HIKVISION DS-2CD20x2-I Quick Start Manual

Network bullet camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Camera
Network Bullet Camera
Quick Start Guide
UD.6L0201B1853A01
1

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION DS-2CD20x2-I

Summary of Contents for HIKVISION DS-2CD20x2-I

  • Page 1 Camera Network Bullet Camera Quick Start Guide UD.6L0201B1853A01...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.

  • Page 4: Regulatory Information

    Network Bullet Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules.

  • Page 5: Safety Instruction

    Network Bullet Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 6 Network Bullet Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ●...
  • Page 7 Network Bullet Camera·Quick Start Guide ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. Cautions ● Make sure the power supply voltage is correct before using the camera.
  • Page 8 Network Bullet Camera·Quick Start Guide ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average enduring time.

  • Page 9: Table Of Contents

    Network Bullet Camera·Quick Start Guide Table of Contents Appearance Description ............... 10 1.1 Overview of Type I Bullet Camera ......... 10 1.2 Overview of Type II Bullet Camera ........ 11 1.2.1 Micro SD Card Slot & Reset/ WPS Button ... 12 1.2.2 PoE Power Supply Configuration (Optional)..

  • Page 10: Appearance Description

    Network Bullet Camera·Quick Start Guide Appearance Description Overview of Type I Bullet Camera Figure 1-1 Type I Bullet Camera Table 1-1 Description Description Description Mounting Base Lens Back Box Sun Shield Front Box Type I camera does not support the function of Wi-Fi and SD card.

  • Page 11: Overview Of Type Ii Bullet Camera

    Network Bullet Camera·Quick Start Guide Overview of Type II Bullet Camera Figure 1-2 Type II Bullet Camera...

  • Page 12: Micro Sd Card Slot & Reset/ Wps Button

    Network Bullet Camera·Quick Start Guide Table 1-2 Description Description Description Mounting Base LED Indicator Adjustment Nut SD Card Slot 10/100M Self-adaptive Ethernet Main Body Interface Sun Shield Power Cable Lens GND Screw Reset/ WPS PoE Power Cable (Optional) Button 1.2.1 Micro SD Card Slot & Reset/ WPS Button Move the Micro SD / Reset/WPS Cover aside, and you can see the Reset button, WPS button and the micro SD card slot.
  • Page 13 Network Bullet Camera·Quick Start Guide Installing the SD Card Insert the micro SD card into the micro SD card slot. SD Card Slot Figure 1-4 Install the SD Card Resetting the Camera Press WPS/RESET about 10s when the camera is power on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
  • Page 14 Network Bullet Camera·Quick Start Guide WPS/RESET Figure 1-5 WPS/Reset Button Setting the WPS Protocol A wireless router with the WPS function is required to enable the WPS function of the camera. Refer the steps below. Steps: Press the WPS button on the router. Press the WPS button (about 2s) on the camera within 120s you enable the WPS of the router to join in the wireless network.
  • Page 15 Network Bullet Camera·Quick Start Guide WPS/RESET Figure 1-6 WPS/Reset Button  The WPS button works as a reset button only when you press it when the camera is powering on.  Press the WPS button on the camera, and then press the WPS button on the router will work as well, and the expire time of WPS connection on the camera is 120s.

  • Page 16: Poe Power Supply Configuration (Optional)

    Network Bullet Camera·Quick Start Guide 1.2.2 PoE Power Supply Configuration (Optional) This type of bullet camera support PoE power supply. The connection of PoE power cables is shown as follows. Connect the single-cable end to the PoE router. Connect the power and Ethernet cables on the other end to the corresponding cables of the camera.

  • Page 17: Installation

    Network Bullet Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.

  • Page 18: Installation Of The Bullet Camera

    Network Bullet Camera·Quick Start Guide Installation of the Bullet Camera Both wall mounting and ceiling mounting are suitable for the IR bullet camera. Wall mounting will be taken as an example in this section. You can take steps of wall mounting as a reference if ceiling mounting is adopted.
  • Page 19 Network Bullet Camera·Quick Start Guide Figure 2-2 Secure the Camera to the Ceiling 4. Connect the corresponding power/ Video Output cables. 5. Adjust the Lens. 1). Loosen the adjustable nut. 2). Adjust the pan direction [0°~360°]. 3). Adjust the tilt direction [0°~90°]. 4).

  • Page 20: Installation Of Water-Proof Jacket

    Network Bullet Camera·Quick Start Guide Adjust Nut 0°~360° 0°~360° 0°~90° Figure 2-3 3-axis Adjustment Installation of Water-proof Jacket It is recommended to adopt the water-proof jacket (supplied) for the network interface when the camera is installed outdoor. Steps: 1. If the network cable has been settled down, cut off the plug of the network cable first.
  • Page 21 Network Bullet Camera·Quick Start Guide 6. Wrap the network interface with the main body of the water-proof jacket, and then rotate the fix nut clockwise to assemble it to the main body of the water-proof jacket. Network Interface O-ring Plug Water-proof Jacket Water-proof Ring Fix Nut Network Cable Figure 2-4 Install Water-proof Jacket...

  • Page 22: Setting The Network Camera Over The Lan

    Network Bullet Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 23: Activating The Camera

    Network Bullet Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.
  • Page 24 Network Bullet Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 25: Activation Via Sadp Software

    Network Bullet Camera·Quick Start Guide 3.2.2 Activation via SADP Software SADP software is used for detecting the online device, activating the camera, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods.

  • Page 26: Modifying The Ip Address

    Network Bullet Camera·Quick Start Guide 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 27 Network Bullet Camera·Quick Start Guide Note: Please refer to Chapter 3.2 to activate the camera if the camera is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.

  • Page 28: Accessing Via Web Browser

    Network Bullet Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 29 Network Bullet Camera·Quick Start Guide Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
  • Page 30 Network Bullet Camera·Quick Start Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in (1)
  • Page 31 Network Bullet Camera·Quick Start Guide Figure 4-4 Install Plug-in (2) 6. Reopen the web browser after the installation of the plug-in and repeat steps 2~4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera.
