  • Page 1 Camera Corrosion-Proof Network Box Camera Quick Start Guide UD.6L0201B2151A02...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Network Box Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 Network Box Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 6 Network Box Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ●...
  • Page 7 Network Box Camera·Quick Start Guide ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. Cautions ● Make sure the power supply voltage is correct before using the camera.
  • Page 8 Network Box Camera·Quick Start Guide ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average enduring time.

  • Page 9: Table Of Contents

    Network Box Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............9 2 Installation ..................11 2.1 Default Parameters............12 2.2 Power supply of the housing ........12 2.3 Cable Connection ............13 2.3.1 Type I Housing Wiring ......... 14 2.3.2 Type II Housing Wiring ........

  • Page 10: Appearance Description

    Network Box Camera·Quick Start Guide 1 Appearance Description The corrosion-proof network box camera can be categorized into three types: Type I corrosion-proof network box camera is equipped with built-in heater and fan modules, as shown below. Figure 1-1 Overview of Type I Camera Type II corrosion-proof network box camera is equipped with wiper, built-in heater and fan modules, as shown below.
  • Page 11 Network Box Camera·Quick Start Guide Figure 1-3 Overview of Type III Camera...

  • Page 12: Installation

    Network Box Camera·Quick Start Guide 2 Installation Before you start ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.

  • Page 13: Default Parameters

    Network Box Camera·Quick Start Guide Default Parameters The default RS-485 parameters of the bracket are listed below: Baud Rate: 9600 Protocol: Pelco-D Address Bit: 0 If ABF function is supported by the network camera, please refer to 3.2 and disable ABF function for wiper control and PTZ control. Select the power adapter according to specific requirement.

  • Page 14: Cable Connection

    Network Box Camera·Quick Start Guide 2.3 Cable Connection According to different places and environment for the housing installation, it is required to perform the investigation and programming before operating the wiring for the safe and stable power supply and wiring. During the wiring, take the following advices: ...

  • Page 15: Type I Housing Wiring

    Network Box Camera·Quick Start Guide 2.3.1 Type I Housing Wiring Black 12V DC- Camera Red 12V DC+ 24V AC Input Heater Figure 2-1 Type I Housing Wiring Steps: 1. Connect the cables of 24V AC power supply (power input) to the housing input terminal.

  • Page 16: Type Ii Housing Wiring

    Network Box Camera·Quick Start Guide  If the camera does not support 12V DC power-supply, an additional power adapter should be purchased. 2.3.2 Type II Housing Wiring Yellow RS485- Orange RS485+ Camera Black 12V DC- Red 12V DC+ 24V AC Input Heater Figure 2-2...

  • Page 17: Type Iii Housing Wiring

    Network Box Camera·Quick Start Guide 4. After connecting the camera, set the RS-485 parameters to be Baud Rate: 9600, Protocol: Pelco-D, Address Bit: 0.  Type II housing is equipped with fan (Power 4W) and wiper functions. A 24V AC power supply is required (purchased separately) for the proper use of device.
  • Page 18 Network Box Camera·Quick Start Guide Black 12V DC- Camera Red 12V DC+ 24V AC Input Heater Figure 2-3 Type III Housing Wiring Steps: 1. Connect the cables of 24V AC power supply (power input) to the housing input terminal. 2. Connect the power output cables to the camera. The power output is 12V DC, and the positive/negative terminals should be distinguished.

  • Page 19: Housing Installation

    Network Box Camera·Quick Start Guide 3 Housing Installation 3.1 Before You Start  Please make sure that the device in the package is in good condition and all the assembly parts are included.  Make sure that all the related equipment is powered-off during the installation.
  • Page 20 Network Box Camera·Quick Start Guide install the camera lens first. Here we take the installing box camera procedure as an example. Steps: 1. Install the lens (not supplied) to the camera and rotate it to get it tightened. Figure 3-1 Install the Lens 2.

  • Page 21: Assemble The Housing

    Network Box Camera·Quick Start Guide  Install the adapter ring to the lens interface if C type lens is adopted. Figure 3-3 CS Adapter Ring  A manual-iris lens can be directly installed to the camera without plugging the power cable of the auto-iris to the auto-iris interface.
  • Page 22 Network Box Camera·Quick Start Guide ： Steps 1. Take off the front cover of corrosion-proof housing with the supplied lever, as shown below. Loosen six AM4×10 screws on the rear cover of the housing and take off the rear cover. Front Cover Rear Cover Lever...
  • Page 23 Network Box Camera·Quick Start Guide 3. Install the lens of the camera. For detailed information of camera lens installation, refer to 3.2. Fix the camera and the layer board by fixing the screws, as shown below. Figure 3-6 Fix the Camera to Layer Board 4.
  • Page 24 Network Box Camera·Quick Start Guide Water-proof Plug Nut Cable Outlet Sealing Plug Spacer Sealing Ring Plug Nut Figure 3-8 Disassemble the Water-proof Plug 6. Select a plug nut and route the cables as power cable and network cable through the screw nut, spacer, sealing ring and cable outlet in order.
  • Page 25 Network Box Camera·Quick Start Guide  Make sure the cable size meets the inside diameter of the sealing ring (11mm) to ensure the water-proof performance of the corrosion-proof housing.  One of the water-proof plugs is sealed with the sealing plug by default.
  • Page 26 Network Box Camera·Quick Start Guide Housing Layer Board Figure 3-11 Insert the Layer Board 9. Rotate the front cover clockwise with the supplied lever to fix it, and tighten the screws of the rear cover of the housing to fix the rear cover.

