  • Page 1 5-inch Speed Dome Quick Guide UD.6L0201B1015A01...
  • Page 2 5-inch Speed Dome·Quick Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to 5-inch speed dome. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.

  • Page 3: Regulatory Information

    5-inch Speed Dome·Quick Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Instruction

    5-inch Speed Dome·Quick Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
  • Page 5 5-inch Speed Dome·Quick Guide  Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger).  Do not aim the speed dome at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.

  • Page 6: Table Of Contents

    5-inch Speed Dome·Quick Guide Table of Contents 1 Overview ...................... 6 2 Installation ....................7 2.1 Wall Mounting ..................... 7 2.2 In-ceiling Mounting.................... 10 2.3 Ceiling Mounting ....................12 2.3.1 Removing the In-ceiling Mount ..............12 2.3.2 Wiring For Ceiling Mounting Applications ............. 13 2.3.3 Mounting ....................

  • Page 7: Overview

    5-inch Speed Dome·Quick Guide 1 Overview Please turn the power off before connect the cables. The cable interfaces of network speed dome are shown in following figure(left). The cables are distinguished by different colors. The labels attached on the cables are for identification.

  • Page 8: Installation

    5-inch Speed Dome·Quick Guide 2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Note: Do not drag the speed dome with its waterproof cables as shown in Figure 2-1, otherwise the waterproof performance is affected.
  • Page 9 5-inch Speed Dome·Quick Guide 3. Align the cuts on the lower dome with the lock screws on the back box to reinstall the lower dome. Tighten the lock screws. 4. Drill 4 screw holes in the wall according to the holes of the mount, and then insert M8 expansion screws into the mounting holes.
  • Page 10 5-inch Speed Dome·Quick Guide Note: The dimension of pendant adapter is G1 9. Hook the back box of the speed dome to the mount with the safety rope. Route the cables through the mount. 10. Align the direction label of pendant adapter with the label of the back box to install the speed dome.

  • Page 11: In-Ceiling Mounting

    5-inch Speed Dome·Quick Guide 2.2 In-ceiling Mounting Before you start: The in-ceiling mounting is applicable to the indoor ceiling construction. The followings are the mandatory precondition for mounting:  The height of the space above the ceiling must be more than 250mm. ...
  • Page 12 5-inch Speed Dome·Quick Guide 6. Install the speed dome to the ceiling. Steps: 1). Loosen the two lock screws on both sides of the back box and make the locks in internal position, as shown in the following figure: Lock Lock Figure 2-9 Locks and Lock Screws 2).

  • Page 13: Ceiling Mounting

    5-inch Speed Dome·Quick Guide Arrow label Notch Figure 2-11 Install the Trim Ring 2.3 Ceiling Mounting Before you start:  The thickness of the ceiling must ranges from 5 to 40mm.  The ceiling must be strong enough to withstand more than 4 times the weight of the dome and its accessories.

  • Page 14: Wiring For Ceiling Mounting Applications

    5-inch Speed Dome·Quick Guide Figure 2-12 Remove the Mount 2. Install 4 bolts to the screw holes as shown in Figure 2-13. Figure 2-13 Install the bolts 2.3.2 Wiring For Ceiling Mounting Applications The cables of dome can be routed either from the top or the side of the back box, as shown in Figure 2-14.

  • Page 15: Mounting

    5-inch Speed Dome·Quick Guide 2.3.3 Mounting Before you start:  If the speed dome is installed to the wooden wall, use the self-tapping screws to secure the mounting base.  If the dome is installed to the cement wall, drill three Φ5 screw holes onto the wall according to the hole locations, and then secure the mounting base to the wall with expansion screws.
  • Page 16 5-inch Speed Dome·Quick Guide Push forwards Line Push upwards Spring Lock clip Figure 2-16 Attach the Back Box to the Mounting Base Notes:  Please remove the protective film on the lower dome after the installation is finished.  Do not touch the bubble of the lower dome directly by hand. The image blurs otherwise.

  • Page 17: Setting The Dome Over The Lan

    5-inch Speed Dome·Quick Guide 3 Setting the Dome over the LAN To view and configure the speed dome via LAN(Local Area Network), you need to connect the network speed dome in the same subnet with your PC. Then, install the SADP or client software to search and change the IP of network speed dome.
  • Page 18 5-inch Speed Dome·Quick Guide Figure 3-2 Searching Online Devices Note: Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online device list manually.
  • Page 19 5-inch Speed Dome·Quick Guide Figure 3-3 Select a Device Figure 3-4 Modify Network Parameters 3. Enter the IP address of speed dome in the address field of the web browser to view the live video. Notes:  The default value of the IP address is 192.0.0.64. The default user name of administrator is admin, and password is 12345.

  • Page 20: Accessing Via Web Browser

    5-inch Speed Dome·Quick Guide 4 Accessing via Web browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 7.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above version...
  • Page 21 5-inch Speed Dome·Quick Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the user manual of network speed dome.
