3 SlimDoorPhone Services

3.1 Signalling Overview

The unit signals acoustic conditions that may occur during operation. You can listen to
the signalling samples in the ID Manager program.
Condition
Pick up line
Hang up line
Confirm command
Dialling
Call
Conversation end warning
Enter programming (phone or
PC)
Programming tone
Parameter confirmation
Programming from PC
Connection to line (Reset)
Error
Empty memory
Open lock

3.2 Visitor at the door

When a visitor presses a button the unit will lift up the line, either immediately
(providing the button is not the first number from code lock), or with delay (parameter 53)
and after period given by parameter 55, will dial the programmed phone number. The dialled
number is dictated by the chosen mode, which is set in the unit (parameter 47):
Day/night mode = If the unit is in Day mode, it will always dial the number set in
-
parameter 1, In Night mode, it will always dial the number set in parameter 2. The
mode switchover is set in parameters 45,46.
Two-Group mode = on the first press the number set in parameter 1 will be dialled.
-
By pressing of the same button twice, or on detection of busy tone after trying the
first number, the unit will select the number from the second group (parameter 2).
The next press of the same button again selects the number from the first group,
etc........
If the button is pressed after the line has been opened (but before the call is
answered), the unit will hang up for the period given by parameter 54, lift up the line and
dial the other group number.
The relay can be controlled by pressing the buttons in the combination that is set in the
preprogrammed code (parameters 32-34). The time between presses must not be bigger
than that set in parameter 53. The unit will lift up and close the corresponding relay or the
period given by parameter 36 . Then it will hang up.

3.3 Telephone Caller

A Telephone Caller is a person that is in phone connection with SlimDoorPhone.
Linkcom France
11 rue du Soleil Levant 92140 CLAMART
Tone
Tones
frequency
– – – – 425-850-1275
– – – 1275-850-425
–– –– 425
DTMF/Pulse
– – – – 1275
– – – – 850
–– – ––––– mod. 850
–– ––
Silent
– – – – 1275-850-1275
– – – – –
425....
– –
850-1275-
– – – – –
– – 1700...
modul 50/1250
