3. Smile DoorPhone Service

3.1. Signaling overview

The Smile DoorPhone signaling acoustically stages which are happening during operation. Samples of
acoustical sounds you can play in Smile DoorPhone Config.
Stage
Line pick up (OFF HOOK) type 1
Line hang up (ON HOOK) type1
Line pick up (OFF HOOK) type 2
Line hang up (ON HOOK) type2
Command confirmation by phone
Alerting (knocking) into call
Call ending alert
Relay activation signal
Programming enter by phone
Programming by phone
Parameter confirmation
Programming enter by PC
Line connection (Reset)
Error (generally all incorrects)
Memory empty (no number
programmed)
For the problems identification is very good when you know the tones. It helps you monitor how door
intercom works and where from comes the problem. The signaling might be switch of in a few levels
(Parameters 61,62,63 and 65).
3.2. Visitor at the door
When the visitor finds the desired name and push it, the Smile DoorPhone pick up the line and play the
tone line pick up (when is not switch off by parameter 62) and calls the phone number saved under the
button (parameter 1). On the Smile DoorPhone speaker you hear ringing tone and the destination
phone ringing.
As soon as the destination phone pick up, you can talk to visitor at the door.
When is electrical lock is connected to the Smile DoorPhone, you can open the door for visitor by dial
DTMF code on the destination phone.
When the destination phone hang-up the line then the Smile DoorPhone hangs up after busy tone
detection. When the call duration is longer then setup limit (parameter 52) 10 sec before hang up, the
Smile DoorPhone sends a alerting tone of call ending, dial * or # (parameter 42) to prolong the call.
The dialed number is dictated by the chosen mode, which is set in the unit (parameter 47):
Day/Night mode: If the unit is in Day mode, it will always dial the number set in parameter 1,
•
In Night mode, it will always dial the number set in parameter 2. The mode switchover is set in
parameters 45,46.
2 groups numbers mode: On the first press the number set in parameter 1 will be dialed. When
•
the same button is pushed or 10 seconds after dial busy tone is detected, or setup number of
Linkcom France
11 rue du Soleil Levant 92140 CLAMART
Tone
Tones
frequency
980-1333-1650
–▄■▄■▀–
–▀■▄■▄– 1650-1333-980
800-1067-1200-
–▄■▀–
1333
1333-1200-1067-
–▀■▄–
800
800
––█––
─┴─┴─
1333
–■–■–■–
Modulovaný
─▒▒▒▒▒▒─
–▄■▀– 980-1067-1180
Modulovaný
––▓–▓–––––
800
––█––
980-1067-1180
–▄■▀–
1850-1067-1850
–■–▄–■–
800
–■–■–■–■–■–■–
1300-2100
–▄■▄■▄■▄■–
