- Page 1 Camera Network Fisheye Camera Quick Start Guide UD.6L0201B1907A01...
- Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
-
Page 4: Regulatory Information
Network Fisheye Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. -
Page 5: Safety Instruction
Network Fisheye Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. - Page 6 Network Fisheye Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ●...
- Page 7 Network Fisheye Camera·Quick Start Guide ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. Cautions ● Make sure the power supply voltage is correct before using the camera.
- Page 8 Network Fisheye Camera·Quick Start Guide ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average enduring time.
-
Page 9: Table Of Contents
Network Fisheye Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 10 Overview of Fisheye Camera ......... 10 Disassembling the Camera ..........11 2 Installation ..................13 Ceiling Mounting ............14 Wall Mounting with a Slant Mounting Base ....16 Wall Mounting with a Junction Box ....... -
Page 10: Appearance Description
Network Fisheye Camera·Quick Start Guide 1 Appearance Description Overview of Fisheye Camera Figure 1-1 Overview of the Fisheye Camera Figure 1-2 Disassemble of Fisheye Camera... -
Page 11: Disassembling The Camera
Network Fisheye Camera·Quick Start Guide Table 1-1 Description of Overview Description Description Camera Body Ethernet Interface Reset RS-485 Interface Micro SD Card Slot Power Interface Camera Cover Audio In Alarm Interfaces Audio Out Disassembling the Camera Steps: 1. Loosen the lock screw on the camera cover. 2. - Page 12 Network Fisheye Camera·Quick Start Guide Oval Sheet Figure 1-3 Move the Oval Sheet Aside Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
-
Page 13: Installation
Network Fisheye Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera. -
Page 14: Ceiling Mounting
Network Fisheye Camera·Quick Start Guide 2.1 Ceiling Mounting Steps: 1. Drill three screw holes and the cable hole according to the supplied drill template. Drill Template HoleA: for cables routed through the ceiling Screw hole 1: for Mounting Base Figure 2-1 Drill Template 2. - Page 15 Network Fisheye Camera·Quick Start Guide 3. Connect the corresponding power cable, network cable, audio and alarm cables. 4. Align the screw holes to the inserted screws, hook the camera body to the screws, and route the camera body to secure the camera with the screws.
-
Page 16: Wall Mounting With A Slant Mounting Base
Network Fisheye Camera·Quick Start Guide 2.2 Wall Mounting with a Slant Mounting Base The wall mounting with a slant mounting base provides a wider surveillance view compared to the wall mounting. And you need to purchase a slant mounting base separately if this mounting method is selected. - Page 17 Network Fisheye Camera·Quick Start Guide Figure 2-6 Hammer the Screws 3. Connect the corresponding power cable, network cable, audio and alarm cables. 4. Align the screw holes to the inserted screws, hook the camera body to the screws, and route the camera body to secure the camera with the screws.
- Page 18 Network Fisheye Camera·Quick Start Guide Figure 2-7 Install the Camera Body and Cover Lock Screw Figure 2-8 Tighten the Lock Screw on the Camera Cover...
-
Page 19: Wall Mounting With A Junction Box
Network Fisheye Camera·Quick Start Guide 2.3 Wall Mounting with a Junction Box You have to purchase a junction box separately if this mounting method is selected. Steps: 1. Fix the junction box to the wall with screws. Figure 2-9 Fix the Junction Box 2. -
Page 20: Wall Mounting With A Bracket
Network Fisheye Camera·Quick Start Guide Figure 2-10 Install the Camera Body and Cover Lock Screw Figure 2-11 Tighten the Lock Screw on the Camera Cover 2.4 Wall Mounting with a Bracket... - Page 21 Network Fisheye Camera·Quick Start Guide You have to purchase the bracket separately if this mounting method is selected. 1. Install the bracket to the wall. 2. Install the mounting base to the bracket. 3. Screw the three supplied screws half-deep to the mounting base. Figure 2-12 Install the Bracket 4.
- Page 22 Network Fisheye Camera·Quick Start Guide Figure 2-13 Install the Camera Body and Cover Figure 2-14 Tighten the Screw on the Camera Cover...
-
Page 23: Setting The Network Camera Over The Lan
Network Fisheye Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. -
Page 24: Activating The Camera
Network Fisheye Camera·Quick Start Guide 3.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. - Page 25 Network Fisheye Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
-
Page 26: Activation Via Sadp Software
Network Fisheye Camera·Quick Start Guide 3.2.2 Activation via SADP Software SADP software is used for detecting the online device, activating the camera, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods. -
Page 27: Modifying The Ip Address
Network Fisheye Camera·Quick Start Guide 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. - Page 28 Network Fisheye Camera·Quick Start Guide Note: Please refer to Chapter 3.2 to activate the camera if the camera is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.
-
Page 29: Accessing Via Web Browser
Network Fisheye Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:... - Page 30 Network Fisheye Camera·Quick Start Guide Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
- Page 31 Network Fisheye Camera·Quick Start Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in (1)
- Page 32 Network Fisheye Camera·Quick Start Guide Figure 4-4 Install Plug-in (2) 6. Reopen the web browser after the installation of the plug-in and repeat steps 2~4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera.
