rings is out (parameter 56), the unit will select the number from the second group (parameter 2).
The next press of the same button again selects the number from the first group, etc....
When visitor push the button after line is picked up the Smile DoorPhone hangs up for time setup by
parameter 54 and then picks up the line and dial new number. The dialing number is either by tone dial
(DTMF) or pulse dial up setting by parameter 41. There is one more option: the line hangs up by again
pushing of same button (parameter 4*).
3.3. Telephone Caller
A Telephone Caller is a person that is in phone connection with Smile DoorPhone.
3.3.1. Outgoing call
An "outgoing" call is a call from the unit (i.e. when a visitor presses a button). Once the visitor has
pressed a button a telephone will ring. On answering the telephone, you will be able to converse with the
visitor. 10 seconds before the maximum call duration (parameter 52) the unit will emit a tone to warn
that the call will end. The call may be extended by pressing the key as set in parameter 42. A code may
be dialed to close the relay (parameter 35), releasing the lock. Hanging up the telephone will end the
call, as will the busy tone from the PBX.
3.3.2. Incoming call
An incoming call is a call to the unit. After dialing the PBX extension number to which the unit is
connected, the unit will ring for the set number of rings (parameter 51), the unit will lift up and it is
possible to speak. The possibilities are the same as with outgoing call (Chapter 3.3.1). It is also possible
to switch between Day and Night service.
If, within the first 10 seconds, the service password is entered (#0000), the unit will switch to
•
programming mode and voice communication will cease.
Second exception is when DIP1 is switch to position ("SERVIS"). Then you enter in programming
•
mode directly without dialing service password.
During an incoming call it is possible to restrict relay control. This can be useful in some special
•
applications.
4. Parameter programming
4.1 Programming from a telephone by DTMF
The Smile DoorPhone may be set to programming mode in two ways:
by password : dial the unit's number (either extension number, if connected to a PBX or
•
telephone number, if connected to a PSTN line). The unit will answer (you will hear the Pick up
line tone – see Chapter 3.1). Within 10 seconds dial #xxxx, where xxxx is the password for
entry to programming and, if OK, the registration tone for programming mode will sound, and
afterwards the Programming tone is heard (see Chapter 3.1).
By "SERVICE" switch – dial the unit in the same way as in 1, but when the SERVICE switch is
•
connected, the unit will automatically enter programming mode. You will hear the call connection
confirmation tone; the confirmation tone for programming mode and afterwards the
Programming tone is heard. (see Chapter 3.1).
Linkcom France
11 rue du Soleil Levant 92140 CLAMART
Copyright © 2011 – Linkcom – All rights reserved
8
