the side outlet shown below.
  • Page 176 Installation Manual of Network Camera Figure 5-4 Side Outlet Three side outlets on the enclosure are selectable, which makes routing the cables easier instead of drilling a cable hole on the ceiling. Use a plier to remove the plastic and route the cables through the hole.
  • Page 177 Installation Manual of Network Camera Figure 5-6 Lock Screw Figure 5-7 Adjust the Lens 6. Attach the trim ring to the camera and rotate the trim ring clockwise to get it secured. Figure 5-8 Install the Trim Ring...
  • Page 178 Installation Manual of Network Camera Figure 5-9 Complete the Installation...

  • Page 179: Chapter 6 Cube Camera Installation

    Installation Manual of Network Camera Chapter 6 Cube Camera Installation 6.1 Type I Cube Camera 6.1.1 Camera Description Figure 6-1 Overview Table 6-1 Description Description IR LED Microphone LINK: Network Status LED Indicator. LED indicator is solid yellow when network connection is functioning properly.

  • Page 180: Installation

    Installation Manual of Network Camera Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. 6.1.2 Installation Steps: 1. Fix the mounting bracket to the ceiling. Expansion Screw Self-tapping Screw Figure 6-2 Fix the Bracket...

  • Page 181: Type Ii Cube Camera

    Installation Manual of Network Camera Figure 6-4 Installation Completes 6.2 Type II Cube Camera 6.2.1 Camera Description The overview of the network cube camera is shown below.

  • Page 182: Micro Sd Card Slot

    Installation Manual of Network Camera Figure 6-5 Overview Table 6-2 Description Description IR LED Photosensitive Resistance PIR sensor Microphone Lens 3-axis Adjustment Bracket Alarm Indicator: Indicator goes solid red (camera armed) or solid blue (camera unarmed). Status Indicator: Indicator flashes blue when any movement or presence is detected Link Indicator: Indicator flashes orange when network connection is functioning properly.

  • Page 183: Remote Control Overview

    Installation Manual of Network Camera  Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.  For 2C series camera, which supports WPS function, you need take steps below to enable the WPS function.

  • Page 184: Installation

    Installation Manual of Network Camera Button Name Description Status Indicating the status of the remote control; when you press any button, the Indicator indicator flashes red. Press the button to arm the camera. In arming status, the alarm function, such Arm Button as the wireless alarm and the PIR alarm is enabled.
  • Page 185 Installation Manual of Network Camera Figure 6-8 Fix the Camera 4. Connect the coresponding power cable and the network cable through the drilled cable hole. Or pull the cable through the side outlet of the camera. 5. Reinstall the right cover and fixator. Side Outlet Figure 6-9 Reinstall the cover and Fixator 6.

  • Page 186: Type Iii Cube Camera

    Installation Manual of Network Camera Lock Nut 1 Lock Nut 2 Tilt Rotation Figure 6-10 Adjust the Camera 6.3 Type III Cube Camera 6.3.1 Camera Description There are two types of appearances for 24 series camera. Please refer to the figure below. And one appearance will be taken as an example in the chapter below.
  • Page 187 Installation Manual of Network Camera Figure 6-12 Type II Appearance Figure 6-13 Overview...
  • Page 188 Installation Manual of Network Camera Table 6-4 Description Description Lens Microphone IR LED Alarm: Solid red when the camera is armed; Solid blue when the camera is unarmed. Indicator Status: Reserved Link: Flashing amber when network is connected; Unlit when network is disconnected PIR(Passive Infrared) sensor Light Sensing SD Card Slot...

  • Page 189: Notice

    Installation Manual of Network Camera  Press the WPS button on the camera, and then press the WPS button on the router will work as well, and the expire time of WPS connection on the camera is 120s.  The link indicator blinks if the wireless connection succeeded. 6.3.2 Notice ...

  • Page 190: Installation

    Installation Manual of Network Camera  High humidity may damage the  Under no circumstances should camera hardware; put it in dry and you submerge the camera in well-ventilated place. any type of liquid.  Electromagnetic radiation may affect the video data transmission and the image quality.

  • Page 191: Ceiling Mounting

    Installation Manual of Network Camera Figure 6-14 Assemble the Bracket 2. Align the camera body to the bracket, and rotate the camera body to fix it with the bracket. Figure 6-15 Install the Camera Body  Ceiling Mounting 3. Drill the screw holes according to the drill template. Drill Template Screw hole All:for Mounting Base Figure 6-16 Drill Template...
  • Page 192 Installation Manual of Network Camera 4. Install the fixed plate to the ceiling with the supplied screws. 5. Install the mounting base to the fixed plate. Figure 6-17 Install the Fixed Plate and Mounting Base 6. Install the camera to the bracket. Figure 6-18 Install the Camera 7.

  • Page 193: Chapter 7 Mini Camera Installation

    Installation Manual of Network Camera Chapter 7 Mini Camera Installation 7.1 Camera Description Figure 7-1 Overview (1) Figure 7-2 Overview (2) Table 7-1 Description Description Tilt Adjust Screw 10M / 100M self-adaptive Ethernet interface Power Supply Interface (12 VDC) Tieline buckle Lens Bracket Reset Button...

  • Page 194: Installation

    Installation Manual of Network Camera Press RESET about 10s when the camera is power on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. 7.2 Installation Steps: 1. Fix the camera to the mounting surface with screws. Figure 7-3 Fix the Camera 2.
  • Page 195 Installation Manual of Network Camera Figure 7-4 Adjust the Camera Position 3. Loosen the tilt adjust screw to adjust the camera surveillance angel, and tighten the screw if the angle-adjust is completed. 0~180° Figure 7-5 Fix the Bracket...

  • Page 196: Chapter 8 Mobile Camera

    Installation Manual of Network Camera Chapter 8 Mobile Camera 8.1 Camera Description Figure 8-1 Overview of Mobile Camera Table 8-1 Description Description Description Cover Dome Drive Lens Shield Video Cable IR LED Power Cable 10/100M Self-adaptive Ethernet Mounting Base Interface...

  • Page 197: Installation

    Installation Manual of Network Camera 8.2 Installation Steps: 1. Drill to pierce the screw holes and the cable hole in the vehicle shell according to the supplied drill template. Drill Template Screw Hole Screw Hole Screw Hole Screw Hole Figure 8-2 Drill Template 2.
  • Page 198 Installation Manual of Network Camera Vehicle Spacer Shell Figure 8-4 Fit the Mounting Screws 5. Screw the nuts onto the bottom of the mounting screws from the rear side of the shell. Vehicle Shell Figure 8-5 Screw the Nut 6. Tighten the nuts to secure the mounting base.
  • Page 199 Installation Manual of Network Camera Figure 8-6 Tighten the Nuts 7. Connect the corresponding power cable, network cable, and video cable. 8. Adjust the surveillance angle. 1). Push the lens upward to adjust the tilting angle [0° ~30° ]. 2). Loosen the P direction lock screws. 3).
  • Page 200 Installation Manual of Network Camera P Direction ° ° 15 ~15 R Direction ° ° 0 ~360 Lock Screw for P Direction Adjustment T Direction ° ° 0 ~30 Figure 8-7 3-axis Adjustment 9. Align the cover to camera and fix it by tightening the screws which are embedded together with the cover.

Table of Contents