  • Page 27: Assemble The Type Ii Housing

    Network Box Camera·Quick Start Guide 3.3.2 Assemble the Type II Housing Purpose: Type II housing is equipped with heater, fan, and wiper, please refer to the steps below for the assemble procedure of the Type II corrosion-proof housing. Steps: 1. Take off the front cover of corrosion-proof housing with the supplied lever, as shown below.
  • Page 28 Network Box Camera·Quick Start Guide  Before disassembling the housing, please push aside the wiper of the housing to the side of the front cover.  While taking out the layer board, please be careful to avoid breaking the cable wiring between the wiper and layer board. 3.
  • Page 29 Network Box Camera·Quick Start Guide 5. Disassemble the water-proof plug on the rear cover of the housing by rotating the plug anticlockwise. Water-proof Plug Nut Cable Outlet Sealing Plug Spacer Sealing Ring Plug Nut Figure 3-18 Disassemble the Water-proof Plug 6.
  • Page 30 Network Box Camera·Quick Start Guide  Make sure the cable size meets the inside diameter of the sealing ring (11mm) to ensure the water-proof performance of the corrosion-proof housing.  One of the water-proof plugs is sealed with the sealing plug by default.

  • Page 31: Assemble The Type Iii Housing

    Network Box Camera·Quick Start Guide Front Cover Housing Main Body Rear Cover Lever Figure 3-21 Assembling the Housing 9. Complete the assembling of housing. Figure 3-22 Complete the Assembling 3.3.3 Assemble the Type III Housing Purpose: Type III housing is equipped with heater, fan, and IR light supplement, please refer to the steps below for the assemble procedure of the Type III corrosion-proof housing.
  • Page 32 Network Box Camera·Quick Start Guide Front Cover Rear Cover Figure 3-23 Disassemble the Housing 2. Loosen the screw between the main body of housing and layer board. Take off the layer board from the housing, as shown below. Housing Main Body Layer Board Figure 3-24 Take Off Layer Board...
  • Page 33 Network Box Camera·Quick Start Guide Figure 3-25 Fix the Camera to Layer Board 4. After connecting the cables, adjust the lens focal length of the camera to fit the surveillance scene. Insert the layer board and camera into the housing, as shown below. Housing Layer Board Figure 3-26...
  • Page 34 Network Box Camera·Quick Start Guide Water-proof Plug Nut Cable Outlet Sealing Plug Spacer Sealing Ring Plug Nut Figure 3-27 Disassemble the Water-proof Plug 6. Select a plug nut and route the cables as power cable and network cable through the screw nut, spacer, sealing ring and cable outlet in order.
  • Page 35 Network Box Camera·Quick Start Guide  Make sure the cable size meets the inside diameter of the sealing ring (11mm) to ensure the water-proof performance of the corrosion-proof housing.  One of the water-proof plugs is sealed with the sealing plug by default.

  • Page 36: Installing The Bracket

    Network Box Camera·Quick Start Guide Front Cover Figure 3-30 Assembling the Housing 9. Complete the assembling of housing. Figure 3-31 Complete the Assembling 3.4 Installing the Bracket Purpose: To wall mount the corrosion-proof housing and camera, the wall-mounting bracket is required. The installation of the corrosion-proof housing is shown below.
  • Page 37 Network Box Camera·Quick Start Guide Universal Joint Module Universal Joint Base Bracket Figure 3-32 Take Off the Bracket 2. Drill the screw holes and the cable hole in the wall. Hammer the supplied M8 expansion screws into the screw holes. Wall M8 Expansion Scew Figure 3-33...
  • Page 38 Network Box Camera·Quick Start Guide Route the Cables through the Cable Hole Figure 3-34 Route the Cables 4. Install the assembled housing to the universal joint module with the 1/4 UNC screws, as shown below. Housing Base Universal Joint Module 1/4 UNC Screw Figure 3-35 Install the Universal Joint Module...
  • Page 39 Network Box Camera·Quick Start Guide as shown below. The surveillance angle can be adjusted from -45° to 45° (horizontal). 45° Adjusting Screw -45° Bracket Module Figure 3-36 Adjust the Surveillance Angle 6. Tighten the adjusting screw to fix the bracket module. Install the housing onto the bracket and make sure that the universal joint module is attached to the bracket module, as shown below.
  • Page 40 Network Box Camera·Quick Start Guide Figure 3-38 Fix the Housing and the Bracket...

  • Page 41: Setting The Network Camera Over The Lan

    Network Box Camera·Quick Start Guide 4 Setting the Network Camera over the You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 42: Activating The Camera

    Network Box Camera·Quick Start Guide 4.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported.
  • Page 43 Network Box Camera·Quick Start Guide Figure 4-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your...

  • Page 44: Activation Via Sadp Software

    Network Box Camera·Quick Start Guide 4.2.2 Activation via SADP Software SADP software is used for detecting the online device, activating the camera, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods.

  • Page 45: Modifying The Ip Address

    Network Box Camera·Quick Start Guide 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your...
  • Page 46 Network Box Camera·Quick Start Guide 2. Select an active device. Please refer to Chapter 3.2 to activate the camera if the camera is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.

  • Page 47: Accessing Via Web Browser

    Network Box Camera·Quick Start Guide 5 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 48 Network Box Camera·Quick Start Guide The IP address gets locked if the admin user performs 7 failed password attempts (5 attempts for the user/operator). Click Login. Figure 5-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera.
  • Page 49 Network Box Camera·Quick Start Guide Figure 5-2 Download Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat steps 2~4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera. 0503021051217...
